Product Description
Dirt Dog Heavy-Duty Landscape Rake | MLR Series | Overall Width 72", 84" & 96" inches | Horsepower 30-60 HP | For Tractors
Included Options:
DESCRIPTION
The MLR Heavy-Duty Landscape Rake is built to handle the toughest landscaping tasks with ease. Designed for land clearing, soil preparation, and debris removal, this rake is perfect for farmers, landscapers, and property owners who need a high-performance implement for their tractors.
With a heavy-duty 4" × 4" × 3/8" rake frame, the MLR series provides durability and stability in various terrains. The heat-treated, high-carbon spring steel tines ensure maximum strength, while the adjustable angle settings allow for precision grading and raking.
The Category I Quick Hitch compatibility ensures easy and secure attachment to your tractor. Available in 6 ft, 7 ft, and 8 ft widths, this landscape rake is versatile enough to tackle small and large-scale projects.
Key Features
- Heavy-Duty Frame: Built with 4" × 4" × 3/8" steel for rugged durability.
- Quick Hitch Compatible: Designed for Category I Quick Hitch systems for fast and secure attachment.
- Adjustable Raking Angles: 5 forward angles and 3 reverse angles provide precise raking control.
- Durable Spring Steel Tines: Heat-treated, high-carbon tines enhance performance and longevity.
- Size Options: Available in 6 ft, 7 ft, and 8 ft widths to suit different applications.
Detailed Specifications
| Feature | MLR72 | MLR84 | MLR96 |
|---|---|---|---|
| Overall Height | 41 ½ inches | 41 ½ inches | 41 ½ inches |
| Overall Width | 6 ft | 7 ft | 8 ft |
| Overall Depth | 48 inches | 48 inches | 48 inches |
| Weight | 249 lbs | 266 lbs | 291 lbs |
| Angle Adjustment (F-R) | 30° – 15° | 30° – 15° | 30° – 15° |
| Adjustment Method | Manual or Hydraulic | Manual or Hydraulic | Manual or Hydraulic |
| Number of Tines | 36 | 45 | 48 |
| Horsepower (2WD-4WD) | Up to 60 HP | Up to 60 HP | Up to 60 HP |
| Lower Pitch Pin Height | 22 inches | 22 inches | 22 inches |
| Hitch Type | 3-Point Category I & Quick Attach | 3-Point Category I & Quick Attach | 3-Point Category I & Quick Attach |
| Paint Options | Yellow Powder Coat Paint | Yellow Powder Coat Paint | Yellow Powder Coat Paint |
