Dirt Dog Retractable Box Blade | RBX Series | Overall Width 72", 78" & 84" inches | Horsepower 55-60 HP | For Tractor

Product Description

Dirt Dog Retractable Box Blade | RBX Series | Overall Width 72", 78" & 84" inches | Horsepower 55-60 HP | For Tractor

Included Options:

DESCRIPTION

Box Blades – RBX

Dirt Dog’s Retractable Box Blade is designed with the professional in mind. The RBX is a massive three point lift box with the ability to lower or retract the shanks depending on the job. With the shanks down, the RBX becomes a scarifiering machine. Penetrating hard ground with its shanks much deeper than a standard box blade. Each heat treated shank has a replaceable plow point and is adjustable to dial in the perfect depth. The RBX is attached to the tractor using a heavy duty triple lug hitch and is compatible with all category I & II three point lift tractors up to 70 hp. The scarifier box is retractable from the seat of the tractor with a pull from the handle. Retracting the shanks allows the use of the RBX’s massive box for grading and moving large volumes of dirt. The RBX’s reversible and replaceable ½” x 6” front cutting edge grades while the formed moldboard rolls the dirt as it fills up the box. The floating tail gate allows the front cutting edge to cut deeper by floating up and out of the way and instantly engages when the operator needs to back fill. When professionals need to level, grade and backfill large areas of land, Dirt Dog’s Retractable Box Blade is the perfect tool for the job.

Key Features

• Category I & II Hitch: Ensures compatibility with a range of tractors for versatile use.
• Heavy-Duty A-Frame: Provides strength and durability for demanding tasks.
• Heavy-Duty Triple Strap Hitch: Offers enhanced stability and long-lasting performance.
• 5″ × 5″ × 1/2″ Scarifier Tube: Built for durability and robust operation.
• Heat-Treated Shanks with Replaceable Tips: Ensures longevity and efficient soil penetration.
• Two 1/2″ × 6″ Replaceable Cutting Edges: Designed for effective grading and easy maintenance.
• Available in Multiple Widths: Offered in 6, 6 1/2, and 7 ft options to suit different requirements.
• Rear Floating Back Fill Blade: Adds versatility by allowing efficient backfilling operations.

Detailed Specifications
