Ditch Doctor Excavator Ditch Trencher | Model DD15 | 12-45 GPM | Weight 800 lbs | For Excavator

Product Description

Ditch Doctor Excavator Ditch Trencher | Model DD15 | 12-45 GPM | Weight 800 lbs | For Excavator

DESCRIPTION

The Ditch Doctor® Excavator Attachment is available in two sizes with either a wet scroll case or dry scroll case. The Ditch Doctor® DD15 is for excavator sizes of between 4-12 tons (8818-26000 lb) with a hydraulic flow rate of between 12-45 GPM (46-170 LPM). Ditch Doctor® DD22 is for excavator sizes of between 13-25 tons (29000-55000 lb) with a hydraulic flow rate of between 24-75 GPM (91-284 LPM). Capable of creating a one stage or Two-Stage ditch in various soil conditions and in up to 3 feet (90cm) of water it is a unique and versatile attachment. The variable speed control allows for the even, self levelling distribution of spoil. The Ditch Doctor® method of ditching is a faster and more cost effective alternative to the conventional bucket and excavator, and kinder to the environment.

The Ditch Doctor® DD15 excavator attachment is the smaller of the two for use on an excavator size of between 4 -12 tons with a hydraulic flow rate of between 12-45 GPM and weights 800 lbs.

Key Features

• Adaptable Design – Wet scroll case (5 teeth) and dry scroll case (6 teeth) for different soil and moisture conditions.
• Eco-Friendly – Reduces erosion and maintains a natural buffer zone.
• Time and Cost Efficient – Cuts down on fuel, labor, and trucking costs with 3x faster ditching.
• User-Friendly Maintenance – Self-cleaning with replaceable components for minimized downtime.
• Powerful Operation – Delivers 35-45 GPM hydraulic flow, ideal for demanding ditching tasks.

Detailed Specifications

In Package

• Wet scroll case with 5 teeth

• Dry scroll case with 6 teeth

• Interchangeable scroll case

• Quick connect hydraulic lines

• Custom quick attachment plate

• Round contoured bottom

• Variable displacement motors

• Easily replaced worn components

• Easy to maintain and self cleaning

• 1 year warranty
• Speed control for Adjusting the spool-speed hanger bracket not included
