ERSKINE

Erskine Hydraulic Breaker | 210X, 310X, 360X, 410X & 460X Model | With Moil & Blunt Tool Point | For Skid Steer

Erskine Hydraulic Breaker | 210X, 310X, 360X, 410X & 460X Model | With Moil & Blunt Tool Point | For Skid Steer

Regular price $10,695.00
Regular price Sale price $10,695.00
Sale Sold out
Customizable
Fast
24/7 Support
  • Efficient Design
  • Vibration and Shock Control
  • High Impact Energy
  • Minimal Maintenance
  • Low Recoil and Hydraulic Pressure Spike
  • Unique Trapezoidal Shock Wave
View full details

Product Description

Erskine Hydraulic Breaker | 210X, 310X, 360X, 410X & 460X Model | With Moil & Blunt Tool Point | For Skid Steer

DESCRIPTION

Powerful Performance for Demanding Applications

The Hydraulic Breaker is built to deliver high-impact energy, making it ideal for tasks like breaking concrete, rock, and other challenging materials. With a robust design that includes only two moving parts, this breaker ensures maximum efficiency and durability, even when operating on inclines. Shock-absorbing polymers help to reduce vibrations, enhancing operator comfort and minimizing wear on the machine.

Efficient and Low-Maintenance Design

Engineered for longevity, this breaker features a unique trapezoidal shock wave for increased breaking power, a low recoil design for smooth operation, and only one grease fitting, reducing maintenance requirements. Its hybrid gas/oil technology offers reliable performance, while innovative noise and vibration damping make it suitable for both urban and remote job sites.

Key Features

  • Power Booster: High performance with low vibration
  • Central Lubrication: Easy and efficient maintenance
  • Field-Replaceable Bushing: Simplifies maintenance in the field
  • Hybrid Technology: Combines gas and oil for reliable operation
  • Innovative Design: Fewer components for enhanced durability
  • Noise and Vibration Damping: Reduces noise and vibration levels
  • Internal Control Valve: Highly efficient and reliable for smooth operation

Detailed Specifications

Specification 210X
Part Number 901546
Carrier Weight Class 4,400-9,900 lbs
Weight 600 lbs
Operating Pressure 1,595-2,030 psi
Oil Flow Range 8-13 GPM
Impact Rate 670-1,500 BPM
Tool Points Moil, Blunt, Chisel
Specification 310X
Part Number 901547
Carrier Weight Class 6,600-13,200 lbs
Weight 715 lbs
Operating Pressure 1,595-2,030 psi
Oil Flow Range 9-16 GPM
Impact Rate 520-1,300 BPM
Tool Points Moil, Blunt, Chisel
Specification 360X
Part Number 901548
Carrier Weight Class 8,800-19,800 lbs
Weight 825 lbs
Operating Pressure 1,450-2,030 psi
Oil Flow Range 12-20 GPM
Impact Rate 530-1,200 BPM
Tool Points Moil, Blunt, Chisel
Specification 410X
Part Number 901538
Carrier Weight Class 11,000-26,500 lbs
Weight 1,035 lbs
Operating Pressure 1,740-2,175 psi
Oil Flow Range 16-24 GPM
Impact Rate 530-1,000 BPM
Tool Points Moil, Blunt, Chisel
Specification 460X
Part Number 901539
Carrier Weight Class 13,200-29,700 lbs
Weight 1,150 lbs
Operating Pressure 1,740-2,175 psi
Oil Flow Range 18-26 GPM
Impact Rate 530-1,000 BPM
Tool Points Moil, Blunt, Chisel

In Package

  • Hydraulic Breaker (210X, 310X, 360X, 410X, or 460X model)
  • Set of tool points (Moil, Blunt, and Chisel)
  • User manual and maintenance guide
  • Warranty documentation

Available Options

  • Model Options: 210X, 310X, 360X, 410X, 460X
  • Tool Points: Moil, Blunt, Chisel options included
  • Carrier Weight Class: Different weight classes for various applications
