Erskine Pavement Saw | PS-915, PS-925 & PS-945 | With Pistol Grip Control Harness | For Skid Steer
Erskine Pavement Saw | PS-915, PS-925 & PS-945 | With Pistol Grip Control Harness | For Skid Steer
Regular price
$16,695.00
Regular price
Sale price
$16,695.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Erskine Pavement Saw | PS-915, PS-925 & PS-945 | With Pistol Grip Control Harness | For Skid Steer
DESCRIPTION
The Pavement Saw is an efficient, powerful attachment designed for heavy-duty cutting tasks, making it a cost-effective alternative to larger self-propelled saw units. Equipped with a robust planetary drive motor, this saw delivers the high torque needed to cut through asphalt and other hard surfaces with ease. Featuring a 9" cutter wheel depth, it’s ideal for creating expansion joints, pavement cuts, utility line slots, and traffic loops.
This tool’s patented electro-hydraulic side-shift allows precise cuts close to walls, curbs, and fixed objects. The guide arm ensures straight and accurate cuts, while the hydraulic depth control maintains a consistent cutting depth for professional results. Built with durable tungsten carbide teeth and heavy-duty cast rollers, the Pavement Saw is a reliable choice for construction, road maintenance, and utility projects.
Key Features
- Precise Guide Arm: Ensures straight, accurate cuts for professional results
- Hydraulic Depth Control: Maintains consistent depth throughout the cut
- Powerful Planetary Drive: High torque with high flow hydraulics for efficient cutting
- Durable Cast Rollers: Heavy-duty rollers for smooth operation
- Adaptable Design: Compatible with all high-flow skid steer loaders, replacing cumbersome self-propelled saws
- 9” Cutting Depth: Ideal for patches, expansion joints, utility cuts, and traffic loops
- Electro-Hydraulic Side-Shift: Cuts close to walls and fixed objects with 24" side-shift
- Built-In Shroud: Retracts as cutting depth increases, enhancing debris containment
- Tungsten Carbide Teeth: Cuts through asphalt and hard surfaces with ease
- Heavy-Duty Build: Designed to withstand demanding cutting tasks
Detailed Specifications
| Feature | 915PS |
|---|---|
| Minimum Flow Rate | 22 GPM |
| Maximum Flow Rate | 40 GPM |
| Maximum Speed | 180 RPM |
| Minimum Operating Pressure | 2,800 psi |
| Maximum Pressure | 5,500 psi |
| Maximum Power Output | 60 HP |
| Maximum Torque | 5,000 lb-ft |
| Hydraulic Flow Classification | High Flow |
| Number of Teeth | 36 |
| Width of Cut | 1.5" |
| Depth of Cut | 9” |
| Depth Control | Hydraulic |
| Side-Shift Distance | 24" |
| Side-Shift Control | Hydraulic |
| Overall Width | 67" |
| Overall Length | 59" |
| Overall Height | 40" |
| Weight | 1,300 lb |
| Feature | 925PS |
|---|---|
| Minimum Flow Rate | 25 GPM |
| Maximum Flow Rate | 40 GPM |
| Maximum Speed | 180 RPM |
| Minimum Operating Pressure | 2,800 psi |
| Maximum Pressure | 5,500 psi |
| Maximum Power Output | 60 HP |
| Maximum Torque | 5,000 lb-ft |
| Hydraulic Flow Classification | High Flow |
| Number of Teeth | 28 |
| Width of Cut | 2.5" |
| Depth of Cut | 9” |
| Depth Control | Hydraulic |
| Side-Shift Distance | 24" |
| Side-Shift Control | Hydraulic |
| Overall Width | 67" |
| Overall Length | 59" |
| Overall Height | 40" |
| Weight | 1,335 lb |
| Feature | 945PS |
|---|---|
| Minimum Flow Rate | 25 GPM |
| Maximum Flow Rate | 40 GPM |
| Maximum Speed | 180 RPM |
| Minimum Operating Pressure | 3,000 psi |
| Maximum Pressure | 5,500 psi |
| Maximum Power Output | 60 HP |
| Maximum Torque | 5,000 lb-ft |
| Hydraulic Flow Classification | High Flow |
| Number of Teeth | 28 |
| Width of Cut | 4.5" |
| Depth of Cut | 9” |
| Depth Control | Hydraulic |
| Side-Shift Distance | 24" |
| Side-Shift Control | Hydraulic |
| Overall Width | 67" |
| Overall Length | 59" |
| Overall Height | 40" |
| Weight | 1,365 lb |
Mounting Kit Configurations
- ASV/Terex: RC/PT30
- Bobcat: MT-52/55, 463/S70
- Universal Mounting Plate: Suitable for skid steers with high-flow hydraulic capacity
- Compatible Brands: Toro, Vermeer, Boxer, Ditch Witch, Ramrod, Kanga, Cormidi
In Package
- Pavement Saw Attachment (choose 915PS, 925PS, or 945PS model)
- Guide Arm and Electro-Hydraulic Side-Shift System
- Product Manual and Installation Guide
