Erskine Winged Snowblade | Model 108" | Width 160" | 15–25 GPM | 25–40 HP | For Skid Steers & Tractors

Erskine Winged Snowblade | Model 108" | Width 160" | 15–25 GPM | 25–40 HP | For Skid Steers & Tractors

Regular price $13,945.00
Regular price Sale price $13,945.00
Sale Sold out
Machine Compatibility
Customizable
Fast
24/7 Support
  • Moldboard Width: 108" blade expands to 160" coverage.
  • Hydraulic Flow: Operates efficiently with 15–25 GPM skid steers.
  • Tractor Compatibility: Designed for 25–40 HP compact tractors.
  • Blade Weight: Heavy-duty build at approximately 1,500 lbs.
  • Oscillation & Float: ±5° oscillation, 10° up / 5° down float.
View full details

Product Description

Erskine Winged Snowblade | Model 108" | Width 160" | 15–25 GPM | 25–40 HP | For Skid Steers & Tractors

DESCRIPTION

The Erskine Winged Snowblade 108" Model is engineered for high-volume snow removal in large open areas and long push applications. Featuring expandable hydraulic wings, advanced oscillation and float control, and a high-capacity moldboard with spill guard, this blade moves more snow in fewer passes. With universal skid steer and tractor compatibility, operators can switch between pusher, straight blade, and back drag positions for maximum versatility. Built with heavy-duty steel construction, a trip edge system, and adjustable skid shoes, the Winged Snowblade delivers durability, efficiency, and precision in demanding winter conditions. Expand your working width up to 160 inches, track uneven terrain with ±5° oscillation, and enjoy full hydraulic control for independent wing operation. This snowblade is the ultimate solution for professionals who demand powerful performance, reliability, and efficiency in every pass.

Key Features

  • High-volume snow removal Extra-tall moldboard with integrated spill guard carries more snow per pass, reducing total clearing time.
  • Expandable hydraulic wings Extend working width up to 160" for maximum coverage in wide-open areas.
  • Advanced contour tracking ±5° oscillation and 10° up / 5° down float follow uneven terrain for cleaner results.
  • 3-function hydraulic control Independent wing movement and precise moldboard positioning for superior control.
  • Heavy-duty construction Built with high-strength steel and trip edge system to withstand impacts and reduce wear.
  • Universal skid steer compatibility Quick-attach mounting works with all major skid steer and tractor brands.
  • Multiple blade positions Operates as pusher, straight blade, or back drag for versatile snow management.
  • Durable skid shoes Adjustable shoes improve ground contact, extend blade life, and enhance operator control.
  • Efficient snow carrying Spill guard design prevents spillage, allowing larger snow loads per push.
  • Hydraulic wing angling 60° forward / 80° backward wing movement adapts to changing snow conditions.
  • Bolt-on cutting edge Replaceable ½" × 6" edge ensures long-lasting performance and easy maintenance.
  • Optimized for skid steers Operates with 15–25 GPM hydraulic flow for consistent power and efficiency.
  • Tractor-ready performance Compatible with tractors rated at 25–40 HP for flexible use across equipment.
  • Professional-grade design Engineered for municipalities, contractors, and property managers needing reliable snow control.

Detailed Specifications

Specification 108" Model
Part Number 902093
Moldboard Width 108"
Working Width Pusher 137"
Working Width Straight 160"
Working Width Backdrag 120"
Working Width Windrow 96" to 118" (at 30°)
Moldboard Thickness 0.135"
Blade Angle ±30°
Float Range 10° up / 5° down
Wing Angling Hydraulic, 60° forward / 80° backward
Blade Oscillation ±5°
Trip Style Trip edge
Overall Length Pusher 72"
Overall Length Backdrag 52"
Height with Spill Guard 42.75"
Bolt-On Cutting Edge ½" × 6"
Approximate Weight 1,500 lb.
Hydraulic Flow (Skid Steer) 15–25 GPM
Tractor Compatibility 25–40 HP
Options Factory-installed couplers
