Farm King Back-saver Grain Auger | Model 1684 | Size 16" x 84" | PTO Horsepower 150 Hp | For Tractors

Product Description

Farm King Back-saver Grain Auger | Model 1684 | Size 16" x 84" | PTO Horsepower 150 Hp | For Tractors

DESCRIPTION

Meet the Farm King 1684 BackSaver Grain Auger a flagship solution engineered for high-volume grain transfer. With its 16" diameter tube and extended 84-foot reach, this auger is purpose-built for farmers who need to move large quantities of grain efficiently and reliably.

Whether you’re working with corn, soybeans, or wheat, the 1684 BackSaver maximizes throughput while minimizing operator fatigue. Equipped with a scissor lift undercarriage, self-leveling hopper, and heavy-duty PTO compatibility (150 HP required), this auger delivers premium performance with the rugged durability Farm King is known for.

Farmers managing large grain operations, commercial bins, or elevator sites will appreciate the stability in windy conditions, minimal maintenance design, and effortless hydraulic control system that saves time and labor at every turn.

Key Features

• 16" Diameter Tube with 84' Length Designed for high-capacity grain flow, capable of handling large volumes in minimal time.
• Scissor Lift Undercarriage Exclusive Farm King design offers smooth lifting and improved positioning near bins.
• Hydraulic Self-Leveling Hopper Maintains level orientation on uneven terrain, reducing wear and ensuring smooth intake.
• Built Tough with 10 & 11 Gauge Steel Tubing Withstands heavy use and harsh environments.
• 1/4" Flighting on Main & Swing Auger Built to endure high throughput with reduced wear.
• Hydraulic Controls Mounted directly on the auger for effortless positioning and transport transitions.
• Optional Adjustable Lighting Kit Enables safe, effective operation after dark.
• Safety Ball Valve Lever Locks hydraulic lift in place for added operator safety.
• Wide Wheel Track (13'4") Enhances stability during both operation and transport.
• 150 HP PTO Tractor Requirement (1000 RPM) Optimized for high-power tractors, making it ideal for large-scale farms.
• Dual Spool Valve Option Powers both the intake hopper winch and mover with only two remote valves.
• Transport-Friendly Design Transitions to just 13'2" height in transport mode, meeting most road requirements.
• Steel Bridging & Cables Reinforced upper support for steady operation in windy conditions.
• 6-Bolt Hubs & 11L x 15 x 8 Ply Tires Provide durability and easy towing across farm terrain.
• Heavy-Duty Flighting Shaft (3.5" Diameter, 11-Gauge) Delivers smooth grain flow, even with damp crops.
