Farm King | Grader Blades 3PT Hitch | Model C8315 to C10155 | 5' To 10' Width w/ Hydraulic & Manual Tilt | Horsepower 15 To 150 HP | For Tractor
Farm King | Grader Blades 3PT Hitch | Model C8315 to C10155 | 5' To 10' Width w/ Hydraulic & Manual Tilt | Horsepower 15 To 150 HP | For Tractor
Regular price
$855.00
Regular price
Sale price
$855.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Farm King | Grader Blades 3PT Hitch | Model C8315 to C10155 | 5' To 10' Width w/ Hydraulic & Manual Tilt | Horsepower 15 To 150 HP | For Tractor
DESCRIPTION
The Farm King Grader Blade Series spanning models C8315 to C10155 delivers rugged, dependable performance for landowners, farmers, contractors, and municipalities alike. Whether you're maintaining gravel driveways, preparing seedbeds, ditching, leveling fields, or clearing snow, these rear 3-point hitch blades are engineered to handle tough jobs with precision and durability.
With cutting widths from 5 feet to 10 feet, and compatibility with tractors ranging from 15 HP to 150 HP, there's a Farm King grader blade to match your needs and your machine. Choose from manual or hydraulic adjustments for blade angle, tilt, and offset to match the complexity of your tasks. Heavy-duty, high-carbon steel cutting edges, reinforced moldboards, and plug-and-play hydraulics (on select models) make this line a reliable workhorse across a wide range of applications.
From entry-level manual models like the C8315, to advanced hydraulic units like the C10155, Farm King grader blades provide an unbeatable combination of strength, control, and farm-proven performance.
Key Features
- Widths from 5' to 10': Covers all grading and land-leveling needs, from small farms to large acreage.
- Tractor Compatibility from 15 to 150 HP: Matches compact, utility, and full-size tractors.
- Hydraulic & Manual Models: Choose your level of control manual for simplicity, hydraulic for convenience and precision.
- High-Carbon Steel Cutting Edges: 1/2" x 6" reversible blades resist wear for long-lasting sharpness.
- Rear 3-Point Hitch Compatible: Fits Cat. I, II, and III depending on model easy hookup and removal.
- Hydraulic Angle, Tilt & Offset (Select Models): Makes contouring land, crowning roads, and ditching easier and more precise.
- Blade Angle up to 30° Left or Right: Efficiently push material to the side or create slopes and ditches.
- Five-Position Forward & Reverse Angles: Adjustable for diverse grading tasks and terrain types.
- Formed Moldboard Construction: Reinforced steel moldboards provide added strength in rugged conditions.
- Plug-and-Play Hydraulic Hookup (Select Models): Saves setup time and simplifies use with tractors that have rear remotes.
- Corrosion-Resistant Finish: Powder-coated steel resists weathering and wear for long-term use.
- Offset Capability (Select Models): Ideal for working along fences, buildings, or uneven areas.
- Built for Year-Round Use: From winter snow clearing to summer field prep and road maintenance.
- Precision Grading Results: Level, smooth, and shape your land like a pro.
Detailed Specifications
| Specification | C8315 | C8317 |
|---|---|---|
| Blade Width | 5 ft (60") | 6 ft (72") |
| Horsepower Range | 15–30 HP | 15–30 HP |
| Hitch Category | Category I | Category I |
| Hydraulic Adjustments | Manual angle/tilt via 3PT linkage | Manual angle/tilt via 3PT linkage |
| Cutting Edge Material | 1/4" x 3" Mild Steel | 1/4" x 3" Mild Steel |
| Approx. Weight | ~250 lbs | ~275 lbs |
| Working Width | 60" | 72" |
| Special Features | Compact design for smaller tractors | Enhanced width for wider grading |
| Specification | C8800 | C8801 |
|---|---|---|
| Blade Width | 8 ft (96") | 7 ft (84") |
| Horsepower Range | 30–60 HP | 30–60 HP |
| Hitch Category | Cat. II (Cat. I optional) | Cat. II (Cat. I optional) |
| Hydraulic Adjustments | Manual angle, optional hydraulic tilt | Manual angle, optional hydraulic tilt |
| Cutting Edge Material | 1/2" x 6" High-Carbon Steel | 1/2" x 6" High-Carbon Steel |
| Approx. Weight | ~700 lbs | ~650 lbs |
| Working Width | 96" | 84" |
| Special Features | Heavy-duty with optional hydraulic tilt | Mid-size with flexible tilt options |
| Specification | C8082 / F6683 / F6684 | C9082 / F6683 / F6684 / F6685 |
|---|---|---|
| Blade Width | 8 ft (96") | 9 ft (108") |
| Horsepower Range | 80 HP | 80 HP |
| Hitch Category | Category II | Category II |
| Hydraulic Adjustments | Hydraulic tilt & angle | Hydraulic tilt, angle & offset |
| Cutting Edge Material | 1/2" x 6" Reversible Steel | 1/2" x 6" Reversible Steel |
| Approx. Weight | ~1,100 lbs | ~1,150 lbs |
| Working Width | 96" | 108" |
| Special Features | Robust hydraulic control, reversible edge | Offset capability for versatile grading |
| Specification | C9102 / F6692 / F6693 | C10155 / F6692 / F6694 (9') |
|---|---|---|
| Blade Width | 9 ft (108") | 9 ft (108") |
| Horsepower Range | 100 HP | 150 HP |
| Hitch Category | Category II & III | Category II & III |
| Hydraulic Adjustments | Hydraulic tilt & angle | Hydraulic tilt, angle & offset |
| Cutting Edge Material | 1/2" x 6" Reversible Steel | 1/2" x 6" High-Carbon Steel |
| Approx. Weight | 1,145–1,350 lbs | ~1,300 lbs |
| Working Width | 108" | 108" |
| Special Features | Wide tractor compatibility, heavy-duty | Plug & play hydraulic, powerful grading |
| Specification | C10155 / F6692 / F6694 (10') |
|---|---|
| Blade Width | 10 ft (120") |
| Horsepower Range | 150 HP |
| Hitch Category | Category II & III |
| Hydraulic Adjustments | Hydraulic tilt, angle & offset |
| Cutting Edge Material | 1/2" x 6" High-Carbon Steel |
| Approx. Weight | ~1,300 lbs |
| Working Width | 120" |
| Special Features | Extended width for large-scale use |
