Product Description
Farm King Round Bale Carrier | Model 2450 | Horsepower 80 HP | Tires Capacity 4,680 lb | For Tractors
DESCRIPTION
The Farm King 2450 Round Bale Carrier is the ultimate solution for high-efficiency bale handling. Engineered for rugged farm use and powered by an 80 HP tractor, this double-wide round bale carrier lets you load, transport, and unload up to sixteen 4-foot or fourteen 5-foot round bales in a single trip.
Whether you’re clearing fields after baling or stocking up your feedlot, the 2450 is built to save time, reduce wear on your equipment, and lower labor costs. A heavy-duty deck, tandem walking beam axles, and graphite-coated carrier beams make this machine as durable as it is gentle on your bales. Designed with both end-on and side-on pickup options, it gives you complete control, even in uneven terrain.
With intuitive hand-held remote operation and hydraulically powered arms, the Farm King 2450 delivers industry-leading speed, reliability, and minimal bale damage making it a top choice for large-scale hay operations.
Key Features
- High-Capacity Bale Transport: Carries up to 16 bales (4') or 14 bales (5'), reducing trips and fuel use.
- Tractor-Compatible: Operates efficiently with 80 HP tractors, making it ideal for most midsize farm setups.
- Heavy-Duty Construction: Built with tandem walking beam axles and rugged steel framing for long-term use in tough conditions.
- Gentle Bale Handling: Pickup arms and graphite-coated carrier beams reduce bale tearing and spoilage.
- Dual Hydraulic Circuits: Ensures smooth operation of both lift and tilt functions.
- Fast Unloading: Tilt deck with a rear pusher unloads bales in tight, straight rows perfect for storage and wrapping.
- Smart Pusher Modes: Select “high” for dry hay and straw or “low” for silage to optimize torque and speed.
- Hand-Held Remote Control: 12V powered unit offers full control from your tractor seat.
- Rotating Pickup Arm: Features left and right-hand side pickup arms for superior maneuverability.
- Heavy-Duty Tires: Eight 12.5L x 15FI tires with 4,680 lb capacity at 90 PSI for high-load hauling.
- Safe Highway Transport: Designed for intermittent, unloaded highway use at speeds up to 20 mph.
- Versatile Bale Pickup: Pick up bales from end-on or side-on positions ideal for varied field layouts.
- Compact for Transport: Despite its capacity, it offers a transport width of just 12.75'.
- Maintenance Friendly: Simple hydraulic system, accessible components, and minimal daily service needs.
- Boosts Profitability: Cuts bale handling time, reduces labor, and minimizes crop loss.
Detailed Specifications
| Specification | Details |
|---|---|
| Model | 2450 |
| Tractor HP Requirement | 80 HP (60 kW) |
| Bale Capacity | 16 bales (4' wide) / 14 bales (5' wide) |
| GVW (Gross Vehicle Weight) | 37,440 lb (16,983 kg) |
| Max Speed (Loaded) | 20 mph (32 km/h) |
| Remote Control | Hand-held, 12V, 15 amp fuse |
| Hydraulic Requirements | 2 double-acting circuits |
| Lift Cylinders | 2 × 3" diameter |
| Tilt Cylinders | 2 × 3" diameter |
| Hydraulic Motors | 4 × 22.0 cu. in. |
| Tire Size | 12.5L x 15FI, Load Range F (8 tires total) |
| Tire Load Capacity | 4,680 lb (2,130 kg) at 90 PSI |
| Tire Hubs | 6 bolt with twine guard |
| Wheel Type | Heavy-duty implement style |
| Deck Length | 37 ft (11.3 m) |
| Overall Length | 45 ft (13.7 m) |
| Transportation Width | 12.75 ft (3.9 m) |
