Farmer-Helper | Self-Contained Backhoe | Model FH-BH8 & FH-BH9 | Digging Depth 8 & 9 Feet | Horsepower 25 To 45+ HP | Cat-I/II 3-Point Hitch| For Tractors
DESCRIPTION
The Farmer Helper FH-BH8-9 Backhoe is a robust and efficient digging tool, designed for handling large-scale trenching, excavation, and material handling tasks. Featuring a self-contained hydraulic system powered by the tractor’s PTO, this backhoe delivers exceptional digging depth and precision. With a sturdy build and advanced features, it is perfect for farms, landscaping projects, and construction sites.
Built from durable Q-235 structural steel, the FH-BH8-9 Backhoe boasts high-performance hydraulics with a dual filter setup to ensure smooth operation and minimal maintenance. Its oversized stabilizer pads provide excellent stability, while its adjustable digging capabilities make it a versatile choice for varied applications. With bucket options up to 36 inches wide, the FH-BH8-9 is ideal for demanding tasks requiring efficiency and reliability.
Key Features
- Compatible with tractors rated 25 To 45+ HP PTO, ideal for compact and utility models with Category I & II 3-point hitches.
- Offers digging depths of up to 102″, perfect for trenching, drainage, and foundation work.
- Self-contained hydraulic system with dual filters ensures smooth, reliable operation without external hydraulics.
- 4th-point stabilizer bar enhances weight distribution and eliminates the need for sub-frame mounting.
- Hydraulic stabilizer legs controlled by dual joysticks provide secure footing on uneven terrain.
- Bucket rotation of 180° allows flexible digging angles and efficient material handling.
- Built from Q-235 structural steel for long-lasting durability in rugged conditions.
- Dipperstick digging force up to 2,205 lbs and bucket force up to 3,418 lbs for powerful excavation.
- Transport lock secures the boom arm during travel for safer movement between job sites.
- Swing arc of 180° enables wide coverage without repositioning the tractor.
- Operating pressure of 2,466 psi delivers consistent hydraulic performance under load.
- Net weight ranges from 1,360 to 1,450 lbs depending on model and bucket size.
- Optional mechanical thumb adds gripping capability for logs, rocks, and debris.
- Bucket sizes available from 9″ to 36″ for versatility across digging and loading tasks.
- Designed for landowners, farmers, and contractors needing a rugged, PTO-powered backhoe solution.
Detailed Specifications
| Specification | FH-BH8 |
|---|---|
| Digging Depth | 89.7″ (7.47 ft) |
| Tractor PTO Compatibility | 25 To 45+ HP |
| 3-Point Hitch Type | Cat I & II |
| Reach (from swing pivot) | 126″ |
| Loading Height (Bucket @ 60°) | 72.4″ |
| Transport Height | 83.5″ |
| Transport Overhang | 49″ |
| Bucket Rotation | 180° |
| Stabilizer Spread (Down/Up) | 68.7″ / 46.4″ |
| Dipperstick Digging Force | 2,105 lbs |
| Bucket Digging Force | 2,818 lbs |
| Swing Arc | 180° |
| Operating Pressure | 2,466 psi |
| Shipping Weight | 1,450 lbs |
| Net Weight (with 16″ bucket) | 1,360 lbs |
| Specification | FH-BH9 |
|---|---|
| Digging Depth | 102″ (8.5 ft) |
| Tractor PTO Compatibility | 25 To 45+ HP |
| 3-Point Hitch Type | Cat I & II |
| Reach (from swing pivot) | 142″ |
| Loading Height (Bucket @ 60°) | 80.3″ |
| Transport Height | 92.9″ |
| Transport Overhang | 50.4″ |
| Bucket Rotation | 180° |
| Stabilizer Spread (Down/Up) | 68.7″ / 46.4″ |
| Dipperstick Digging Force | 2,205 lbs |
| Bucket Digging Force | 3,418 lbs |
| Swing Arc | 180° |
| Operating Pressure | 2,466 psi |
| Shipping Weight | 1,540 lbs |
| Net Weight (with 16″ bucket) | 1,450 lbs |
