FarmTek ClearSpan HD BeefMaster™ Building System | Controlled Environment For Livestock
Description
The ClearSpan™ HD BeefMaster™ Building System provides a safe, controlled environment designed to maximize cattle health and increase profitability. Featuring a 12.5 oz., 24 mil premium white cover and truss arches made from USA-made, triple-galvanized structural steel, this structure offers durable protection from the elements. The unique feed shield overhang keeps feed dry, reducing waste and saving on labor costs. Additionally, the covered ridge vents improve ventilation by allowing moisture to escape, maintaining optimal air quality for your livestock.
Each HD BeefMaster™ structure comes open-ended but can be fitted with custom end walls. The frame is reinforced with ClearSpan’s Heavy Duty Base Plates and has truss spacing set at 20 feet on center. Designed to reduce animal stress, increase feed efficiency, and provide long-lasting structural integrity, the HD BeefMaster™ System is ideal for creating a productive cattle environment, particularly with ClearSpan's optional Curtain Package, which offers even more climate control.
Key Features
- Controlled Environment: Protects cattle from harsh weather, reducing injuries and increasing gains.
- Feed Shield Overhang: 4' overhang keeps feed dry, reducing waste and protecting feed quality.
- Heavy-Duty Frame: USA-made, triple-galvanized structural steel frame resists corrosion and lasts long.
- Optimized Ventilation: Covered ridge vents enhance air circulation, improving animal health.
- Durable White Cover: 12.5 oz., 24 mil white cover with a 20-year warranty; frame comes with a 50-year warranty.
Detailed Specifications
| Feature | 35'W x 100'L | 35'W x 140'L |
|---|---|---|
| Width | 35'W | 35'W |
| Height | 26'10-3/4" | 26'10-3/4" |
| Length | 100'L | 140'L |
| Weight | 11,483 lbs | 8,500 lbs |
| Feature | 45'W x 100'L | 54'W x 100'L |
|---|---|---|
| Width | 45'W | 54'W |
| Height | 27'11-1/16" | 29'6-7/16" |
| Length | 100'L | 100'L |
| Weight | 12,423 lbs | 14,481 lbs |
| Feature | 65'W x 100'L |
|---|---|
| Width | 65'W |
| Height | 35'4-1/16" |
| Length | 100'L |
| Weight | 9,000 lbs |
| Material Specifications | Detail |
|---|---|
| Frame Material | Triple-galvanized, structural steel |
| Cover Material | 12.5 oz., 24 mil rip-stop poly, white |
| Feed Shield | 4' overhang |
| Truss Spacing | 20' on center |
| Sidewall Height | 10' |
| End Wall Option | Custom walls and Curtain Package |
| Recommended Space Per Head | 40 sq. ft. |
