Product Description
Fieldking | Robust Series Single Speed Rotary Tiller | Model FKDRTSG Series | Widths 4' To 7.5' | Horsepower 35 To 70 HP | For Tractors
DESCRIPTION
The FIELDKING Robust Series Single Speed Rotary Tiller is engineered for farmers, landscapers, and landowners who demand uncompromising performance in the toughest soil conditions. Available in working widths from 4 feet to 7.5 feet, this heavy-duty tiller delivers deep soil aeration and finely pulverized seedbeds for healthier, high-yield crops.
Whether you're revitalizing pastureland, prepping for planting, or working with stubborn clay soils, the Robust Series is your go-to tillage solution. Featuring boron steel blades, a sealed oil-bath gear drive, and a durable single-speed gearbox, this tiller is designed to last season after season with minimal maintenance.
Compatible with a wide range of compact and utility tractors (35–70 HP), the FIELDKING Robust Series transforms raw earth into perfectly prepped ground faster, cleaner, and with less strain on your machine.
Key Features
- Heavy-Duty Single Speed Gearbox – Built to withstand demanding soil conditions and ensure long-term durability.
- Side Gear Drive in Sealed Oil Bath – Maximizes torque while minimizing wear and tear in heavy tillage environments.
- Boron Steel Rotary Tiller Blades – Last up to 50% longer than high-carbon alternatives, reducing downtime and replacement costs.
- Helical Blade Configuration – Reduces load on your tractor, resulting in more efficient tillage and fuel savings.
- Heavy-Duty PTO Shaft with Slip Clutch – Offers critical overload protection to prevent drivetrain damage.
- Adjustable Tilling Depth up to 7 Inches – Perfect for deep soil aeration, seedbed prep, or weed control.
- Available in L, C, and J Blade Options – Choose the perfect configuration for your specific soil type and farming goals.
- Heavy-Duty Spring Plank Assembly – Delivers a perfectly level, smooth, and uniform seedbed finish.
- Sealed Bearings – Keep out mud and moisture, reducing maintenance in wet field conditions.
Detailed Specifications
| Specification | Rotary Tiller FKDRTSG-125 | Rotary Tiller FKDRTSG-150 | Rotary Tiller FKDRTSG-175 |
|---|---|---|---|
| Model | FKDRTSG-125 | FKDRTSG-150 | FKDRTSG-175 |
| Part Number | FKDRTSG-125 | FKDRTSG-150 | FKDRTSG-175 |
| Working Width | 4 ft (1250 mm) | 5 ft (1500 mm) | 5.5 ft (1750 mm) |
| Tractor HP Required | 35–40 HP | 40–45 HP | 45–50 HP |
| Rotary RPM | 540 RPM | 540 RPM | 540 RPM |
| Number of Flanges | 5 | 6 | 7 |
| Number of Blades | 30 | 36 | 42 |
| Blade Configuration | L, C, or J | L, C, or J | L, C, or J |
| Max Tilling Depth | Up to 7 inches | Up to 7 inches | Up to 7 inches |
| Drive Type | Side gear drive (oil bath) | Side gear drive (oil bath) | Side gear drive (oil bath) |
| Gearbox Type | Single-speed gear box | Single-speed gear box | Single-speed gear box |
| PTO Type | Heavy-duty PTO with slip clutch | Heavy-duty PTO with slip clutch | Heavy-duty PTO with slip clutch |
| Blade Material | Boron steel (50% longer life) | Boron steel (50% longer life) | Boron steel (50% longer life) |
| Sealed Bearings | Yes | Yes | Yes |
| Leveling Mechanism | Heavy-duty spring plank assembly | Heavy-duty spring plank assembly | Heavy-duty spring plank assembly |
| Specification | Rotary Tiller FKDRTSG-200 | Rotary Tiller FKDRTSG-225 |
|---|---|---|
| Model | FKDRTSG-200 | FKDRTSG-225 |
| Part Number | FKDRTSG-200 | FKDRTSG-225 |
| Working Width | 6.5 ft (2000 mm) | 7.5 ft (2250 mm) |
| Tractor HP Required | 50–60 HP | 60–70 HP |
| Rotary RPM | 540 RPM | 540 RPM |
| Number of Flanges | 8 | 9 |
| Number of Blades | 48 | 54 |
| Blade Configuration | L, C, or J | L, C, or J |
| Max Tilling Depth | Up to 7 inches | Up to 7 inches |
| Drive Type | Side gear drive (oil bath) | Side gear drive (oil bath) |
| Gearbox Type | Single-speed gear box | Single-speed gear box |
| PTO Type | Heavy-duty PTO with slip clutch | Heavy-duty PTO with slip clutch |
| Blade Material | Boron steel (50% longer life) | Boron steel (50% longer life) |
| Sealed Bearings | Yes | Yes |
| Leveling Mechanism | Heavy-duty spring plank assembly | Heavy-duty spring plank assembly |
