FLIR Systems

FLIR M232 Pan/Tilt 9Hz Marine Thermal Camera [E70354]

FLIR M232 Pan/Tilt 9Hz Marine Thermal Camera [E70354]

Regular price $3,095.00
Regular price $0.00 Sale price $3,095.00
Sale Sold out
Customizable
Fast
24/7 Support
  • Compact & Affordable: FLIR M232 offers accessible thermal night vision for any vessel.
  • Boson Thermal Core: Delivers 320 x 240 resolution for high-quality imaging.
  • Enhanced Navigation Safety: Detects obstacles like docks and buoys day or night.
  • ClearCruise™ Analytics: Integrates with Raymarine Axiom for advanced thermal alerts.
  • IP Video Connectivity: Streamlined installation with minimal cabling, integrates with MFDs.
View full details

Products Description

FLIR M232 Pan/Tilt 9Hz Marine Thermal Camera [E70354]

DESCRIPTION

The FLIR M232 marine thermal camera offers compact, cost-effective thermal night vision, allowing boaters to detect bridges, buoys, docks, and other vessels with 320 x 240 resolution and 2x digital zoom. When paired with a Raymarine Axiom MFD, the M232 brings ClearCruise™ intelligent thermal analytics, delivering alerts for non-water objects to improve situational awareness. Its IP video technology minimizes cable needs, simplifying installation on any vessel. This camera’s small and lightweight design makes it an easy addition to any boat setup.

Key Features

  • Boson Thermal Core: Latest generation thermal imaging technology for sharp, clear visuals with 320 x 240 resolution.
  • 2x Digital Zoom: Provides extended range performance, improving detail at long distances.
  • ClearCruise™ Compatibility: Enhances safety with audible and visual alerts for obstacles like boats and navigation markers.
  • Pan & Tilt Functionality: Offers 360° continuous pan and tilt up to +110°/-90°, providing full, unobstructed views.
  • Easy Installation: Lightweight, compact design with IP video connectivity for quick setup on any vessel.

Detailed Specifications

Category Details
Thermal Sensor FLIR Boson 320 x 240 VOx Microbolometer
Video Refresh Rate 9 Hz
Field of View 24° x 18°
Digital Zoom 2x
Image Processing FLIR Proprietary Digital Detail Enhancement™
Pan/Tilt Range Pan: 360° continuous, Tilt: +110° / -90°
Video Output H.264 IP video stream
Power Requirements 12 or 24 VDC
Power Consumption Typical 15W, Max 18W
Ethernet-Enabled Yes, for integration with other electronics

In Package

  • Camera Unit: Core thermal camera with pan/tilt capability and thermal vision.
  • Top-Down Riser Kit: For secure mounting.
  • Thermal Camera Base-Seal: Ensures watertight installation.
  • Right-Angled RayNet-to-RayNet Cable: 32 ft (10 m) for seamless network connection.
  • RayNet to RJ45 Adapter Cable: 4 in. (100 mm) adapter for flexible connectivity.
  • Right-Angled 3-Pin Power Cable: 32 ft (10 m) for reliable power supply.
  • Stainless Steel Mounting Hardware Kit: Includes screws, nuts, and washers for secure installation.

Manuals & Documents

Owner's Manual (pdf)
