Teledyne FLIR Vue TZ20 Dual Thermal Camera
Teledyne FLIR Vue TZ20 Dual Thermal Camera
Regular price
$5,500.00
Regular price
Sale price
$5,500.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
Teledyne FLIR Vue TZ20 Dual Thermal Camera
DESCRIPTION
The FLIR Vue® TZ20 is a powerful, plug-and-play thermal imaging payload built to enhance mission success for public safety and industrial inspection professionals. Fully compatible with DJI Matrice 200 V2 series and Matrice 300 drones via Skyport 2.0, the TZ20 integrates dual FLIR Boson® thermal cameras with up to 20x zoom, delivering unmatched flexibility between wide-area scanning and focused inspections.
Equipped with both wide (95° HFOV) and narrow (18° HFOV) lenses, the TZ20 gives pilots the tools to survey large areas quickly or zero in on specific targets with precision. With real-time infrared video streaming at 30 Hz, MSX-level detail, and TIFF/MPEG recording, this camera is ideal for tactical response, search and rescue, utility inspection, and more.
Key Features
- Dual FLIR Boson® Thermal Sensors: Two factory-calibrated 640 × 512 LWIR sensors provide crisp, high-resolution thermal imaging.
- 20x Thermal Zoom: Switch from 95° wide field of view to 4.5° narrow view with 5x optical and 4x digital zoom.
- Plug-and-Play DJI Compatibility: Integrated with Skyport 2.0, the TZ20 mounts seamlessly on DJI Matrice 200 V2 and M300 drones.
- Mission-Ready Out of the Box: Quick deployment with no additional setup required—ideal for rapid response scenarios.
- Multiple Recording Modes: Supports still image (TIFF), video (MPEG), and multipage TIFF capture in both wide and narrow fields of view.
- Rugged Environmental Performance: Rated IP44 for protection against dust and water splashes; tested for extreme temperatures and EMI.
Detailed Specifications
| Category | Specification |
|---|---|
| General | |
| Payload Dimensions | 75 × 70 × 55 mm |
| Dimensions with Gimbal | 128 × 154 × 141 mm |
| Weight | 640 g |
| Zoom | 5x Optical (WFOV/NFOV), 4x Digital (Effective Zoom: 1x to 20x) |
| Environmental Rating | IP44 |
| Imaging & Optics | |
| Thermal Sensors | Dual FLIR Boson® – 640 × 512 LWIR |
| Pixel Pitch | 12 µm |
| Thermal Sensitivity (NETD) | ≤ 85 mK @ F/1.0 |
| Frame Rate | 640 × 512 @ 25 Hz streaming |
| Optics | Wide: 95° HFOV, 4.9 mm EFLNarrow: 18° HFOV, 24 mm EFL |
| Still Image Capture | TIFF (single or multipage) |
| Video Capture | MPEG (same as streaming output) |
| Power & Electrical | |
| Power Input | 13.6 V / 4 A via Skyport 2.0 |
| Electrical Interface | Skyport 2.0 |
| Mechanical & Interface | |
| Mounting System | DJI Skyport V2.0 (plug-and-play) |
| Storage | Dual microSD card slots |
| Environmental | |
| Operating Temperature | -20°C to 45°C (-4°F to 113°F) |
| Storage/Tested EMI Temperature | -20°C to 60°C (-4°F to 140°F) |
| Ground Control Integration | DJI Pilot App |
| Drone Compatibility | DJI Matrice 200 V2 series, DJI Matrice 300 |
| Recording Formats | Still: TIFFVideo: MPEGMultipage TIFF: Wide & Narrow FOV |
