GKB Machines Combislit | Model CL160 & CL200 | Width 63" (160 cm) & 79" (200 cm) | 3‑point Cat I–II | 30–60 HP | For Tractor
DESCRIPTION
The GKB Combislit brings leveling, damage repair, and top-layer aeration together in one robust, easy‑running unit. As the successor to the Topair, it’s engineered with a heavier, stiffer frame and simplified adjustments to meet today’s field standards while protecting surface flatness on natural and hybrid turf. Evolvente blades open the profile with minimal prying, relieving compaction and improving oxygen exchange without rippling or heave. For versatility, you can mount cutting discs for weed control and additional surface aeration, and add a finishing pressure roller to consolidate after the pass. An integrated ballast tray on top lets you fine‑tune downforce for variable conditions. The platform also shares interfaces with the Combiseeder, allowing quick transfer of the seeder shaft for faster, shallower aeration when schedules are tight.
Key Features
- Multi‑task turf care – Levels, repairs play damage, and aerates the top layer in one pass, reducing downtime between games or events.
- Dual‑model versatility – Available in 63″ (CL160) and 79″ (CL200) working widths to match field size and tractor capacity.
- Heavy‑duty frame – Rigid, reinforced structure for consistent depth control and reliable operation on natural or hybrid turf.
- Adjustable downforce – Integrated top ballast tray for adding weight when extra penetration is needed in compacted areas.
- Low‑disturbance aeration – Evolvente® blades cut clean slits up to 16 cm deep without prying, keeping surfaces smooth and playable.
- Customizable tooling – Optional cutting discs for weed control and supplemental aeration; pressure roller for a finished, firm surface.
- Interchangeable components – Shares shaft system with the GKB Combiseeder for quick swap to a shallow‑aeration setup.
- Operator‑paced performance – Depth and travel speed adapt to seasonal needs, soil type, and surface sensitivity.
- Tractor‑friendly – Standard 3‑point Cat I–II hitch and 30–60 hp requirement fit a wide range of compact and utility tractors.
- Sustainable maintenance – Improves oxygen flow, root health, and field longevity while reducing the number of machine passes.
Detailed Specifications
Model CL160
Specification |
Detail |
---|---|
Working Width |
160 cm / 63″ |
Working Depth |
0–16 cm / 0–6.3″ |
Operating Speed |
0–5 mph |
Power Requirement |
30–40 hp |
Dimensions (L × W × H) |
112 × 186 × 95 cm |
Dimensions (L × W × H in inches) |
44 × 73 × 37″ |
Weight |
345 kg / 760 lbs |
Linkage |
Standard three‑point Cat I–II |
Blade Type |
Evolvente® blades (low‑pry design) |
Optional Attachments |
Cutting discs for weed control, pressure roller for finish quality |
Ballast Tray |
Yes – top‑mounted for adjustable downforce |
Typical Application |
Aeration and surface repair on natural and hybrid turf |
Model CL200
Specification |
Detail |
---|---|
Working Width |
200 cm / 79″ |
Working Depth |
0–16 cm / 0–6.3″ |
Operating Speed |
0–5 mph |
Power Requirement |
40–60 hp |
Dimensions (L × W × H) |
112 × 228 × 95 cm |
Dimensions (L × W × H in inches) |
44 × 90 × 37″ |
Weight |
395 kg / 870 lbs |
Linkage |
Standard three‑point Cat I–II |
Blade Type |
Evolvente® blades (low‑pry design) |
Optional Attachments |
Cutting discs for weed control, pressure roller for finish quality |
Ballast Tray |
Yes – top‑mounted for adjustable downforce |
Typical Application |
Aeration and surface repair on natural and hybrid turf |
