Product Description
Heavy Duty Ramps Modular Mini Yard Ramp System | Model 15-84-184-06-MYR | 84" W x 15' 4" L | 25,000 lb. Capacity | Horsepower 23 HP | For Box Trucks & Dock Loading
DESCRIPTION
Transform your loading and unloading operations with the Heavy Duty Ramps 84" Aluminum Portable Modular Mini Yard Ramp System engineered for efficiency, portability, and safety. Perfect for warehouses, small businesses, construction sites, and facilities without a permanent loading dock, this ramp system makes moving forklifts, pallet jacks, and heavy equipment seamless.
Crafted from premium USA-made aluminum, the modular design ensures lightweight portability without sacrificing strength. The EZ Traction punch plate surface keeps wheels secure in all weather conditions, giving operators peace of mind while handling up to 25,000 lbs. of equipment and cargo. Adjustable ramp stands accommodate truck and dock heights from 15" to 32", while the modular system packs down to fit in a pickup truck bed or 4×8 trailer for easy transport.
Set up takes less than 15 minutes with just two people no tools required. Whether you need a temporary solution for seasonal work or a permanent addition for daily operations, this modular mini yard ramp system delivers unmatched versatility, convenience, and durability.
Key Features
- 25,000 lb. Load Capacity: Safely transport forklifts, pallet jacks, and heavy equipment without overloading.
- Made in the USA: High-quality aluminum construction ensures durability, corrosion resistance, and long service life.
- EZ Traction Punch Plate Surface: Provides superior grip in rain, snow, or mud to prevent slipping.
- Portable & Modular Design: Ramps break down for easy single-pallet transport and storage.
- Quick 15-Minute Setup: Two people can assemble the full system without tools.
- Adjustable Height Stands: Ramp height can be fine-tuned from 15" to 32" to match trucks, trailers, or docks.
- Multiple Configurations: Available in 8' and 15' 4" lengths for flexible loading options.
- Integrated Safety Rails: 4" high rails provide added support and prevent accidents.
- Smooth Transition Plate & Knife Foot: Ensures safe vehicle and equipment entry/exit.
- Compact Transport: Entire system fits on a single pallet for easy shipping and handling.
- Lightweight Design: Total weight 834 lbs., ideal for transport and repositioning by two people.
- Heavy Equipment Ready: Engineered for industrial use, supporting forklifts, skid steers, and other equipment.
- No Tools Required: Simplifies deployment in fast-paced operational environments.
- Patent-Pending Modular System: Innovative design allows stacking and easy storage between uses.
- Weather-Resistant: Aluminum construction resists rust and environmental wear for long-term outdoor use.
Detailed Specifications
| Feature | Specification |
|---|---|
| Brand | Heavy Duty Ramps |
| Model | 84" Aluminum Portable Modular Mini Yard Ramp |
| Item Number | 15-84-184-06-MYR |
| Ramp Length | 15' 4" |
| Ramp Width | 84" |
| Usable Width | 6' 10" |
| Minimum Height | 15" |
| Maximum Height | 32" |
| Weight | 834 lbs. |
| Maximum Capacity | 25,000 lb. total |
| Material | Aluminum |
| Lift Type | Adjustable Height Stands |
| Guard Rail Height | 4" |
| Setup Time | 15 minutes |
| People Required for Setup | 2 |
| Weather Resistance | All-weather traction with punch plate surface |
