HLA Attachment Silage Blade for Articulated Tractors Less Undermount | 10'-18' Width | For Tractor
HLA Attachment Silage Blade for Articulated Tractors Less Undermount | 10'-18' Width | For Tractor
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
HLA Attachment Silage Blade for Articulated Tractors Less Undermount | 10'-18' Width | For Tractor
DESCRIPTION
The HLA Silage Blade for Articulated Tractors is engineered for efficient, high-capacity silage handling, designed to work seamlessly with front-wheel assist and articulated tractors. With blade sizes available from 10 to 18 feet, this silage blade is perfect for large-scale silage, snow, and debris management. Each blade is constructed from heavy-duty materials with two 3"x16" angle cylinders, offering both durability and excellent maneuverability. Featuring hydraulic angle and tilt functions, a high moldboard, and reversible cutting edge, this silage blade delivers reliability and flexibility across diverse agricultural tasks. An undermount kit is required for proper installation, with options tailored to various tractor models.
The HLA Silage Blade f/Articulated Tractors is a rugged angle blade designed for moving large volumes of silage. Hydraulic angle and tilt are standard. Selection of a custom fitted tractor undermount kit is required for a complete unit.
Key Features
- Mount Selection Required – Mounting kit options available to fit a wide variety of tractors.
- Heavy-Duty Construction – Equipped with two 3" x 16" angle cylinders and a robust moldboard for lasting durability.
- Adjustable Blade Features – Hydraulic angle and tilt with high moldboard for increased piling height and stability.
- Reversible Cutting Edge – Extends the blade's lifespan, maximizing value.
- Versatile Size Options – Available in 10 ft (2170 lbs), 12 ft (2535 lbs), 14 ft (2765 lbs), 16 ft, and 18 ft widths to match specific needs.
- UNDERMOUNT SELECTION IS REQUIRED - see options
- Hydraulic angle and tilt are standard.
- Radial lift design to increase ground clearance.
- Blade oscillates
- High moldboard for piling snow.
- Undermount kit tucks in close to frame for permanent mounting.
- Undermount has forward mounted hydraulic connectors for ease of connection.
Detailed Specifications
10 Ft Silage Blade & 12 Ft Silage Blade Model
| Specification | 10 Ft Silage Blade | 12 Ft Silage Blade |
|---|---|---|
| Blade Width | 10 ft | 12 ft |
| Weight | Approx. 2170 lbs | Approx. 2535 lbs |
| Overall Blade Height | 58" (Moldboard 34", Mesh Guard 24") | 58" (Moldboard 34", Mesh Guard 24") |
| Cylinder Size | Two 3"x16" angle cylinders | Two 3"x16" angle cylinders |
| Cutting Edge | Reversible | Reversible |
| Hydraulic Requirements | Standard with hoses and connectors | Standard with hoses and connectors |
| Mount Compatibility | Mount selection required | Mount selection required |
14 Ft Silage Blade, 16 Ft Silage Blade & 18 Ft Silage Blade
| Specs | 14 Ft Silage Blade | 16 Ft Silage Blade | 18 Ft Silage Blade |
|---|---|---|---|
|
Blade Width |
14 ft | 16 ft | 18 ft |
| Weight | Approx. 2765 lbs | Contact for Details | Contact for Details |
|
Overall Blade Height |
58" (Moldboard 34", Mesh Guard 24") |
58" (Moldboard 34", Mesh Guard 24") |
58" (Moldboard 34", Mesh Guard 24") |
|
Cylinder Size |
Two 3"x16" angle cylinders | Two 3"x16" angle cylinders | Two 3"x16" angle cylinders |
|
Cutting Edge |
Reversible | Reversible | Reversible |
|
Hydraulic Requirements |
Standard with hoses and connectors |
Standard with hoses and connectors |
Standard with hoses and connectors |
|
Mount Compatibility |
Mount selection required | Mount selection required | Mount selection required |
