HLA Attachments

HLA Attachment Snow Wing Plow Less Frame | Model 4205 Series | 8'-14' Multiple Width | 80-150 HP | For Tractor

HLA Attachment Snow Wing Plow Less Frame | Model 4205 Series | 8'-14' Multiple Width | 80-150 HP | For Tractor

$22,991.00
$22,991.00
Sale Sold out
Customizable
Fast
24/7 Support
  • Ideal for Tractors & Loaders (80–150 HP) with a max operating weight of 25,000 lbs
  • Adjustable Width: From 8 ft. to 14 ft. closed, extending up to 24 ft. open for versatile snow clearing.
  • Independent Wing Control: Wings operate independently from 0 to 180 degrees.
  • Heavy-Duty Construction: 34" high moldboard with a 36" high wing and reversible spring trip cutting edge.
  • Versatile Angling: Two hydraulic cylinders allow 35 degrees left or right with cross-over relief protection and lateral float.
View full details

Product Description

HLA Attachment Snow Wing Plow Less Frame | Model 4205 Series | 8'-14' Multiple Width | 80-150 HP | For Tractor

DESCRIPTION

The HLA 4205 Series Snow Wing Plow is built to tackle tough winter conditions with unmatched flexibility and efficiency. Whether you're maintaining municipal roads, clearing commercial lots, or managing large properties, this snow plow delivers industry-grade performance you can trust.

Designed with a high moldboard, independent 180° wing control, and dual hydraulic cylinders, the 4205 gives operators full control in snow management. Available in both Standard and Edge Flex configurations, this plow adapts to uneven surfaces, curbs, and contours while maintaining clean passes.

Built for 80–150 horsepower machines and up to 25,000 lbs of operating weight, the 4205 Snow Wing is a rugged, reliable solution engineered for demanding jobs and long winters.

Key Features

  • Independent Wing Control (0–180°) for maximum maneuverability and snow placement
  • Dual Hydraulic Cylinders with 35° angling for left/right adjustments
  • Reversible Spring Trip Cutting Edge for added safety against obstacles
  • Double Electric Selector Valve included for streamlined hydraulic management
  • High Moldboard (34") and Wing Height (36") ensures effective snow capture and throwing
  • Edge Flex Option allows individual cutting edge segments to contour over uneven ground
  • Ideal for Tractors & Loaders (80–150 HP) with a max operating weight of 25,000 lbs
  • Multiple Width Options from 8'/18' to 14'/26' for different snow clearing needs
  • Heavy-Duty Construction ensures long-lasting durability under extreme use
  • Compatible Hose & Mounting Kits available for easy integration with your equipment

Detailed Specifications

HLA 4205 Snow Wing Plow — Standard Series

Model 8'/18' (SB4205W818LF) 10'/20' (SB4205W1020LF)
Closed Width 8 ft 10 ft
Open Width 18 ft 20 ft
Moldboard Height 34 in 34 in
Wing Height 36 in 36 in
Wing Rotation 0–180° Independent 0–180° Independent
Hydraulic Angling 35° Left/Right 35° Left/Right
Electric Selector Valve Included Included
Cutting Edge Type Reversible Spring Trip Reversible Spring Trip
Tractor HP Range 80–150 HP 80–150 HP
Max Operating Weight 25,000 lbs 25,000 lbs
Approximate Weight 3020 lbs 3280 lbs


Model 12'/22' (SB4205W1222LF) 14'/24' (SB4205W1424LF)
Closed Width 12 ft 14 ft
Open Width 22 ft 24 ft
Moldboard Height 34 in 34 in
Wing Height 36 in 36 in
Wing Rotation 0–180° Independent 0–180° Independent
Hydraulic Angling 35° Left/Right 35° Left/Right
Electric Selector Valve Included Included
Cutting Edge Type Reversible Spring Trip Reversible Spring Trip
Tractor HP Range 80–150 HP 80–150 HP
Max Operating Weight 25,000 lbs 25,000 lbs
Approximate Weight 3475 lbs 3765 lbs



HLA 4205 Snow Wing Plow — Edge Flex Series

Model 8'/18' (SB4205WEF818LF) 10'/20' (SB4205WEF1020LF)
Closed Width 8 ft 10 ft
Open Width 18 ft 20 ft
Moldboard Height 34 in 34 in
Wing Height 36 in 36 in
Wing Rotation 0–180° Independent 0–180° Independent
Hydraulic Angling 35° Left/Right 35° Left/Right
Electric Selector Valve Included Included
Cutting Edge Type Edge Flex Segment Trip Edge Flex Segment Trip
Tractor HP Range 80–150 HP 80–150 HP
Max Operating Weight 25,000 lbs 25,000 lbs
Approximate Weight 2920 lbs 3180 lbs



Model 12'/22' (SB4205WEF1222LF) 14'/24' (SB4205WEF1424LF)
Closed Width 12 ft 14 ft
Open Width 22 ft 24 ft
Moldboard Height 34 in 34 in
Wing Height 36 in 36 in
Wing Rotation 0–180° Independent 0–180° Independent
Hydraulic Angling 35° Left/Right 35° Left/Right
Electric Selector Valve Included Included
Cutting Edge Type Edge Flex Segment Trip Edge Flex Segment Trip
Tractor HP Range 80–150 HP 80–150 HP
Max Operating Weight 25,000 lbs 25,000 lbs
Approximate Weight 3375 lbs 3665 lbs



Manuals & Documents

LOADER MOUNTS

HLA EDGE FLEX BROCHURE

HLA SNOW BROCHURE
