HLA Attachment Snow Wing (Edge Flex) Less Frame/Mount | Model 6205 Series | 10'-20' Multiple Width | 150-250 HP | For Tractor
HLA Attachment Snow Wing (Edge Flex) Less Frame/Mount | Model 6205 Series | 10'-20' Multiple Width | 150-250 HP | For Tractor
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
HLA Attachment Snow Wing (Edge Flex) Less Frame/Mount | Model 6205 Series | 10'-20' Multiple Width | For Tractor
DESCRIPTION
When you need uncompromising snow removal power, the HLA 6205 Series Snow Wing is the ultimate solution. Designed for heavy-duty operations, this snow wing attachment utilizes Edge Flex Technology to offer unparalleled versatility, efficiency, and durability in snow clearing. With a range of models, including widths from 10' to 30', you can select the perfect configuration for your operation.
These snow wings are perfect for clearing large commercial properties, highways, parking lots, and municipal roads. The independent wing operation allows you to adjust the wings from 0° to 180°, providing complete control over your snow clearing process, whether you're working in tight spaces or covering wide areas.
With a 53" high moldboard, reversible spring trip cutting edges, and 60" deep/wide wings, the 6205 Series Snow Wing is built for heavy-duty performance. Rated for loaders up to 60,000 lbs, this attachment is as durable as it is flexible, built to withstand the toughest winter conditions and provide long-lasting reliability.
Whether you're operating in a high-demand commercial environment or a municipal setting, the HLA 6205 Series Snow Wing is your go-to tool for effective, efficient, and durable snow removal.
Key Features
- Edge Flex Technology: Wings operate independently from 0° to 180° for maximum flexibility, allowing for precise snow clearing in both narrow and wide areas.
- Adjustable Widths: Models range from 10' to 30', enabling you to select the perfect configuration for your project, whether you need a compact setup or wide coverage.
- Durable Construction: The 53" high moldboard ensures efficient snow clearing, while the 60" deep/wide wings enhance performance in heavy snow conditions.
- Reversible Spring Trip Cutting Edges: Designed for superior performance and longevity, the cutting edges are reversible, offering extended usability.
- Heavy-Duty Design: Built for use with loaders weighing up to 60,000 lbs, ensuring strength and stability during demanding operations.
- Crossover Relief Valve: Equipped with nitrate rods on angle cylinders and a crossover relief valve to prevent damage while maintaining peak operational performance.
- Commercial-Grade Durability: With a 2-year commercial warranty, the 6205 Series Snow Wing offers reliability in even the toughest conditions.
- Flexible Mounting Options: The snow wing comes without a frame or mount, allowing for a customized setup depending on your loader and operation.
Detailed Specifications
| Specification | Model SB6205WEF1020LF | Model SB6205WEF1222LF | Model SB6205WEF1424LF |
|---|---|---|---|
| Width (Closed/Open) | 10' / 20' | 12' / 22' | 14' / 24' |
| Wing Flexibility | 0° to 180° | 0° to 180° | 0° to 180° |
| Moldboard Height | 53" | 53" | 53" |
| Wing Depth/Width | 60" deep/wide | 60" deep/wide | 60" deep/wide |
| Loader Compatibility | Up to 60,000 lbs | Up to 60,000 lbs | Up to 60,000 lbs |
| Weight | Approx. 4335 lbs | Approx. 4660 lbs | Approx. 4930 lbs |
| Crossover Relief Valve | Yes | Yes | Yes |
| Spring Trip Cutting Edge | Reversible | Reversible | Reversible |
| Hydraulic Cylinders | Nitrate rods on angle cyl. | Nitrate rods on angle cyl. | Nitrate rods on angle cyl. |
| Maximum Operating Weight | 60,000 lbs | 60,000 lbs | 60,000 lbs |
| Specification | Model SB6205WEF1626LF | Model SB6205WEF1828LF | Model SB6205WEF2030LF |
|---|---|---|---|
| Width (Closed/Open) | 16' / 26' | 18' / 28' | 20' / 30' |
| Wing Flexibility | 0° to 180° | 0° to 180° | 0° to 180° |
| Moldboard Height | 53" | 53" | 53" |
| Wing Depth/Width | 60" deep/wide | 60" deep/wide | 60" deep/wide |
| Loader Compatibility | Up to 60,000 lbs | Up to 60,000 lbs | Up to 60,000 lbs |
| Weight | Approx. 5385 lbs | Approx. 5755 lbs | Approx. 6120 lbs |
| Crossover Relief Valve | Yes | Yes | Yes |
| Spring Trip Cutting Edge | Reversible | Reversible | Reversible |
| Hydraulic Cylinders | Nitrate rods on angle cyl. | Nitrate rods on angle cyl. | Nitrate rods on angle cyl. |
| Maximum Operating Weight | 60,000 lbs | 60,000 lbs | 60,000 lbs |
