HLA Attachments

HLA Attachments 3500 Series Snow Pusher W/ Wings | Clearing Width With Wings 11' To 15' Ft | Wing Depth 30" inches | For Tractors

HLA Attachments 3500 Series Snow Pusher W/ Wings | Clearing Width With Wings 11' To 15' Ft | Wing Depth 30" inches | For Tractors

Regular price $10,759.00
Regular price Sale price $10,759.00
Sale Sold out
Machine Compatibility
Customizable
Fast
24/7 Support
  • Hydraulic Flexibility: Equipped with individually controlled hydraulic rotary actuators, allowing wing end plates to pivot up to 180 degrees for enhanced maneuverability.
  • High-Capacity Clearing: Maximum clearing width of 15 ft. with a 30" moldboard height, designed to handle substantial snow volumes.
  • Reliable & Durable: Reversible cutting edge with spring trip protection and adjustable skid shoes for adaptable use and increased longevity.
  • Heavy-Duty Build: Suitable for up to 10,000 lbs maximum operating weight, ensuring compatibility with larger tractor models.
  • Enhanced Warranty: Backed by a 2-year commercial warranty for peace of mind and reliable, long-term performance.
View full details

Product Description

HLA Attachments 3500 Series Snow Pusher W/ Wings | Clearing Width With Wings 11' To 15' Ft | Wing Depth 30" inches | For Tractors

DESCRIPTION

The HLA Attachments 3500 Series Snow Pusher with Edge Flex technology is built for tough winter tasks. Engineered to clear expansive areas, this snow pusher offers a clearing width of up to 15 feet, making it ideal for commercial, agricultural, and large residential use. Its innovative design includes individually controlled hydraulic rotary actuators, which allow the wing end plates to pivot independently up to 180 degrees, adapting to diverse snow-clearing scenarios. The pusher also features a reversible cutting edge with spring trip protection, adjustable skid shoes, and lateral blade float, ensuring effective snow management on uneven surfaces. Designed to withstand heavy use, it supports a maximum operating weight of 10,000 lbs, offering rugged dependability and long-lasting performance.

Key Features

  • Adaptable Clearing Widths: Available in various sizes, with wings extending the clearing width from 6 ft. to 15 ft. depending on the model, making it suitable for a range of snow removal needs.
  • Efficient Moldboard Height: Standing at 30 inches, it ensures effective snow containment and efficient clearing.
  • Versatile Wing Depth: With a 30-inch depth, the wings provide excellent capacity for managing heavy snowfall.
  • Durable Cutting Edge: Features a reversible cutting edge with spring trip protection to safeguard against obstacles and ensure longevity.
  • Adjustable Skid Shoes: Customizable skid shoes for enhanced versatility across different terrains and conditions.
  • Hydraulic Rotary Actuators: Individually controlled hydraulic actuators allow the wing end plates to pivot up to 180 degrees, offering adaptability and efficient snow clearing.
  • Lateral Blade Float: Ensures better contact with uneven surfaces, enhancing the efficiency of snow removal.
  • Heavy-Duty Build: Supports a maximum operating weight of 10,000 lbs, offering rugged dependability and long-lasting performance.
  • Crossover Relief Valve Protection: Provides additional protection for hydraulic components, ensuring reliable operation.

Detailed Specifications

Specification SP3530W611LF SP3530W712LF SP3530W813LF
Model Number SP3530W611LF SP3530W712LF SP3530W813LF
Base Width 6 ft. 7 ft. 8 ft.
Maximum Clearing Width 11 ft. 12 ft. 13 ft.
Moldboard Height 30 in. 30 in. 30 in.
Wing Depth (each side) 30 in. 30 in. 30 in.
Wing Operation Hydraulic Rotary Actuators (180° pivot) Hydraulic Rotary Actuators (180° pivot) Hydraulic Rotary Actuators (180° pivot)
Cutting Edge Type Reversible, Spring Trip Reversible, Spring Trip Reversible, Spring Trip
Blade Float Feature Yes — Lateral with Relief Valve Yes — Lateral with Relief Valve Yes — Lateral with Relief Valve
Skid Shoes Adjustable (standard) Adjustable (standard) Adjustable (standard)
Weight (Approx.) 1,275 lbs 1,345 lbs 1,405 lbs
Maximum Operating Weight 10,000 lbs 10,000 lbs 10,000 lbs
Hydraulic Requirements Flat Face Couplers (HK90 Kit Compatible) Flat Face Couplers (HK90 Kit Compatible) Flat Face Couplers (HK90 Kit Compatible)
Frame/Mount Compatibility Required, Sold Separately Required, Sold Separately Required, Sold Separately
Ideal For Compact Loaders & Tight Areas Small to Medium Commercial Lots Medium Sites & Roads



Specification SP3530W914LF SP3530W1015LF
Model Number SP3530W914LF SP3530W1015LF
Base Width 9 ft. 10 ft.
Maximum Clearing Width 14 ft. 15 ft.
Moldboard Height 30 in. 30 in.
Wing Depth (each side) 30 in. 30 in.
Wing Operation Hydraulic Rotary Actuators (180° pivot) Hydraulic Rotary Actuators (180° pivot)
Cutting Edge Type Reversible, Spring Trip Reversible, Spring Trip
Blade Float Feature Yes — Lateral with Relief Valve Yes — Lateral with Relief Valve
Skid Shoes Adjustable (standard) Adjustable (standard)
Weight (Approx.) 1,465 lbs 1,535 lbs
Maximum Operating Weight 10,000 lbs 10,000 lbs
Hydraulic Requirements Flat Face Couplers (HK90 Kit Compatible) Flat Face Couplers (HK90 Kit Compatible)
Frame/Mount Compatibility Required, Sold Separately Required, Sold Separately
Ideal For Large Commercial Lots Industrial & Municipal Use



Manuals & Documents

HLA WARRANTY

LOADER MOUNTS

HLA EDGE FLEX BROCHURE

General Warranty Info:

  • Ripping It Outdoors works closely with our manufacturers to supply and support your products warranty needs as best as possible!
  • The majority of products come with a manufacturer represented warranty against manufacturing defects for at least a 12 month period after the date of sale.
  • Expendable components and "wear parts" including but not limited to blades, knives, teeth, oil, chain sprockets, skid shoes, knife mounting discs, and similar components are usually excluded from manufacturer warranties.
  • Please reach out to us for any specific warranty information neededabout products and parts you can’t find!
