HLA Attachments

HLA Attachments 3600 Series Six-Way Blade | Width 54" to 84" Inches | Mouldboard Height 30" inches | For Tractor

HLA Attachments 3600 Series Six-Way Blade | Width 54" to 84" Inches | Mouldboard Height 30" inches | For Tractor

Regular price $6,201.00
Regular price Sale price $6,201.00
Sale Sold out
Customizable
Fast
24/7 Support
  • Versatile Sizing Options: Available in sizes from 54" to 144", suitable for various applications from sidewalks to large roadways.
  • 6-Way Hydraulic Control: Easily adjusts up to 35° left or right, with V-forward and rear settings for optimal snow management.
  • Heavy-Duty AR400 Steel Cutting Edge: Reversible, durable, and equipped with spring trip protection.
  • Lateral Float and Skid Shoes: Ensures even ground contact with adjustable height skid shoes for improved surface protection.
  • Wide Range of Mounting Options: Compatible with various loader models; mounting kits sold separately.
  • Maximum Weight Capacity: Supports up to 25,000 lbs for larger sizes, ensuring robust snow-clearing performance.
View full details

Product Description

HLA Attachments 3600 Series Six-Way Blade | Width 54" to 84" Inches | Mouldboard Height 30" inches | For Tractor



DESCRIPTION

Engineered for precision and durability, the Stout SB3600V Series 6-Way Snow Blades deliver professional-grade snow removal for skid steers and compact loaders. Available in versatile widths ranging from 54" to 84", these blades feature full hydraulic control for angling up to 35 degrees left or right, plus V forward or rear positions giving you unmatched flexibility in tough winter conditions. The 30-inch high moldboard with lateral float adapts to uneven terrain while the reversible AR400 steel cutting edge with spring trip ensures long-lasting wear resistance and safety. Ideal for sidewalks, small roads, parking lots, and commercial sites, these snow blades provide reliable and efficient snow clearing performance in any setting.

Key Features

  • 6-Way Hydraulic Control Tilt, angle, lift, and V-position capabilities for versatile snow management.
  • Durable AR400 Steel Cutting Edge Reversible with spring trip to protect against impact and extend service life.
  • High Moldboard Design 30" tall blade height with lateral float for smooth operation over uneven surfaces.
  • Skid Shoes Included Protects moldboard and maintains blade height on rough terrain.
  • Universal Mount Compatibility Mounts sold separately to fit a wide range of skid steer and compact loader models.
  • Robust Build Engineered for up to 10,000 lbs operating weight for heavy-duty use.
  • Hydraulic Selector & Relief Valves Included for system safety and precise blade control.

Detailed Specifications

Specification SB3600V54 SB3600V60 SB3600V66
Part Number SB3600V54 SB3600V60 SB3600V66
Blade Width 54" 60" 66"
Moldboard Height 30" 30" 30"
Approximate Weight 695 lbs 720 lbs 740 lbs
Max Operating Weight 10,000 lbs 10,000 lbs 10,000 lbs
Hydraulic Control 6-Way (35° Angling, V-Position) 6-Way (35° Angling, V-Position) 6-Way (35° Angling, V-Position)
Cutting Edge Reversible AR400 Steel with Spring Trip Reversible AR400 Steel with Spring Trip Reversible AR400 Steel with Spring Trip
Skid Shoes Included Included Included
Mount Compatibility Mount Sold Separately Mount Sold Separately Mount Sold Separately



Specification SB3600V72 SB3600V78 SB3600V84
Part Number SB3600V72 SB3600V78 SB3600V84
Blade Width 72" 78" 84"
Moldboard Height 30" 30" 30"
Approximate Weight 765 lbs 785 lbs 805 lbs
Max Operating Weight 10,000 lbs 10,000 lbs 10,000 lbs
Hydraulic Control 6-Way (35° Angling, V-Position) 6-Way (35° Angling, V-Position) 6-Way (35° Angling, V-Position)
Cutting Edge Reversible AR400 Steel with Spring Trip Reversible AR400 Steel with Spring Trip Reversible AR400 Steel with Spring Trip
Skid Shoes Included Included Included
Mount Compatibility Mount Sold Separately Mount Sold Separately Mount Sold Separately



Manuals & Documents

SB3600V MANUAL

LOADER MOUNTS

HLA SNOW BROCHURE

General Warranty Info:

  • Ripping It Outdoors works closely with our manufacturers to supply and support your products warranty needs as best as possible!
  • The majority of products come with a manufacturer represented warranty against manufacturing defects for at least a 12 month period after the date of sale.
  • Expendable components and "wear parts" including but not limited to blades, knives, teeth, oil, chain sprockets, skid shoes, knife mounting discs, and similar components are usually excluded from manufacturer warranties.
  • Please reach out to us for any specific warranty information neededabout products and parts you can’t find!
