Product Description
HLA Attachments | 4-in-1 Front Loader Bucket | Models MBFNO66 To MBFNO84 | Widths 66" To 84" | Struck Capacity Up To 20.0 cu.ft. | Hydraulic Flow Range 10-15 GPM | For Skid Steer
DESCRIPTION
When versatility meets durability, you get the HLA 4-in-1 Front Loader Bucket your go-to attachment for maximum efficiency on the jobsite or farm. Whether you’re grading, grappling, dozing, or dumping, this robust bucket delivers unmatched utility for your compact or full-size front-end loader.
Crafted with heavy-duty ¼" steel and reinforced 3/8" end plates, this bucket doesn't just perform it performs for years. Thanks to its hydraulic clam shell design and powerful integrated cylinders, you can tackle tough digging, material handling, and site prep jobs with ease.
Choose from multiple sizes (66", 72", 78", 84") to match your machine and operational needs. A wide range of loader mounts is available, giving you seamless compatibility with John Deere, Kubota, Euro/Global, Westendorf, and more. Whether you're managing a job site or a homestead, this is the high-performance bucket designed for real work.
Key Features
- 4-in-1 Design: Combines a dozer, scraper, grapple, and bucket for all-in-one versatility.
- Heavy-Duty Construction: Built from ¼" thick steel with 3/8" end plates and clam floor for lasting strength.
- Hydraulic Clamshell Action: Integrated cylinders allow fast and smooth opening/closing for grab, release, and dump functions.
- High-Capacity Loading: Offers up to 25.7 cu.ft. heaped capacity for efficient material transport.
- Loader Mount Compatibility: Fits most major tractor and loader brands with quick-attach options (sold separately).
- Work-Ready Dimensions: 27" tall and 30" deep for enhanced volume and load control.
- Ideal for Agriculture & Construction: Perfect for landscapers, farmers, contractors, and utility workers needing flexible equipment.
- Powder-Coated Finish: Protects against rust and corrosion in demanding outdoor environments.
-
Hydraulic Flow Range: 10–15 GPM — optimized for compact to mid-size loaders; ensures smooth clamshell operation without overloading system pressure.
Detailed Specifications
| Specification | 4-in-1 Front Loader Bucket MBFNO66 | 4-in-1 Front Loader Bucket MBFNO72 |
|---|---|---|
| Part # | MBFNO66 | MBFNO72 |
| Width | 66" | 72" |
| Struck Capacity | 15.7 cu.ft. | 17.1 cu.ft. |
| Heaped Capacity | 20.0 cu.ft. | 21.9 cu.ft. |
| Height | 27" | 27" |
| Depth | 30" | 30" |
| Weight (Approx.) | 1,015 lbs | 1,020 lbs |
| Material Construction | ¼" shell, 3/8" endplates, clam floor | ¼" shell, 3/8" endplates, clam floor |
| Mount Type | Mount required – sold separately (Euro, JD, Kubota, etc.) | Mount required – sold separately (Euro, JD, Kubota, etc.) |
| Hydraulic Functionality | Includes hydraulic cylinders for 4-in-1 clamshell operation | Includes hydraulic cylinders for 4-in-1 clamshell operation |
| Specification | 4-in-1 Front Loader Bucket MBFNO78 | 4-in-1 Front Loader Bucket MBFNO84 |
|---|---|---|
| Part # | MBFNO78 | MBFNO84 |
| Width | 78" | 84" |
| Struck Capacity | 18.5 cu.ft. | 20.0 cu.ft. |
| Heaped Capacity | 23.8 cu.ft. | 25.7 cu.ft. |
| Height | 27" | 27" |
| Depth | 30" | 30" |
| Weight (Approx.) | 1,130 lbs | 1,195 lbs |
| Material Construction | ¼" shell, 3/8" endplates, clam floor | ¼" shell, 3/8" endplates, clam floor |
| Mount Type | Mount required – sold separately (Euro, JD, Kubota, etc.) | Mount required – sold separately (Euro, JD, Kubota, etc.) |
| Hydraulic Functionality | Includes hydraulic cylinders for 4-in-1 clamshell operation | Includes hydraulic cylinders for 4-in-1 clamshell operation |
