Ignite Attachments 3-Point Disc Harrow | Model DH72 | Working Width 72" | Cultivation Width 75" | Horsepower 22-40 HP | For Tractors
DESCRIPTION
Whether you're prepping new ground or revitalizing old plots, the Ignite DH72 72-Inch Disc Harrow is built to deliver exceptional performance, season after season. Designed with the serious landowner and hobby farmer in mind, this 3-point disc harrow connects seamlessly to CAT 1 tractors and handles 22 to 40 horsepower machines with ease.
The notched front blades break through hard, compacted earth and chop through stubborn plant residue, while the smooth rear blades leave a clean, even seedbed for planting. With 20 heavy-duty, heat-treated steel discs, adjustable gang angles, and durable sealed bearings, the Ignite DH72 makes land preparation faster, cleaner, and more effective.
Whether you're planting food plots, gardens, or small-acreage crops, this American-made disc harrow provides the strength, versatility, and reliability your land demands.
Key Features
- Wide 72-Inch Cutting Width Tills large plots efficiently for gardens, food plots, and light farm use.
- Optimized for 22–40 HP Tractors Perfect for compact and utility tractors with standard CAT 1 3-point hitches.
- Aggressive Notched Front Blades 18" steel discs break up clumps and penetrate compacted soil with power.
- Smooth Rear Blades for Seedbed Finishing Smooth out soil for even planting and improved germination.
- Adjustable Disc Gangs Set your tillage angle from 2.5° to 15° to suit varying soil types and field conditions.
- Heavy-Duty Construction Reinforced steel frame and replaceable sealed bearings built for rugged use.
- Quick Hitch Compatible Easily attaches to most CAT 1 Quick Hitch systems for faster hookup and operation.
- Made in the USA Built with pride and precision for long-lasting field performance.
Detailed Specifications
Specification | Details |
---|---|
Model | DH72 |
Working Width | 72 in (Cultivation Width: 75.0 in) |
Tractor HP Requirement | 22-40 HP |
Overall Length | 50.0 in |
Overall Height | 41.0 in |
Operating Weight | 553 lbs |
Number of Discs | 20 |
Disc Blade Spacing | 7.5 in |
Front Disc Blades | 18.0 in dia. x 0.12 in Notched Steel |
Rear Disc Blades | 18.0 in dia. x 0.12 in Smooth Steel |
Bearing Type | 2 Replaceable Sealed Bearings per Gang |
Gang Angle Adjustability | 2.5° to 15° |
Hitch Type | CAT 1 |
Quick Hitch Compatible | Yes |
Country of Manufacture | USA |
