Product Description
IMD LLC PTO 31/2 S Generator | 31KW Continuous Output | 120/240V Single Phase | 125 Amp Capacity
Description
Power Through Any Task with the High-Performance PTO 31/2 S Generator The PTO 31/2 S Generator is a top-tier power solution designed for agricultural, residential, and light commercial applications. Delivering a robust 31KW continuous output, this generator features a brushless design for maintenance-free operation, ensuring durability and reliability. Built with 100% copper windings, a heavy-duty cast iron gearbox, and a drip-proof design, it provides high-quality, distortion-free power. With simultaneous 120V and 240V outputs, real-time monitoring through a 4” Three Bar LED meter, and advanced safety mechanisms, the PTO 31/2 S Generator is an essential tool for any demanding operation.
Why Choose the PTO 31/2 S Generator?
The PTO 31/2 S Generator combines power, precision, and durability to meet the needs of a variety of operations. Its maintenance-free design, robust construction, and advanced safety features make it a reliable and long-lasting choice for high-demand applications. Whether for agricultural use or backup power, this generator ensures uninterrupted performance.
Key Features
- 31KW Continuous Power: Provides consistent, high-capacity performance for demanding tasks.
- Brushless Design: Ensures maintenance-free reliability and efficiency over time.
- High-Quality Power Output: Features 100% copper windings and a low-distortion alternator (THM<5%) for clean, stable power.
- Rugged Construction: Durable aluminum-steel housing with a cast iron gearbox for long-lasting use.
- Simultaneous Voltage Output: Operates at both 120V and 240V for versatile applications.
- User-Friendly Monitoring: A 4” Three Bar LED meter provides accurate real-time readings of Hertz, Volts, and Amps.
- Safety Features: Equipped with a magnetic circuit breaker and individual circuit protection to prevent overloads.
- Drip-Proof Design: Engineered to perform reliably in challenging environments.
- Full Power Access: Includes a full-power outlet capable of transferring power directly to your home through a transfer switch.
Detailed Specifications
| Category | Specification |
|---|---|
| Model Name | PTO 31/2 S |
| Rated Output | 31KW (31,000 Watts) |
| Maximum Breaker Capacity | 125 Amps |
| Voltage | 120/240V |
| Frequency | 60 Hz |
| Power Source | Tractor Powered |
| PTO Speed | 540RPM |
| Minimum PTO Horsepower | 63 |
| Receptacles | NEMA 5-20, NEMA 14-50, Modular 175A |
| Housing Material | Aluminum, Steel |
| Windings Material | 100% Copper |
| Alternator Type | Low-distortion alternator (THM < 5%), Insulation Class H |
| Dimensions | 35 x 23 x 34 inches |
| Weight | 390 Pounds |
| Safety Mechanisms | Magnetic circuit breaker, individual circuit protection |
| Monitoring Meter | 4” LED meter (Hertz, Volts, Amps) |
| Certifications | UL/CSA-certified circuit breakers and receptacles |
