Interlam Grapple Saw

Interlam Grapple Saw Fixed Rotator | Model IT1050, IT1300, IT1600 & IT1900 | Cutting Diameter 18"-34" | Machine Size 3-30 Tons | For Excavators

Interlam Grapple Saw Fixed Rotator | Model IT1050, IT1300, IT1600 & IT1900 | Cutting Diameter 18"-34" | Machine Size 3-30 Tons | For Excavators

$1.00
$1.00
Sale Sold out
Customizable
Fast
24/7 Support
  • Pricing Unavailable, Request Quote
  • Cutting Capacity Up to 34" Handles small limbs to large trunks depending on model
  • Chain Options: .404" or ¾" Forestry Chain Compatible with B11 or C13 sprockets for rugged cutting applications
  • Excavator Compatibility: 3–30 Tons Fits a wide range of machines fro compact to full-size excavators
View full details

How To Get A Quote:

***Online pricing not available, Please request a quote:***

How To Get A Quote:

Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!

Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!

Product Description

Interlam Grapple Saw Fixed Rotator | Model IT1050, IT1300, IT1600 & IT1900 | Cutting Diameter 18"-34" | Machine Size 3-30 Tons | For Excavators

DESCRIPTION

The Interlam Grapple Saw Fixed Rotator Series is engineered for high-efficiency tree handling, cutting, and removal in forestry, land clearing, and utility applications. Designed to mount on excavators ranging from 3 to 30 tons, each model features a fixed rotator for enhanced control and reduced swing during operation. The hydraulic saw system delivers up to 3625 PSI of cutting power, with models capable of handling diameters from 18" to 34".

From compact units like the IT1050 for mini excavators to heavy-duty models like the IT1900 with worm drive rotator and automatic chain tensioning, the series offers unmatched versatility and durability. All units are equipped with Parker F11 hydraulic motors, bolt-in fish tail chain points, and rugged grapple arms for secure material handling. Whether you're trimming roadside trees or clearing dense timber, Interlam’s grapple saws deliver precision, power, and reliability.

Key Features

  • Fixed Rotator Design Provides stable cutting with reduced swing for precise tree handling
  • Hydraulic Saw Drive (3625 PSI) Delivers powerful cutting performance across all models
  • Cutting Capacity Up to 34" Handles small limbs to large trunks depending on model
  • Parker F11 Hydraulic Motors High-efficiency motors ranging from F11/06 to F11/19 for consistent torque
  • Chain Options: .404" or ¾" Forestry Chain Compatible with B11 or C13 sprockets for rugged cutting applications
  • Chain Tensioning Systems Mechanical quick-tension on smaller models; automatic tensioning on IT1600/800 and IT1900
  • Bolt-In Fish Tail Chain Point Enhances soil penetration and cutting stability
  • Excavator Compatibility: 3–30 Tons Fits a wide range of machines from compact to full-size excavators
  • Heavy-Duty Construction Built for demanding forestry and land clearing environments

Detailed Specifications


IT Series Forestry Cutter Specifications

Feature

IT1050

IT1300

IT1600/500

IT1600/800

IT1900
Weight (lbs) 663 1250 1650 1960 ~2200–2400
Flow Rate (GPM) 10.5–13.5 18–27 18–26 31–42 35–45
Hydraulic Pressure 3625 PSI 3625 PSI 3625 PSI 3625 PSI 3625 PSI
Cutting Diameter Up to 18" 22–25" 20–24" 26–32" 28–34"
Chain Type .404" .404" .404" .404" or ¾" ¾"
Sprocket Type B11 B11 B11 C13 C13
Motor (Parker F11) F11/06 F11/10 F11/10 F11/19 F11/19
Chain Tensioner Mechanical Quick Mechanical Quick Mechanical Quick Automatic Automatic
Excavator Size Range 3–5.5 tons ~5–10 tons ~10–20 tons ~20–30 tons 20–30 tons
Rotator Type Fixed Fixed Fixed Fixed Worm Drive Rotator
Standard Features 5-finger grapple 5-finger grapple 5-finger grapple 7-finger grapple 7-finger grapple
