JMA Attachments Ditching Bucket | Bucket Width 72" inches | Pin Size 45mm Pins | For 5 – 6.5 Tons Excavators
JMA Attachments Ditching Bucket | Bucket Width 72" inches | Pin Size 45mm Pins | For 5 – 6.5 Tons Excavators
Regular price
$3,626.70
Regular price
Sale price
$3,626.70
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
JMA Attachments Ditching Bucket | Bucket Width 72" inches | Pin Size 45mm Pins | For 5 – 6.5 Tons Excavators
Description
Meet your new secret weapon for ditching mastery – the 72" Ditching Bucket for 5 - 6.5 Tons Mini Excavators. 45mm Pins. This 0.50 m³ powerhouse combines capacity and precision to transform your approach to drainage and grading tasks. Game-Changing Advantages:
Key Features
- Volume Virtuoso: 0.50 m³ capacity allows you to handle more material per cycle, boosting overall productivity.
- Durability Champion: Forged from top-grade AR400 Steel to withstand the harshest job site conditions year after year.
- Edge Excellence: Equipped with a Reversible Bolt-On Cutting Edge for superior cutting performance and longevity.
- Mini Excavator Optimized: Designed to maximize your Mini Excavator's potential in the 10,000 - 13,000 lbs class, delivering optimal performance on every job.
- Smooth Operator: Engineered contours facilitate easy material flow and release, even in challenging soil conditions.
Detailed Specifications
| Attribute | Value |
|---|---|
| Carrier Weight Class (tn) | 5 - 6.5 Tons |
| Bucket Width (mm) | 1,828.8 mm |
| Bucket Width (in) | 72" |
| Inner Bucket Height (mm) | 595 mm |
| Bucket Side Wall Thickness (mm) | 15 mm |
| Bucket Depth (mm) | 387 mm |
| Capacity (yd³) | 0.65 yd³ |
| Capacity (m³) | 0.50 m³ |
| Edge Style | Reversible Bolt-On Cutting Edge |
| Material Type | AR400 Steel |
| Finish | Powder-Coated Green |
| Front Pin Length (mm) | 303 mm |
| Rear Pin Length (mm) | 303 mm |
| Front Pin Diameter (mm) | 45 mm |
| Rear Pin Diameter (mm) | 45 mm |
| Front Ear to Ear Distance (mm) | 156 mm |
| Rear Ear to Ear Distance (mm) | 156 mm |
| Center to Center Distance (mm) | 260 mm |
| Carrier Weight Class (lbs) | 10,000 - 13,000 lbs |
| Drain Holes (ct) | 6 |
| Features | 3x Reinforced Side Plates |
| Product Weight (lbs) | 716.50 lb |
| Product Weight (kg) | 325 kg |
Fits To
|
Brand |
Model |
|---|---|
| Airman | AX40U-5F, AX48U-5A, AX50U-5F, AX55U-5A, AX50U-4, AX50-2, AX40U, AX40, AX45, AX50 |
| Bobcat | E42R2, E45EM, E42M, E45M, E55Z, X435, E40, E42, E45, E48, E50, E55, E58, E60, E62 EM, E63, E55EM, E55R2, E60EA, E60R2, E48R2, E50EM, E50R2, E55M, E60A, E63M, E50M, E50Z, E55W, E57W, E65W |
| Case | CX50B, CX55B, CX65D, CX40, CX47, CX50, CX55, CX57, CX58, CX60 |
| Caterpillar | 305.5E2 CR, 305.5D CR, 305.5E CR, 305E2 CR, 305SR II, 304C CR, 305.5SR, 305C CR, 305D CR, 305E CR, 304CCR, 305.5E, 428MK1, 428MK2, 305.5, 305BR, 305CR, 305SR, 306.5, 306CR, 305C, 305D, 305E, 306D, 306E, E70B, 305, 306 |
| Daewoo | S55 V PLUS, S75 LC V, S55V-G, S55W V, S75-V, S50 V, S055, S50 |
| Develon | DX60WN ECO, DX50Z-7, DX55R-7, DX57W-7, DX63-7, DX55 |
| Doosan | DX55-9CN ACE, DX55MT ACE, S55 V PLUS, DX60WN ECO, DX60E-9CN, DX60E-10N, DX75E-9CN, DX60W ECO, DX55MT-5, DX60-9CN, DX75-9CN, DX55W-5K, DX55W-5L, DX55WACE, DX60E-9C, DX60W-9C, DX55-5K, DX60-9C, DX62R-3, DX62R-7, DX65-9C, DX75-5B, DX75-9C, DX85R-3, DX89R-7, DX42-5K, DX50-5K, DX50Z-7, DX55-9C, DX55R-7, DX55W-5, DX57W-5, DX57W-7, DX70-9C, DH55-V, DH60-7, DH70-7, DH80-7, DX63-3, DH55-7, DX42-5, DX50-5, S55W V, DX55WA, DX55WK, DX85R, DX55A, DX55E, DX80R, DX50Z, DX53W, DX55W, DX60R, DX60W, DX55, DX60, DX62, DX63, DX80, DX85, SL55, DH55, DH70, DH80, DX75, DX42, DX50, S55, S70, S75 |
| Ford | 555C, 555, 655 |
| Hanix | H50B, H50C, H56B, H56C, H45, H50 |
| Hitachi | ZX65USB-5A CLP, ZX65USB-5A CLR, ZX65USB-5A LC, ZX60USB-3CLR, ZX60USBNA-3, ZX48U-2 -3, ZX55U-2 -3, ZX60USB LC, ZX60USB-3F, ZX60USB-5N, ZX65USB-3F, ZX65USB-5A, ZX60USB-3, ZX60USB-5, ZX65USB-3, ZX65USB-5, ZX65USB-6, EX55UR-3, EX75UR-3, ZX48U-5A, ZX50U-3F, ZX55U-5A, ZX55UR-3, ZX50U-2, ZX50U-3, ZX60-5A, ZX60USB, EX40-2, EX45-2, EX55UR, EX58MU, EX60-1, EX60-2, EX60-3, EX60UR, EX75UU, ZX50-2, ZX60-2, ZX60-3, ZX60US, EX40U, EX50U, ZX40U, EX40, EX50, EX58, UE02, ZX60, ZX50U, ZX60U |
| Hyundai | R60CR-9, R60W-9S, R55-3, R55-7, R55-9 |
| Ihi | IS40-JX, 50NX, 50VX, 55NX, IS40, IS45 |
| JCB | 8080 ZTS, 100C-1, 50Z-2, 51R-1, 56Z-2, 57C-1, 60C-2, 65R-1, 67C-1, 805.2, 8052C, 8060C, 85Z-1, 86C-1, 90Z-1, 8052, 8060, 8065, 8080, 8085, 45Z, 48Z, 55Z, 65R, 67C, 85Z, 86C, 90Z |
| John Deere | 50C ZTS, 50D ZTS, 50 ZTS, 55 ZTS, 50C, 50D, 50G, 60D, 60G, 70D, 50 |
| Kobelco | SK040SR-3, SK040SR-5, SK050SR-3, SK050SR-5, SK40SR-1, SK40SR-2, SK40SR-3, SK40SR-5, SK45SR-1, SK45SR-2, SK50SR-3, SK50SR-5, SK50UR-2, SK55SR-5, SK045-1, SK045-2, SK045-3, SK045SR, SK40SR, SK50UR, SK042, SK045 |
| Komatsu | PC45 MRX-1, PC50 MRX-2, PC40MRC-2, PC40MRX-1, PC50UUT-2, PC40MR-2, PC40MR-3, PC50MR-2, PC50UU-1, PC50UU-2, PC50UU-3, PC55MR-3, PC58SF-1, PC58UU-3, PC40MRX, PC40R-8, PC45R-8, PC50 MR, PC50UUT, PC40-7, PC45-1, WB97, WB93, WB91, PC45, PC55 |
| Kubota | KX057-4, KX121-4, KX161-2, KX161-3, KH191, KX060, KX151, KX161, U45-3, U48-4, U48-5, U50-3, U50-5, U55-4, U56-6, K045, KH28, KO40, KX75, U40, U45, KX057-5, U55 |
| Linkbelt | MS070 |
| Nagano | NS55-3 |
| New Holland | EH50 BSR, E50-2SR, NH115 B |
| Sany | SY50U, SY50 |
| Takeuchi | TB153FR, TB53FR, TB045, TB145, TB153, TB250, TB260, TB45 |
| Volvo | EC55 - 12 Volt, EC55B PRO, EC60B LC, EC50/W, MX55/W, SE50-3, EC60C, EC60D, EC60E, ECR58, BL71, EC55 |
| Wacker Neuson | 6003, 6503, EZ53, 50Z |
| XCMG | XCG60-8 |
| Yanmar | VIO50B50, VIO40-2, VIO40-7, VIO45-5, VIO50-2, VIO55-5, YC45-7, VIO50, VIO55, VIO57, SV60 |
