Brand |
Model |
|---|---|
| Caterpillar | 315D2 GC, 315F LCR, 315 GC, 315D2L, 317BLN, 318BL2, 318BLN, 318CLN, 318D2L, 318DL2, 318EL2, 318FL2, 315BL, 315CL, 315DL, 315LN, 316EL, 316FL, 316GC, 317BL, 317GC, 318CN, M313D, 315B, 315C, 315D, 315F, 315L, 316E, 317B, 317N, 318B, 318E, 215, 315, 317 |
| Hyundai | R160LC-3, R160LC-7, R160LC-9, R180LC-3, R180LC-7, R180LC-9, R210LC-3, R170W-3, R200W-2, R200W-3, R160LC, R180LC, R200LC, R220LC |
| Kato | 700SEV2, HD700SE, HD700V2, HD700, 900 |
| Kobelco | SK170LC-8 |
| Komatsu | PC160 LC-7A E0, PC150 HD LC-5, PC150N HD-5K, PC158US LC-2, PC160 LC-7E0, PC160 LC-7KA, PC180 LC-7E0, PC180N LC-5K, PC180N LC-6K, PC180N LC-7K, PC150 HD-5K, PC150 LC-3W, PC150 LC-6K, PC150 LC-8K, PC150 LGP-6, PC150N HD-5, PC160 LC-6K, PC160 LC-7E, PC160 LC-7K, PC160 LC-7L, PC160LC-7EO, PC170 LC-10, PC170 LC-11, PC180 LC-5K, PC180 LC-6K, PC180 LC-7K, PC180L LC-3, PC180N LC-3, PC180N LC-5, PC180N LC-6, PC180N LC-7, PC150 HD-3, PC150 HD-5, PC150 LC-1, PC150 LC-3, PC150 LC-5, PC150 LC-6, PC150 LC-7, PC158US LC, PC160 LC-6, PC160 LC-7, PC160 LC-8, PC180 LC-3, PC180 LC-5, PC180 LC-6, PC180 LC-7, PC150N HD, PC158US-2, PC160N LC, PC180N LC, PC150 HD, PC150 LC, PC150 SE, PC150-3W, PC150-5K, PC150-6K, PC150C-3, PC150C-6, PC150L-6, PC158 LC, PC160 LC, PC160-6K, PC160-7K, PC168 LC, PC170 LC, PC180 LC, PC180-3K, PC180-5K, PC180-6K, PC150-1, PC150-3, PC150-5, PC150-6, PC160-6, PC160-7, PC160-8, PC180-3, PC180-5, PC180-6, PC180-7, PC150C, PC150L, PC150, PC158, PC160, PC180, PW150 |
| Liebherr | 922 |
| Samsung | SE130LC |
| Sumitomo | LS2800FJ, S2800FJ |
| Volvo | EC160B LC, EC160C LC, EC150 LC, EC160 LC, SE170W-3, EC160CL, EC160DL, EC160EL, EC170DL, EC180CL, EC180DL, EC180EL, MX175WS, EC150B, EC150C, EC160B, EC160C, EC160N, EC160P, EC180B, EC180C, EC180D, EC150, EC160, EW170 |
JMA Attachments Hydraulic Hammer | Model JMA-160 EBH | Energy Class 2,100 Joules | For 15 – 18 Tons Excavators
JMA Attachments Hydraulic Hammer | Model JMA-160 EBH | Energy Class 2,100 Joules | For 15 – 18 Tons Excavators
Regular price
$11,326.70
Regular price
Sale price
$11,326.70
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
JMA Attachments Hydraulic Hammer | Model JMA-160 EBH | Energy Class 2,100 Joules | For 15 – 18 Tons Excavators
Description
Dominate the demolition landscape with the 2,100 Joules Hydraulic Hammer for 15 - 18 Tons Excavators. 70mm Pins. Engineered for Mini Excavators, this hydraulic hammer is the cornerstone of efficient breaking operations and accelerated project timelines. Unleash the full potential of your Mini Excavator. The 2,100 Joules Hydraulic Hammer for 15 - 18 Tons Excavators. 70mm Pins isn't just an attachment – it's your competitive edge in the demanding world of demolition and breaking.
Key Features
- Forceful Impact: 2,100 Joules energy class for unrivaled breaking power.
- Rapid Strikes: 400 - 650 bpm impact frequency maximizes productivity on every job.
- Rugged Resilience: AR400 Steel construction withstands the harshest working conditions.
- Minimal Recoil: Advanced design enhances operational safety and reduces operator fatigue.
-
Complete Kit: 2 Hydraulic Hoses,1 Moil Rock Chisel Bit, 1 Wedge Rock Chisel Bit, Tool Box, Nitrogen Gauge, Nitrogen Bottle, Repair Seal Kit, 2 Greasable Pins, 4 Bushings included for immediate deployment.
Detailed Specifications
| Details | Specifications |
|---|---|
| Material Type | AR400 Steel |
| Finish | Powder-Coated Green |
| Energy Class (J) | 2,100 Joules |
| Energy Class (ft·lb) | 1,548.88 ft·lb |
| Impact Frequency (bpm) | 400 - 650 bpm |
| Operating Pressure (kgf/m²) | 150 - 170 kgf/m² |
| Operating Pressure (lbs/ft²) | 30.72 - 34.82 lb/ft² |
| Oil Flow (GPM) | 21.13 – 29.05 gpm |
| Tool Chisel Bit Diameter (mm) | 100 mm |
| Tool Chisel Bit Length (mm) | 1000 mm |
| Working Weight (kg) | 861 kg |
| Accessories Included | 2 Hydraulic Hoses, 1 Moil Rock Chisel Bit, 1 Wedge Rock Chisel Bit, Tool Box, Nitrogen Gauge, Nitrogen Bottle, Repair Seal Kit, 2 Greasable Pins, 4 Bushings |
| Front Pin Diameter (mm) | 70 mm |
| Rear Pin Diameter (mm) | 70 mm |
| Front Ear to Ear Distance (mm) | 311 mm |
| Rear Ear to Ear Distance (mm) | 311 mm |
| Center to Center Distance (mm) | 401 mm |
| Carrier Weight Class (tn) | 15 - 18 Tons |
| Carrier Weight Class (lbs) | 30,000 - 36,000 lbs |
| Product Weight (lbs) | 2,197.53 lb |
| Product Weight (kg) | 996.78 kg |
