JMA Attachments Hydraulic Hammer | Model JMA-304 EBH | Energy Class 500 Joules | For 4 – 5 Tons Mini Excavators & Backhoe Loaders
JMA Attachments Hydraulic Hammer | Model JMA-304 EBH | Energy Class 500 Joules | For 4 – 5 Tons Mini Excavators & Backhoe Loaders
Regular price
$4,045.36
Regular price
Sale price
$4,045.36
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
JMA Attachments Hydraulic Hammer | Model JMA-304 EBH | Energy Class 500 Joules | For 4 – 5 Tons Mini Excavators & Backhoe Loaders
Description
Unleash the power of efficient demolition with the 500 Joules Hydraulic Hammer For 4 - 5 Tons Mini Excavators and Backhoe Loaders. 40mm Pins. Precision-engineered for Excavators, this hydraulic hammer is the ultimate tool for conquering the most demanding breaking tasks. Take your demolition projects to the next level. With the 500 Joules Hydraulic Hammer For 4 - 5 Tons Mini Excavators and Backhoe Loaders. 40mm Pins, you're investing in a tool that combines raw power with intelligent design to deliver unmatched results in any breaking application.
Key Features
- Exceptional Breaking Power: 500 Joules energy class ensures superior performance on tough materials.
- High-Frequency Impact: 600 - 1,000 bpm strikes per minute for rapid material processing.
- Durability Redefined: AR400 Steel construction guarantees longevity in harsh working conditions.
- Operator-Friendly Design: Engineered to minimize recoil and enhance safety.
- Complete Package: Includes 2 Hydraulic Hoses,1 Moil Rock Chisel Bit, 1 Wedge Rock Chisel Bit, Tool Box, Nitrogen Gauge, Nitrogen Bottle, Repair Seal Kit, 2 Greasable Pins, 4 Bushings for immediate deployment and optimal performance.
Detailed Specifications
| Attribute | Value |
|---|---|
| Material Type | AR400 Steel |
| Finish | Powder-Coated Green |
| Energy Class (J) | 500 Joules |
| Energy Class (ft·lb) | 368.78 ft·lb |
| Impact Frequency (bpm) | 600 - 1,000 bpm |
| Operating Pressure (kgf/m²) | 90 - 120 kgf/m² |
| Operating Pressure (lbs/ft²) | 18.43 - 24.58 lb/ft² |
| Oil Flow (GPM) | 6.6 - 13 gpm |
| Tool Chisel Bit Diameter (mm) | 53 mm |
| Tool Chisel Bit Length (mm) | 550 mm |
| Working Weight (kg) | 152 kg |
| Accessories Included | 2 Hydraulic Hoses, 1 Moil Rock Chisel Bit, 1 Wedge Rock Chisel Bit, Tool Box, Nitrogen Gauge, Nitrogen Bottle, Repair Seal Kit, 2 Greasable Pins, 4 Bushings |
| Front Pin Diameter (mm) | 40 mm |
| Rear Pin Diameter (mm) | 40 mm |
| Front Ear to Ear Distance (mm) | 156 mm |
| Rear Ear to Ear Distance (mm) | 156 mm |
| Center to Center Distance (mm) | 260 mm |
| Carrier Weight Class (tn) | 4 - 5 Tons |
| Carrier Weight Class (lbs) | 8,000 - 10,000 lbs |
| Product Weight (lbs) | 491.16 lb |
| Product Weight (kg) | 222.79 kg |
Fits To
|
Brand |
Model |
|---|---|
| Airman | AX30U-5F, AX30UC-4, AX30UC-5, AX33U-5A, AX35U-5F, AX38U-5A, AX30-U2, AX30U-4, AX33Mu, AX30, AX35 |
| Case | CX31B, CX36B, CX33, CX37 |
| Caterpillar | 303.5D2 CR, 303.5E2 CR, 303.5C CR, 303.5D CR, 303.5E CR, 303C2 CR, 303.5CR, 303C CR, 303E CR, 304D CR, 303.4C, 303.5C, 303.5D, 303.5E, 303CR2, 303ESR, 304ECR, 305CR2, 303.5, 303CR, 303GR, 303SR, 304.5, 304CR, 304E2, 303 |
| Daewoo | S030, S035, S35 |
| Develon | DX27Z-7, DX35Z-7, DX42-7 |
| Doosan | DX27Z-7, DX35Z-7, DX35-5, DX35 |
| Ford | 550 |
| Hanix | H36B-R, H30A, H35A, H36A, H36B |
| Hitachi | ZX33U-2 -3, ZX38U-2 -3, EX40UR-2C, EX40UR-2, EX40UR-3, ZX33U-5A, ZX35U-3F, ZX38U-5A, ZX30-U2, ZX30U-2, ZX35U-2, EX30-2, EX33MU, EX35-2, EX40UR, EX50UR, EX30U, EX33U, EX35U, ZX30U, ZX35U, EX35, EX45, ZX26U, ZX30, ZX35 |
| Hyundai | R35-5, R35-7 |
| Ihi | IS35VX-2, IS35N, IS35 |
| JCB | 8040, 8045, 8055 |
| John Deere | 27C ZTS, 27D ZTS, 35C ZTS, 35D ZTS, 27 ZTS, 35 ZTS, 27CT, 35CT, 35ZT, 25D, 25E, 26G, 27C, 27D, 30G, 35C, 35D, 35G, 25, 30, 35, 26P, 30P, 35P, 27ZTS, 35ZTS |
| Kobelco | SK30SR-1, SK30SR-2, SK30SR-3, SK30SR-4, SK30SR-5, SK35SR-1, SK35SR-2, SK35SR-3, SK35SR-4, SK35SR-5, SK35SR-6, SK032, SK035 |
| Kubota | U30 Import, KX040-4, KX101-3, KX121-2, KX121-3, KX121-5, KX71-2, KX71-3, KX91-2, KX91-3, KH16W, KX101, KX121, RX302, U35-3, U35-4, U36-4, KH90, KO30, KX71, KX91, U35, KX033, KX040 |
| Linkbelt | HE902, MM40, MM55 |
| Liugong | 9035E |
| Nagano | NS35R-3, NS55R-5, NS45-3, NS35 |
| New Holland | E35B, E33, E37 |
| Nissan | N350 |
| Sany | SY26, SY26U, SY27U |
| Sumitomo | SWE50, SWE55 |
| Takeuchi | TB138FR, TB035, TB107, TB108, TB135, TB138, TB235, TB240, TB14, TB16, TB23, TB36 |
| Terex | TC35/TC37, TC48/TC50, TC60 |
| Volvo | EC35 C, EC35C, ECR38 |
| Wacker Neuson | 3003, 3503, 3703, 38Z3, ET35, EZ26, EZ35, EZ36, EZ38, 28Z, 38Z |
| Yanmar | YC18-3, YC25-2, YC30-2, YC35 |
