JMA Attachments Main Pin Hydraulic Thumb | Pin Size 22.5" inches | For 15 – 19 Tons Excavators
JMA Attachments Main Pin Hydraulic Thumb | Pin Size 22.5" inches | For 15 – 19 Tons Excavators
Regular price
$4,997.00
Regular price
Sale price
$4,997.00
Unit price
per
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
JMA Attachments Main Pin Hydraulic Thumb | Pin Size 22.5" inches | For 15 – 18 Tons Excavators
Description
Elevate your excavation capabilities with the 70mm Main Pin Hydraulic Thumb for 15 - 18 Tons Excavators. Tailored for Excavators in the 30,000 - 36,000 lbs class, this hydraulic thumb attachment brings unparalleled versatility to your job site operations. Experience the pinnacle of material handling technology. With the 70mm Main Pin Hydraulic Thumb for 15 - 18 Tons Excavators, you're not just attaching a thumb – you're unlocking a world of new possibilities for your excavation projects.
Key Features
- Superior Grip: 4-tine design ensures secure handling of diverse materials.
- Precision Control: 1,655 mm hydraulic cylinder for smooth, accurate movements.
- Built to Last: AR400 Steel construction guarantees longevity in demanding environments.
- Operational Flexibility: Excels in demolition, landscaping, and irregular object handling.
- Seamless Integration: Designed for easy installation and optimal performance with your Excavator.
Detailed Specifications
| Feature | Value |
|---|---|
| Product Width (mm) | 571.5 mm |
| Product Width (in) | 22.5" |
| Product Length (mm) | 1308.1 mm |
| Product Length (in) | 51.5" |
| Tines (ct.) | 4 |
| Tines Thickness (in) | 0.79" |
| Tines Thickness (mm) | 20 mm |
| Material Type | AR400 Steel |
| Finish | Powder-Coated Green |
| Tines Spacing (mm) | 150 mm |
| Hydraulic Cylinder Length Retracted (mm) | 990 mm |
| Hydraulic Cylinder Length Extended (mm) | 1655 mm |
| Main Pin Diameter (mm) | 70 mm |
| Front Ear to Ear Distance (mm) | 480 mm |
| Carrier Weight Class (tn) | 15 - 18 Tons |
| Carrier Weight Class (lbs) | 30,000 - 36,000 lbs |
| Product Weight (lbs) | 665.80 lb |
| Product Weight (kg) | 302 kg |
Fits To
|
Brand |
Model |
|---|---|
| Caterpillar | 315D2 GC, 315F LCR, 315 GC, 315D2L, 317BLN, 318BL2, 318BLN, 318CLN, 318D2L, 318DL2, 318EL2, 318FL2, 315BL, 315CL, 315DL, 315LN, 316EL, 316FL, 316GC, 317BL, 317GC, 318CN, M313D, 315B, 315C, 315D, 315F, 315L, 316E, 317B, 317N, 318B, 318E, 215, 315, 317 |
| Hyundai | R160LC-3, R160LC-7, R160LC-9, R180LC-3, R180LC-7, R180LC-9, R210LC-3, R170W-3, R200W-2, R200W-3, R160LC, R180LC, R200LC, R220LC |
| Kato | 700SEV2, HD700SE, HD700V2, HD700, 900 |
| Kobelco | SK170LC-8 |
| Komatsu | PC160 LC-7A E0, PC150 HD LC-5, PC150N HD-5K, PC158US LC-2, PC160 LC-7E0, PC160 LC-7KA, PC180 LC-7E0, PC180N LC-5K, PC180N LC-6K, PC180N LC-7K, PC150 HD-5K, PC150 LC-3W, PC150 LC-6K, PC150 LC-8K, PC150 LGP-6, PC150N HD-5, PC160 LC-6K, PC160 LC-7E, PC160 LC-7K, PC160 LC-7L, PC160LC-7EO, PC170 LC-10, PC170 LC-11, PC180 LC-5K, PC180 LC-6K, PC180 LC-7K, PC180L LC-3, PC180N LC-3, PC180N LC-5, PC180N LC-6, PC180N LC-7, PC150 HD-3, PC150 HD-5, PC150 LC-1, PC150 LC-3, PC150 LC-5, PC150 LC-6, PC150 LC-7, PC158US LC, PC160 LC-6, PC160 LC-7, PC160 LC-8, PC180 LC-3, PC180 LC-5, PC180 LC-6, PC180 LC-7, PC150N HD, PC158US-2, PC160N LC, PC180N LC, PC150 HD, PC150 LC, PC150 SE, PC150-3W, PC150-5K, PC150-6K, PC150C-3, PC150C-6, PC150L-6, PC158 LC, PC160 LC, PC160-6K, PC160-7K, PC168 LC, PC170 LC, PC180 LC, PC180-3K, PC180-5K, PC180-6K, PC150-1, PC150-3, PC150-5, PC150-6, PC160-6, PC160-7, PC160-8, PC180-3, PC180-5, PC180-6, PC180-7, PC150C, PC150L, PC150, PC158, PC160, PC180, PW150 |
| Liebherr | 922 |
| Samsung | SE130LC |
| Sumitomo | LS2800FJ, S2800FJ |
| Volvo | EC160B LC, EC160C LC, EC150 LC, EC160 LC, SE170W-3, EC160CL, EC160DL, EC160EL, EC170DL, EC180CL, EC180DL, EC180EL, MX175WS, EC150B, EC150C, EC160B, EC160C, EC160N, EC160P, EC180B, EC180C, EC180D, EC150, EC160, EW170 |
