| Attribute | Value |
|---|---|
| Product Width (mm) | 470 mm |
| Product Width (in) | 18.5" |
| Product Height (mm) | 597 mm |
| Product Height (in) | 23.5" |
| Product Length (mm) | 831 mm |
| Product Length (in) | 32.72" |
| Material Type | AR400 Steel |
| Finish | Powder-Coated Green |
| Hydraulic Motor Brand | Permco Hydraulic Motor Pump |
| Tamping Force (kg/cm) | 100 - 130 kg/cm |
| Tamping Force (ft⋅lb) | 7,233 - 9,403 ft⋅lb |
| Hydraulic Flow (LPM) | 70 LPM |
| Hydraulic Flow (GPM) | 18 GPM |
| Revolutions Per Minute (Minimum) | 600 rpm |
| Revolutions Per Minute (max) | 3,000 rpm |
| PSI (max) | 4,640 psi |
| Motor Series | PT7B |
| Motor Force (kw) | 16.5 kw |
| Impluse Force (tn) | 5 Tons |
| Impluse Force (lbs) | 11,023.10 lb |
| Accessories Included | Leveling Pushing Blade, Two Hydraulic Hoses and Tools for Servicing |
| Front Pin Diameter (mm) | 45 mm |
| Rear Pin Diameter (mm) | 45 mm |
| Front Ear to Ear Distance (mm) | 156 mm |
| Rear Ear to Ear Distance (mm) | 156 mm |
| Center to Center Distance (mm) | 260 mm |
| Front Pin Length (mm) | 303 mm |
| Rear Pin Length (mm) | 303 mm |
| Carrier Weight Class (tn) | 5 - 6.5 Tons |
| Carrier Weight Class (lbs) | 10,000 - 13,000 lbs |
| Product Weight (lbs) | 616 lbs |
| Product Weight (kg) | 280 kg |
Fits To
|
Brand |
Model |
|---|---|
| Airman | AX40U-5F, AX48U-5A, AX50U-5F, AX55U-5A, AX50U-4, AX50-2, AX40U, AX40, AX45, AX50 |
| Bobcat | E42R2, E45EM, E42M, E45M, E55Z, X435, E40, E42, E45, E48, E50, E55, E58, E60, E62 EM, E63, E55EM, E55R2, E60EA, E60R2, E48R2, E50EM, E50R2, E55M, E60A, E63M, E50M, E50Z, E55W, E57W, E65W |
| Case | CX50B, CX55B, CX65D, CX40, CX47, CX50, CX55, CX57, CX58, CX60 |
| Caterpillar | 305.5E2 CR, 305.5D CR, 305.5E CR, 305E2 CR, 305SR II, 304C CR, 305.5SR, 305C CR, 305D CR, 305E CR, 304CCR, 305.5E, 428MK1, 428MK2, 305.5, 305BR, 305CR, 305SR, 306.5, 306CR, 305C, 305D, 305E, 306D, 306E, E70B, 305, 306 |
| Daewoo | S55 V PLUS, S75 LC V, S55V-G, S55W V, S75-V, S50 V, S055, S50 |
| Develon | DX60WN ECO, DX50Z-7, DX55R-7, DX57W-7, DX63-7, DX55 |
| Doosan | DX55-9CN ACE, DX55MT ACE, S55 V PLUS, DX60WN ECO, DX60E-9CN, DX60E-10N, DX75E-9CN, DX60W ECO, DX55MT-5, DX60-9CN, DX75-9CN, DX55W-5K, DX55W-5L, DX55WACE, DX60E-9C, DX60W-9C, DX55-5K, DX60-9C, DX62R-3, DX62R-7, DX65-9C, DX75-5B, DX75-9C, DX85R-3, DX89R-7, DX42-5K, DX50-5K, DX50Z-7, DX55-9C, DX55R-7, DX55W-5, DX57W-5, DX57W-7, DX70-9C, DH55-V, DH60-7, DH70-7, DH80-7, DX63-3, DH55-7, DX42-5, DX50-5, S55W V, DX55WA, DX55WK, DX85R, DX55A, DX55E, DX80R, DX50Z, DX53W, DX55W, DX60R, DX60W, DX55, DX60, DX62, DX63, DX80, DX85, SL55, DH55, DH70, DH80, DX75, DX42, DX50, S55, S70, S75 |
| Ford | 555C, 555, 655 |
| Hanix | H50B, H50C, H56B, H56C, H45, H50 |
| Hitachi | ZX65USB-5A CLP, ZX65USB-5A CLR, ZX65USB-5A LC, ZX60USB-3CLR, ZX60USBNA-3, ZX48U-2 -3, ZX55U-2 -3, ZX60USB LC, ZX60USB-3F, ZX60USB-5N, ZX65USB-3F, ZX65USB-5A, ZX60USB-3, ZX60USB-5, ZX65USB-3, ZX65USB-5, ZX65USB-6, EX55UR-3, EX75UR-3, ZX48U-5A, ZX50U-3F, ZX55U-5A, ZX55UR-3, ZX50U-2, ZX50U-3, ZX60-5A, ZX60USB, EX40-2, EX45-2, EX55UR, EX58MU, EX60-1, EX60-2, EX60-3, EX60UR, EX75UU, ZX50-2, ZX60-2, ZX60-3, ZX60US, EX40U, EX50U, ZX40U, EX40, EX50, EX58, UE02, ZX60, ZX50U, ZX60U |
| Hyundai | R60CR-9, R60W-9S, R55-3, R55-7, R55-9 |
| Ihi | IS40-JX, 50NX, 50VX, 55NX, IS40, IS45 |
| JCB | 8080 ZTS, 100C-1, 50Z-2, 51R-1, 56Z-2, 57C-1, 60C-2, 65R-1, 67C-1, 805.2, 8052C, 8060C, 85Z-1, 86C-1, 90Z-1, 8052, 8060, 8065, 8080, 8085, 45Z, 48Z, 55Z, 65R, 67C, 85Z, 86C, 90Z |
| John Deere | 50C ZTS, 50D ZTS, 50 ZTS, 55 ZTS, 50C, 50D, 50G, 60D, 60G, 70D, 50 |
| Kobelco | SK040SR-3, SK040SR-5, SK050SR-3, SK050SR-5, SK40SR-1, SK40SR-2, SK40SR-3, SK40SR-5, SK45SR-1, SK45SR-2, SK50SR-3, SK50SR-5, SK50UR-2, SK55SR-5, SK045-1, SK045-2, SK045-3, SK045SR, SK40SR, SK50UR, SK042, SK045 |
| Komatsu | PC45 MRX-1, PC50 MRX-2, PC40MRC-2, PC40MRX-1, PC50UUT-2, PC40MR-2, PC40MR-3, PC50MR-2, PC50UU-1, PC50UU-2, PC50UU-3, PC55MR-3, PC58SF-1, PC58UU-3, PC40MRX, PC40R-8, PC45R-8, PC50 MR, PC50UUT, PC40-7, PC45-1, WB97, WB93, WB91, PC45, PC55 |
| Kubota | KX057-4, KX121-4, KX161-2, KX161-3, KH191, KX060, KX151, KX161, U45-3, U48-4, U48-5, U50-3, U50-5, U55-4, U56-6, K045, KH28, KO40, KX75, U40, U45, KX057-5, U55 |
| Linkbelt | MS070 |
| Nagano | NS55-3 |
| New Holland | EH50 BSR, E50-2SR, NH115 B |
| Sany | SY50U, SY50 |
| Takeuchi | TB153FR, TB53FR, TB045, TB145, TB153, TB250, TB260, TB45 |
| Volvo | EC55 - 12 Volt, EC55B PRO, EC60B LC, EC50/W, MX55/W, SE50-3, EC60C, EC60D, EC60E, ECR58, BL71, EC55 |
| Wacker Neuson | 6003, 6503, EZ53, 50Z |
| XCMG | XCG60-8 |
| Yanmar | VIO50B50, VIO40-2, VIO40-7, VIO45-5, VIO50-2, VIO55-5, YC45-7, VIO50, VIO55, VIO57, SV60 |
