Brand |
Model |
---|---|
Airman | AX30U-5F, AX30UC-4, AX30UC-5, AX33U-5A, AX35U-5F, AX38U-5A, AX30-U2, AX30U-4, AX33Mu, AX30, AX35 |
Case | CX31B, CX36B, CX33, CX37 |
Caterpillar | 303.5D2 CR, 303.5E2 CR, 303.5C CR, 303.5D CR, 303.5E CR, 303C2 CR, 303.5CR, 303C CR, 303E CR, 304D CR, 303.4C, 303.5C, 303.5D, 303.5E, 303CR2, 303ESR, 304ECR, 305CR2, 303.5, 303CR, 303GR, 303SR, 304.5, 304CR, 304E2, 303 |
Daewoo | S030, S035, S35 |
Develon | DX27Z-7, DX35Z-7, DX42-7 |
Doosan | DX27Z-7, DX35Z-7, DX35-5, DX35 |
Ford | 550 |
Hanix | H36B-R, H30A, H35A, H36A, H36B |
Hitachi | ZX33U-2 -3, ZX38U-2 -3, EX40UR-2C, EX40UR-2, EX40UR-3, ZX33U-5A, ZX35U-3F, ZX38U-5A, ZX30-U2, ZX30U-2, ZX35U-2, EX30-2, EX33MU, EX35-2, EX40UR, EX50UR, EX30U, EX33U, EX35U, ZX30U, ZX35U, EX35, EX45, ZX26U, ZX30, ZX35 |
Hyundai | R35-5, R35-7 |
Ihi | IS35VX-2, IS35N, IS35 |
JCB | 8040, 8045, 8055 |
John Deere | 27C ZTS, 27D ZTS, 35C ZTS, 35D ZTS, 27 ZTS, 35 ZTS, 27CT, 35CT, 35ZT, 25D, 25E, 26G, 27C, 27D, 30G, 35C, 35D, 35G, 25, 30, 35, 26P, 30P, 35P, 27ZTS, 35ZTS |
Kobelco | SK30SR-1, SK30SR-2, SK30SR-3, SK30SR-4, SK30SR-5, SK35SR-1, SK35SR-2, SK35SR-3, SK35SR-4, SK35SR-5, SK35SR-6, SK032, SK035 |
Kubota | U30 Import, KX040-4, KX101-3, KX121-2, KX121-3, KX121-5, KX71-2, KX71-3, KX91-2, KX91-3, KH16W, KX101, KX121, RX302, U35-3, U35-4, U36-4, KH90, KO30, KX71, KX91, U35, KX033, KX040 |
Linkbelt | HE902, MM40, MM55 |
Liugong | 9035E |
Nagano | NS35R-3, NS55R-5, NS45-3, NS35 |
New Holland | E35B, E33, E37 |
Nissan | N350 |
Sany | SY35C, SY35U, SY26, SY35, SY26U, SY27U |
Sumitomo | SWE50, SWE55 |
Takeuchi | TB138FR, TB035, TB107, TB108, TB135, TB138, TB235, TB240, TB14, TB16, TB23, TB36 |
Terex | TC35/TC37, TC48/TC50, TC60 |
Volvo | EC35 C, EC35C, ECR38 |
Wacker Neuson | 3003, 3503, 3703, 38Z3, ET35, EZ26, EZ35, EZ36, EZ38, 28Z, 38Z |
Yanmar | YC18-3, YC25-2, YC30-2, YC35 |
Product Description
JMA Attachments Post Driver Hammer | Model JMA-53 GND | Energy Class 500 Joules | For 3 – 6.5 Tons Mini Excavators & Skid Steers
Description
Unlock unprecedented post driving potential with the 500 Joules Post Driver Hammer for 3 - 6.5 Tons Mini Excavators & Skid Steers. Designed for professionals, this advanced post driver hammer redefines efficiency in fencing and signage installation. Experience the pinnacle of post driving technology. With the 500 Joules Post Driver Hammer for 3 - 6.5 Tons Mini Excavators & Skid Steers, you're not just driving posts – you're elevating your entire operation to new heights of efficiency.
Key Features
- Powerful Performance: 500 Joules energy class for superior driving force.
- High-Speed Operation: 600 - 1,000 bpm impact frequency for rapid post installation.
- Precision Engineering: 53 mm chisel bit diameter and 550 mm length for versatile applications.
- Optimal Pressure Range: 18.43 - 24.58 lb/ft² ensures consistent and reliable performance.
- Built to Last: AR400 Steel construction guarantees durability in demanding environments.
-
Fully Equipped: Comes with Hydraulic Joystick, 2 Hydraulic Hoses,1 Moil Rock Chisel Bit, 1 Wedge Rock Chisel Bit, Tool Box, Nitrogen Gauge, Nitrogen Bottle, Repair Seal Kit, 2 Pins, out-of-the-box productivity.
Detailed Specifications
Attribute | Value |
---|---|
Material Type | AR400 Steel |
Finish | Powder-Coated Green |
Max Jaw Opening (mm) | 1,286 mm |
Max Jaw Opening (in) | 50.63" |
Jaw Configuration | 2 x 2 |
Energy Class (J) | 500 Joules |
Energy Class (ft·lb) | 368.78 ft·lb |
Impact Frequency (bpm) | 600 - 1,000 bpm |
Operating Pressure (kgf/m²) | 90 -120 kgf/m² |
Operating Pressure (lbs/ft²) | 18.43 - 24.58 lb/ft² |
Oil Flow (GPM) | 6.6 - 13 gpm |
Tool Chisel Bit Diameter (mm) | 53 mm |
Tool Chisel Bit Length (mm) | 550 mm |
Working Weight (kg) | 152 kg |
Front Pin Diameter (mm) | 40 mm |
Rear Pin Diameter (mm) | 40 mm |
Front Ear to Ear Distance (mm) | 156 mm |
Rear Ear to Ear Distance (mm) | 156 mm |
Center to Center Distance (mm) | 260 mm |
Carrier Weight Class (tn) | 3 - 6.5 Tons |
Carrier Weight Class (lbs) | 6,000 - 13,000 lbs |
Accessories Included | 2 Hydraulic Joysticks, 2 Hydraulic Hoses, 1 Moil Rock Chisel Bit, 1 Wedge Rock Chisel Bit, Tool Box, Nitrogen Gauge, Nitrogen Bottle, Repair Seal Kit, 2 Greasable Pins, 4 Bushings |
Product Weight (lbs) | 869.97 lb |
Product Weight (kg) | 394.61 kg |
