Product Description
Kioti DK5520M Manual Tractor With Loader | 55 HP Gross Power Diesel Engine | 63" Width|3-Point Hitch & Synchronized Shuttle
Description
The Kioti DK5520M Manual Tractor combines power, versatility, and compact design for those requiring premier performance. With a 55 HP diesel engine and synchronized shuttle transmission, this tractor efficiently handles a range of tasks. The rear and mid PTO, along with a Category II 3-point hitch, allow for easy attachment of multiple implements, making it ideal for small farms, landscaping, and heavy-duty property maintenance.
Operators will appreciate the comfort of the deluxe suspension seat, PTO cruise control, and high ground clearance. Safety features such as wet disc brakes, a ROPS frame, and clear visibility lights ensure a secure working environment. Additional options like various tire types, sunshade, and front weights allow customization for specific needs, providing both stability and comfort for long days in the field.
Key Features
- High Power: 55 HP, 3-cylinder diesel engine
- Synchronized Shuttle: 8x8 transmission for smooth shifting
- Hydraulic PTO: Push-button independent PTO for attachments
- ROPS Frame: Sturdy open station for safety
- Differential Lock: Enhanced traction in tough terrain
- Comfort Seat: Deluxe suspension with lumbar support
- Tilt Steering: Adjustable for operator comfort
- Convenient Lighting: Headlights and rear work light included
- Category II Hitch: Compatible with a wide range of implements
- Customization Options: Turf, industrial, or R14 tires
Detailed Specifications
| Category | Specification |
|---|---|
| Engine | |
| Model | 3HT-TM4B |
| Gross Power | 55 HP (41 kW) |
| PTO Power | 45.6 HP (34 kW) |
| Rated RPM | 2,600 RPM |
| Transmission | |
| Type | Synchro Shuttle |
| Shuttle | Dry Type Single Stage |
| Travel Speeds | 8 Forward / 8 Reverse |
| Min Speed (Forward) | 2.08 mph (3.35 km/h) |
| Max Speed (Forward) | 26.9 mph (43.3 km/h) |
| PTO | |
| Type | Independent |
| Rear PTO Speed | 540 RPM |
| Brakes and Clutch | |
| Brakes | Wet Multi Disc |
| Clutch | Dry Single Plate |
| Dimensions | |
| Length with 3-Point | 124.3 in. (3,157 mm) |
| Width | 62.8 in. (1,596 mm) |
| Height (ROPS) | 96.8 in. (2,458 mm) |
| Wheelbase | 71.3 in. (1,810 mm) |
| Ground Clearance | 14.5 in. (368 mm) |
| Turning Radius w/ Brake | 102.8 in. (2,610 mm) |
| Hydraulics | |
| Pump Type | Gear |
| Max Flow Rate | 14.56 GPM (55.1 L/min) |
| 3-Point Hitch | |
| Category | Category II |
| Lift Capacity (24” Aft) | 2,716 lbs (1,232 kg) |
| Control | Position |
| Weight | |
| Weight with Ag Tires | 3,373 lbs (1,530 kg) |
In Package
- Kioti DK5520M Manual Tractor with Loader
- Operator’s Manual and Quick Start Guide
Available Options
- Tire Options: Turf, Industrial, R14
- Sunshade for open station
- Front weights for enhanced stability
