Product Description
Kioti DK6020SEHB 60 HP 4WD Premium Tractor | 60HP Gross Power | 63" Width | Turf Tires & Hydrostatic Transmission
Description
The Kioti DK6020SEHB is a premium 4WD tractor designed to meet the needs of various landowners, from weekend farmers to seasoned professionals. With a powerful 60 HP 3-cylinder diesel engine and hydrostatic transmission, this tractor effortlessly handles challenging tasks. SE model enhancements, such as a deluxe suspension seat, joystick valve, and single hydraulic valve, add convenience and comfort for longer work sessions.
Equipped with features like PTO cruise control, high ground clearance, and wet disc brakes, the DK6020SEHB ensures safe and efficient operation. Its large hydraulic pump provides the power necessary to manage heavy attachments, while the independent PTO and rear differential lock offer versatile performance. The option to choose from turf, industrial, or R14 tires enables customization for specific applications, making it ideal for any terrain or task.
These tires were made for working. And that’s just what they’ll do.
|
Agricultural Front: 10-16.5 Rear: 13.6-24 |
 |
|
Industrial Front: 10-16.5 Rear: 14.9-24 |
 |
|
R14 Front: 10-16.5 Rear: 14.9-24 |
 |
|
Turf Front: 29-12.5-15 Rear: 21.5L-16.1 |
 |
Key Features
- High Power: 60 HP, 3-cylinder diesel engine
- Hydrostatic Transmission: 3 forward and reverse speeds
- 4WD System: Enhances traction on rough terrain
- Comfort Seat: Deluxe suspension for a smoother ride
- Independent PTO: Rear and mid PTO for attachments
- High Ground Clearance: 14.5 inches for rugged landscapes
- Hydraulic Power: 16.5 GPM pump for heavy-duty work
- Wet Disc Brakes: Reliable braking under load
- Tilt Steering: Power and tilt adjustments for comfort
- Lighting: Projection and working lamps for low-light visibility
Detailed Specifications
| Category | Specification |
|---|---|
| Engine | |
| Model | 3HT-TH4C-57HP-44PTO |
| Gross Power | 60 HP (44.8 kW) |
| PTO Power | 33.4 HP (39.3 kW) |
| Rated Speed | 2,600 RPM |
| Fuel Type | Diesel |
| Aspiration | Natural |
| Displacement | 111.4 cu.in. (1,826 cc) |
| Fuel Capacity | 12.7 gal (48 L) |
| Transmission | |
| Type | Hydrostatic |
| Shuttle | Hydrostatic |
| Forward Speeds | 3 |
| Reverse Speeds | 3 |
| Max Speed (Forward) | 18.5 mph (29.7 km/h) |
| Max Speed (Reverse) | 20.8 mph (12.9 km/h) |
| PTO | |
| Type | Independent |
| Rear PTO Speed | 540 RPM |
| Mid PTO Speed | 2,000 RPM |
| Drive Train | |
| Brakes | Wet Multi Disc |
| Clutch | None |
| Hydraulics | |
| Pump Type | Gear |
| Max Flow Rate | 16.5 GPM (62.4 L/min) |
| 3-Point Hitch | |
| Type | Category II |
| Control | Position Control |
| Lift Capacity | 2,716 lbs (1,232 kg) |
| Dimensions | |
| Length with Hitch | 126 in (3,202 mm) |
| Width | 62.8 in (1,596 mm) |
| Wheelbase | 71.3 in (1,810 mm) |
| Ground Clearance | 14.5 in (368 mm) |
| Front Tread | 49.4 in (1,254 mm) |
| Rear Tread | 49.3 in (1,251 mm) |
| Turning Radius | 102.8 ft (2,610 mm) |
| Weight | |
| Weight | 3,523 lbs (1,598 kg) |
In Package
- Kioti DK6020SEHB Tractor with Turf Tires
- Operator’s Manual and Quick Start Guide
Available Options
- Tire Options: Turf, Industrial, R14
- Sunshade for added comfort
- Front weights for increased stability
