Product Description
Kioti NS5310H Hydrostatic Utility Tractor | 53 HP Diesel Engine | 3-Range HST, Loader Ready
Description
The Kioti NS5310H Hydrostatic Utility Tractor is a powerful 53-horsepower compact utility tractor, ideal for demanding tasks on the farm, in landscaping, and more. Equipped with a hydrostatic transmission, independent PTO, and a single-lever joystick, this tractor provides smooth and efficient performance. The eco-friendly, Tier 4 CRDI diesel engine offers both reduced noise and enhanced fuel efficiency, letting you work longer with fewer interruptions.
With the NS5310H's high ground clearance, ergonomic operator station, and intuitive three-range hydrostatic transmission, this tractor is ready to handle rugged terrains and heavy-duty implements with ease. The independent PTO control, rear remote hydraulic valve, and hydrostatic transmission make it highly versatile, while the single-lever joystick ensures easy, precise control of the loader.
Key Features
- 53 HP Diesel Engine: Eco-friendly, turbocharged power for tough tasks
- Hydrostatic Transmission: Smooth 3-range HST for efficient control
- Independent PTO: Rear PTO with 540 rpm, optional mid PTO at 2,000 rpm
- Single Lever Joystick: Easy control for precise loader operation
- High Ground Clearance: 13.4 inches for navigating rough terrain
- Rear Remote Hydraulic Valve: Operates hydraulic implements from the cab
- Wet Disc Brakes: Dependable stopping power in various conditions
- Twin Pedal Operation: Intuitive forward and reverse movement
- Position & Draft Control: Enhanced 3-point hitch management
- Ergonomic Design: Comfortable operator area with easy-access controls
Detailed Specifications
| Category | Specification |
|---|---|
| Engine Model | 3HT-S4TH50A |
| Engine Power | 50.3 HP (37.5 kW) |
| Rated Speed | 2,600 rpm |
| Cylinders | 3 |
| Fuel Type | Diesel |
| Aspiration | Turbocharged |
| Displacement | 111.4 cu. in. (1,826 cc) |
| Fuel Tank Capacity | 13.2 gal (50 L) |
| Transmission Type | Hydrostatic, 3 Range |
| Max Travel Speed | 17.5 mph (28.1 km/h) |
| PTO Power | 41.8 HP (31.2 kW) |
| Rear PTO Speed | 540 rpm |
| Mid PTO Speed | 2,000 rpm (Optional) |
| Brakes | Wet Disc Type |
| Dimensions (L x W x H) | 136.4 x 67.1 x 98.4 in |
| Wheelbase | 75.5 in |
| Ground Clearance | 13.4 in |
| Front/Rear Tread | 51.1 / 54.3 in |
| Turning Radius w/ Brake | 10.94 ft (3.34 m) |
| Hydraulic Pump Flow | 16.5 GPM (62.4 L/min) |
| 3-Point Hitch Category | Category I |
| Lift Capacity (24" Aft) | 2,493 lbs (1,131 kg) |
| Weight | 4,027 lbs (1,827 kg) |
In Package
- Kioti NS5310H Utility Tractor
- Loader Attachment
- Owner’s Manual and Quick Start Guide
Available Options
- Tire Options: Ag, Turf, Industrial
- Additional Attachments: Rear blade, sunshade, front weights
