Products Description
Larson Electronics 2.4KW Solar Powered Security Light Tower - (8) 120W LED Lights -30' Manual Mast
DESCRIPTION
The SPLT-2.4K-1600A-30-8X120W-LED-BC.40.240 Solar Powered Light Tower by Larson Electronics is an advanced solar-powered lighting solution, ideal for remote and off-grid work areas. Equipped with eight high-intensity LED lamps producing 86,000 lumens and a fully solar-powered system, this tower eliminates the need for traditional power sources, making it ideal for applications in areas without electricity access. This unit’s solar panels deliver 2,400 watts, supported by a 1,600aH battery bank and accessible 120/240V outlets for flexible power usage. The solar-powered operation also eliminates the noise of gas-powered generators, ensuring a quieter work environment.
This light tower’s 30-foot telescoping mast can be adjusted manually and locked in place, with a robust design that withstands winds up to 125 mph when lowered. The LED lamps, mounted on a sturdy, powder-coated blue steel frame, are designed for broad flood illumination, capable of lighting up to 1-2 acres. With an operational life of over 50,000 hours and a non-toxic, recyclable build, the LEDs offer sustainable and efficient lighting. All components are mounted on a rugged trailer, providing mobility and easy deployment for large-scale, continuous lighting needs.
Key Features
- High Lumen Output: 86,000 lumens of LED light for wide-area illumination
- Solar-Powered System: 2,400W solar panels with 1,600aH battery for sustainable power
- Telescoping Mast: 30-foot height for maximum coverage, collapsible to 8.75 feet
- Robust LED Lamps: Eight 120W LEDs with a color temperature of 4,000K and 90 Lm/W efficacy
- Wind Resistance: Withstands up to 125 mph winds when lowered
- Trailer-Mounted: Heavy-duty trailer for easy transport and deployment
- Battery Charger: 40A battery charger for efficient power management
- Durable Build: Powder-coated steel frame for corrosion resistance and durability
- Receptacles Included: (2) 50A twist outlets [120/240V] and (4) 20A [120V] for flexibility
- Eco-Friendly Lighting: LED lights are energy-efficient and free of hazardous substances
Detailed Specifications
| Specification | Details |
|---|---|
| Tower Length | Telescoping from 8.75 to 30
|
| Mast Head Length | 44" |
| Materials | Steel |
| Finish | Powder Coated - Gloss Blue |
| Operation | 3,500 lbs Manual Winch |
| Mast Cable | 3/16" Galvanized Aircraft Cable |
Solar Specifications
| Specification | Details |
|---|---|
| Panel Watts | 2,400W |
| Method of Deployment | Manual |
| System Voltage | 24 Volts |
| Battery Capacity | 1,600aH @ 24V |
| Battery Charger | 40A |
| Outlets | (2) 50A Twist [120/240V], (4) 20A [120V] |
| System Runtime | - |
Light Specifications
| Specification | Details |
|---|---|
| Lamp Quantity | 8 |
| Lamp Technology | LED |
| Total Watts | 960W |
| Single-lamp Watts | 120W |
| Total Lumens | 86,000 |
| Single-lamp Lumens | 10,750 |
| Luminous Efficacy | 90 Lm/W |
| Light Distribution | 1-2 Acres |
| Color Temperature | 4,000K |
| Rated Lifespan | 50,000+ Hours |
| Lens Material | Strengthened Glass |
| Mount | Tower |
Transport Specifications
| Specification | Details |
|---|---|
| Transport Dimensions | 8'-W x 23' 6"-L x 10' 6"-H |
| Deployed Dimensions | 12' 6"-W x 22'-L x 21'-H |
| Dry Weight | 8,450 lbs |
| Axle | - |
| Suspension | - |
| Outriggers | - |
| Wheels | - |
| Tires | - |
| Weight | - |
| Shipping | Common Freight |
| Shipping Dimensions | - |
| Shipping Weight | - |
| Options | Length, Mounting, Fixtures |
Available Options
- Length: Custom lengths available upon request
- Mounting: Secure mounting options for diverse applications
- Fixtures: Configurable lighting and power fixtures based on project needs
In Package
- SPLT-2.4K-1600A-30-8X120W-LED-BC.40.240 Solar Powered Light Tower
- (20) 240W Solar Panels (totaling 2,400W)
- 1,600aH Battery Bank with 40A Charger
- Heavy-duty Trailer with NEMA 3R Control Center
