Products Description
Larson Electronics 20kW Generator - Water Cooled Diesel Engine - 25' Telescoping Tower - (4) LED Lamps - 25 Gal Tank
Description
The WCDE-4-20KW-4X500LTL-LED-CPR-M2 mobile light tower from Larson Electronics is a towable lighting package powered by a 20 kW generator, designed to illuminate a 6-7 acre area continuously for 200+ hours. Equipped with four 400-watt LED lamps producing 208,000 lumens, this unit is ideal for remote locations requiring reliable lighting. The system includes a 50-gallon fuel tank and features a Deepsea controller for real-time monitoring of the IP65-rated unit.
Key Features
- 20 kW Perkins diesel generator
- Four 400-watt LED lamps (208,000 lumens total)
- 200+ hours runtime with a 50-gallon fuel tank
- IP65-rated construction for outdoor use
- Deepsea controller for system monitoring
- Three-phase 120/240V output with various receptacles
- Aluminum telescoping boom up to 25 feet, with 360-degree rotation
- Four-point adjustable outriggers for stability
Applications:
- Emergency services
- Large-scale event illumination
- Construction, mining, industrial operations
- Remote locations without grid access
Detailed Specifications:
Genset Specs:
- Engine: Perkins/404D-22G EPA Tier 4
- Engine Type: 4-cycle, water-cooled, direct injection
- Engine Speed: 1800 RPM
- Cylinders: 4
- Rated Power: 20 kW (22 kW standby)
- Voltage: 120/240V, 50Hz
- Receptacles: (2) 15A 5-15R, (2) 30A L6-30R
- Fuel Capacity: 50 gallons (200+ hours runtime)
- Noise Level: <58 dBA @ 30 ft
- Safety: Low fuel, spill beacon, engine shutdown spill sensor
Light Mast Specs:
- Mast Type: Manual crank-up, telescoping
- Height: Up to 25 feet
- Material: Aluminum
- Rotation: 360 degrees
- Outriggers: Four-point with 2,000 lbs manual leveling jacks
Light Specs:
- Lamp Type: Bridgelux® LED
- Total Watts: 1,600W (400W per lamp)
- Total Lumens: 208,000 lumens (52,000 per lamp)
- Luminous Efficiency: 130 lm/w
- LED Life Expectancy: 80,000 hours
- Waterproof Rating: IP67
- Coverage: 6 to 7 acres
Trailer Specs:
- Material: 14ga sheet steel enclosure, 12ga steel chassis
- Hitch: Combo hitch for 2" ball/2.5" pintle hook
- Axle: 2,200 lbs capacity
- Suspension: 2,000 lbs double-eye leaf springs
- Wheels: (2) 13" steel rims
- Dimensions: 137" L x 93.3" W x 53.9" H
Protection:
- Automatic shutdown for low oil, high engine temp
- Individual light switch circuit breakers
- Deepsea controller for real-time monitoring
- Withstands 50 mph winds at full extension
Larson Electronics manufactures a variety of products, including custom-built designs.
