Larson Electronics 77' Hydraulic Megatower™ Light Plant - 33' Trailer - (20) 500W LED Fixtures - 20KW Genset w/ 110 Gal
Description
The Larson Electronics WCDE-11-HLM65-16X500LTL-LED is a powerful and durable mobile LED light plant designed for rigorous industrial applications. Equipped with a 20KW Kubota diesel generator and twenty 500W LED floodlights, this tower delivers an impressive 1,350,000 lumens to illuminate large areas effectively. The hydraulic mast can extend up to 77 feet, providing elevated lighting suitable for construction sites, mining operations, outdoor events, and emergency services.
With a rugged, dual tandem-axle trailer and an IP67-rated LED system, this Megatower™ is built to withstand challenging terrain and harsh conditions. The cold weather package includes hydraulic de-icing and insulated lines to ensure reliable performance even in freezing temperatures. Each LED head is independently adjustable, allowing operators to direct light precisely where needed. This grid-tie model is efficient and low-maintenance, providing an ideal solution for extended, large-area illumination.
Key Features
- Massive Light Output: 1,350,000 lumens from twenty LED heads, ideal for expansive lighting needs.
- Tall Hydraulic Mast: Extends up to 77 feet with hydraulic operation; collapses to 30 feet for easy transport.
- Long Runtime: Runs for up to 43 hours on a 110-gallon fuel tank, minimizing refueling needs.
- Weatherproof Build: IP67-rated LEDs and galvanized steel mast for protection against environmental elements.
- Cold Weather Package: Prevents hydraulic freezing with insulated de-icing system and weather-rated cables.
- Energy-Efficient LEDs: Low power consumption LEDs reduce heat output and are environmentally friendly.
- Wind Protection: Auto-retracts in high winds for operational safety.
- Six-Point Stabilization: Six jacks with 12” x 12” I-beam construction provide stability on uneven terrain.
- Low Maintenance Requirements: External oil pump system allows 3,000-hour intervals between oil changes.
Detailed Specifications
Genset Specifications
| Specification | Details |
|---|---|
| Genset | 20KW |
| Engine | Perkins, 28.9 HP, liquid-cooled |
| Fuel Type | Diesel |
| Voltage | 120/240V Single Phase |
| Fuel Tank Capacity | 110 gallons with anti-splash baffles |
| Fuel Delivery | Electric |
| Engine Speed | 1800 RPM |
| Cold Weather Package | Included (battery blanket, fuel heater, coolant heater) |
| Noise Level | 68 dB at 23 feet |
Light Mast Specifications
| Specification | Details |
|---|---|
| Tower Length | 30' (collapsed) to 77' (fully extended) |
| Materials | Galvanized Carbon Steel |
| Operation | Hydraulic for upright and extension |
| Wind Resistance | Auto-retract feature for wind speeds over 35 mph |
| Beam Pattern Options | Flood and Spot |
Light Head Specifications
| Specification | Details |
|---|---|
| Lamp Type | LED |
| Total Wattage | 10,000W (500W per lamp) |
| Total Lumens | 1,350,000 lumens (67,500 per lamp) |
| Color Temperature | 5000K |
| Efficiency | 135 lumens per watt |
| Waterproof Rating | IP67 |
| Heat Sink Design | Passive cooling for extended LED lifespan |
Trailer Specifications
| Specification | Details |
|---|---|
| Trailer Dimensions | 33'L x 8'W trailer bed |
| Transport Height | 8'6" |
| Hitch Type | Gooseneck with 12" I-beam construction |
| Axles | (2) 10,000 lbs dual tandem with electric brakes |
| Outriggers | (6) 7,000 lbs jacks with 12' x 12" x 12" I-beams |
| Tires | (8) P235/80R16 with steel rims |
| Weight | 18,000 lbs |
| Wind Resistance | Withstands 50 mph when mast is 30' high, 95 mph when collapsed |
Additional Features
| Feature | Description |
|---|---|
| Environmental Rating | IP67 - withstands dust, water, and extreme conditions |
| Stabilization | Six-point leveling system for uneven terrain |
| De-icing System | Prevents hydraulic lines from freezing in cold climates |
| LED Lifespan | 80,000 hours with 70% lumen retention |
| Independent Control | On/off breaker switches for each bank of LED heads |
| Eco-Friendly Design | Mercury-free, recyclable LEDs with reduced heat emission |
Applications
- Construction site lighting
- Industrial facility illumination
- Emergency services and temporary job site lighting
- Large-scale events
- Mining operations
- Harsh weather environments with extreme cold
In Package
- (1) 20KW Hydraulic LED Megatower™ with 20 x 500W LED light heads
- (1) 110-gallon diesel fuel tank with electric delivery system
- Control Box: NEMA 3R breaker control box with individual light controls
- Cold Weather Package: Hydraulic line de-icing, insulated control box, fuel heater, and battery blanket
- Mounting Accessories: Six-point outrigger stabilizers with hand-crank jacks
