Larson Electronics1.5KW Solar Power Generator w/ Pneumatic Light Tower Mast - (4) LED Lights - 64000 Lumens - 36 Hours

Product Description

Larson Electronics1.5KW Solar Power Generator w/ Pneumatic Light Tower Mast - (4) LED Lights - 64000 Lumens - 36 Hours

Description

The Larson Electronics SPLT-1.5K-1000A-30-4X16K-LED Solar Powered LED Light Plant is a fully solar-powered, mobile LED light tower ideal for remote locations, outdoor events, and work sites requiring sustainable lighting solutions. Equipped with a 1.59 kW solar generator, this unit powers four high-output, 120-watt LED floodlights, offering up to 64,000 lumens. Its 30-foot pneumatic mast, coupled with automated solar panels and advanced battery technology, ensures up to 36.5 hours of continuous operation on a single charge. With dusk-to-dawn and timer-based lighting controls, this solar light tower provides flexible usage tailored to various operational requirements.

Key Features

• Fully Solar-Powered: Zero fuel usage, eco-friendly power solution.
• Extended Operation: Up to 36.5 hours of runtime with intelligent power management.
• High-Output LED Lighting: Four 135-watt LED fixtures, delivering 64,000 lumens.
• 30’ Pneumatic Mast: Smooth, automated height adjustment with a 360° rotating mast.
• Weather Resistant: IP67-rated LED lights, waterproof and resistant to harsh environments.
• Intelligent Lighting Control: Dusk-to-dawn sensor, programmable timers, and multi-intensity settings (0-100%).
• Rugged Trailer Design: Heavy-duty trailer, DOT-compliant with adjustable hitch and removable tongue.
• Multiple Charging Options: Solar charging as primary, with 120V/240V AC charging available.
• Safety-Enhanced: Electric brakes, breakaway switch, outriggers for stability, and robust component cooling.

Detailed Specifications

Solar Power System

• Solar Panels: Six 265-watt polycrystalline panels, totaling 1590 watts.
• Deployment: Rotating axis, hydraulic actuators for deployment, and winter/summer angle adjustment for optimal sunlight.
• Battery Charging: Up to 363 amp-hours daily under peak sunlight conditions.
• Protection: Fused combiner box and Outback Extreme MPPT charge controller with high-heat resistance.

Battery Bank

• Battery Type: Eight 12-volt 250aH AGM batteries.
• Total Capacity: 1000 amp-hours (500 amp-hours usable).
• Alternate Charging: 120V/240V AC with multi-stage protection.
• Battery Life Management: Min/max voltage sensors automatically shut off distribution below 50% capacity.

Light Mast

• Mast Type: Pneumatic with electric compressor for smooth adjustment.
• Height: 8.25 feet (collapsed) to 30 feet (extended).
• Rotation: 360° mast rotation with keyway locks.
• Mounting Capacity: 150 lbs, compatible with lighting and monitoring equipment.

LED Lighting

• Lamp Type: CREE LEDs, each producing 16,000 lumens.
• Total Lumens: 64,000 lumens across four 135-watt floodlights.
• Color Temperature: Cool White, 5000K.
• Waterproof Rating: IP67, ETL-listed for wet locations.
• Independent Control: Intensity settings (0%, 25%, 50%, 75%, 100%) and dusk-to-dawn automation.

Trailer Specifications

• Dimensions: 16’ L x 6’ W bed, with an extended footprint of 16’ L x 10’ W (outriggers deployed).
• Hitch: 2” ball coupler or 3” pintle hitch.
• Axle: 3,500 lbs capacity with leaf springs.
• Safety: Electric brakes with breakaway switch, DOT lighting, and safety chains.
• Outriggers: Four manual leveling jacks for stability.

Control and Monitoring

• System Control: NEMA 3R control box with ground fault protection, battery monitoring, and cooling.
• Cooling: 1400 CFM fan to prevent overheating in high temperatures.
• Monitoring: Outback Mate 3, tracks solar and battery status with SD card logging for analysis.

Additional Information

• Runtime:
  • 36.5 hours at 25% intensity
  • 18.25 hours at 50% intensity
  • 12.15 hours at 75% intensity
  • 9.125 hours at 100% intensity
• Transportation: Skid pockets for forklift, eyelets for crane, and DOT-approved highway transport.
• Weight: 3,000 lbs dry weight; approved for highway travel.

Applications

Ideal for:

• Construction sites, emergency response, events, and telecommunications in remote areas.
• Outdoor lighting for work zones, large event venues, and safety applications.

Customization

Larson Electronics offers full customization for this light tower to accommodate specific project requirements, from additional battery storage to varied light configurations.
