Product Description
Loflin Fabrication | Auger | Drive & Bits | 4" To 48" Bit Range | Hydraulic Flow 6 To 40 GPM | For Skid Steer
DESCRIPTION
The Loflin Fabrication Land Plane is the ultimate tool for achieving perfectly graded and leveled surfaces with ease. Whether you're maintaining driveways, preparing construction sites, or improving soil compaction, this attachment ensures smooth and precise leveling in minimal time.
Built with heavy-duty steel construction, this land plane is designed to withstand rugged use while efficiently redistributing materials, eliminating high spots, and filling low areas. Available in 72" and 84" widths, it provides options to accommodate different project scales while delivering exceptional performance.
Ideal for skid steer loaders, this attachment enables effortless operation, giving professionals the ability to refine dirt roads, level fields, and ensure smooth terrain for optimal usability. Engineered for efficiency and durability, the Loflin Fabrication Land Plane is a must-have solution for roadwork, site preparation, and agricultural applications.
Key Features
- Auburn Planetary Drive Delivers industry-leading torque for high-performance drilling in tough soils and terrain.
- Job-Site Ready Comes pre-equipped with Parker hoses, fittings, and couplers for fast and secure hookup.
- 2” Hex Output Shaft Industry standard output for broad bit compatibility and easy maintenance.
- Wide Range of Bit Sizes Choose from 4" to 48" diameter bits, including standard and tree auger bits.
- Hydraulic Flow Range: 6 – 40 GPM Compatible with a wide range of machines including skid steers and compact tractors.
- Rugged Construction Built to withstand heavy-duty daily use in commercial, agricultural, or residential settings.
- Quick Attach Mount Fast and secure connection to your machine’s universal mounting plate.
Detailed Specifications
Auger Drive Unit
| Specification | Details |
|---|---|
| Model | 0360601000 |
| Type | Hydraulic Auger Drive |
| Gear Drive | Auburn Planetary |
| Hydraulic Flow Range | 6 To 40 GPM |
| Output Shaft | 2" Hex |
| Includes | Parker hoses, fittings, couplers |
| Weight | 326 lbs |
| Mount Type | Universal Skid Steer / Tractor |
Available Auger Bits (Standard Fabrication)
| Bit Model | Bit Size | Type | Weight (lbs) |
|---|---|---|---|
| 03606-03 | 4" | Standard | 44 |
| 03606-04 | 6" | Standard | 60 |
| 03606-05 | 8" | Standard | 75 |
| 03606-06 | 9" | Standard | 94 |
| 03606-07 | 10" | Standard | 100 |
| 03606-08 | 12" | Standard | 118 |
| 03606-09 | 15" | Standard | 132 |
| 03606-10 | 16" | Standard | 145 |
| 03606-11 | 18" | Standard | 168 |
| 03606-12 | 20" | Standard | 189 |
| 03606-13 | 24" | Standard | — |
| 03606-14 | 30" | Standard | 214 |
| 03606-15 | 36" | Standard | 358 |
Available Tree Auger Bits
| Bit Model | Bit Size | Type | Weight (lbs) |
|---|---|---|---|
| 03606-16 | 18" | Tree Bit | — |
| 03606-17 | 24" | Tree Bit | — |
| 03606-18 | 30" | Tree Bit | — |
| 03606-19 | 36" | Tree Bit | — |
| 03606-20 | 42" | Tree Bit | 366 |
| 03606-21 | 48" | Tree Bit | — |
