Product Description
Loflin Fabrication | Front Dump (High Tip) Bucket | Widths 72"-96" | Capacity 1.270 To 1.760 CUYD | For Skid Steer
DESCRIPTION
Introducing the Loflin Fabrication Front Dump Bucket, a revolutionary skid steer attachment designed to enhance your loading capabilities and efficiency on the job site. This innovative bucket addresses the need for higher loading and reach capacity, making it ideal for professionals who require the ability to load into taller trucks and containers.
With an impressive 5 feet of additional height and 3 feet of extra reach compared to standard buckets, the Front Dump Bucket is engineered for optimal performance. It is equipped with two robust 2” x 10” hydraulic cylinders, ensuring powerful operation and reliable performance. The oversized, greasable 1¼” pins enhance durability and ease of maintenance, making this bucket a dependable choice for any task.
The bucket features a 3/4” thick x 6” wide cutting edge, designed for maximum efficiency in various applications. It is available in sizes ranging from 72” to 96”, with custom sizes available to meet your specific needs. Additionally, the optional bolt-on reversible double edge provides added versatility, allowing you to extend the life of your cutting edge.
Safety and convenience are paramount, and all buckets come standard with treaded steps, providing operators with greater traction and support when entering and exiting the cab. The Front Dump Bucket is job site ready, equipped with high-quality Parker brand hoses, fittings, and couplers, ensuring you can get to work immediately.
Key Features
- Extended Reach & Height 5 feet of additional lift and 3 feet of extra forward reach, allowing for efficient material loading into higher trucks or bins.
- Heavy-Duty Hydraulic Cylinders Equipped with two 2″ x 10″ hydraulic cylinders, delivering precise and controlled dumping operation.
- Reinforced Steel Construction Built with ¾″ thick x 6″ wide cutting edge, ensuring long-lasting durability and wear resistance.
- Oversized Greasable Pins 1¼” greasable pins enhance smooth articulation and extended component life.
- Optional Bolt-On Reversible Edge Provides customizable cutting efficiency, maximizing bucket lifespan.
- Fully Protected Hydraulic System Comes equipped with Parker brand hoses, fittings, and couplers, ensuring jobsite-ready performance.
- Reinforced Quick Attach System Enables secure connection to skid steer loaders, optimizing maneuverability and handling.
- Treaded Step for Operator Safety Improves footing and stability, allowing for safe skid steer entry and exit.
- Multiple Width Options Available in 72″, 78″, 84″, and 96″, with custom sizing available upon request.
Detailed Specifications
| Specification | Details |
|---|---|
| Brand | Loflin Fabrication |
| Model Name | Front Dump (High Tip) Bucket |
| Type | High Reach / High Tip Skid Steer Bucket |
| Working Width Options | 72”, 78”, 84”, 96” (and custom sizes available) |
| Height Gain over Standard | 5 feet (approx. 1.52 meters) |
| Reach Gain over Standard | 3 feet (approx. 0.91 meters) |
| Hydraulic Cylinders | Two 2” X 10” |
| Pins | Oversized, greasable 1 ¼” |
| Hose & Fittings | Parker brand (jobsite ready) |
| Cutting Edge | ¾” thick X 6” wide |
| Optional Feature | Bolt-on reversible double edge |
| Operator Step | Treaded step |
| Axle Type | N/A (Skid Steer Attachment) |
| Compatibility | Universal Skid Steer Compatibility |
| Key Benefit | Significantly extends loading height and reach, ideal for efficient loading into tall trucks and containers. |
Comparison Chart
| SKU | Width + Capacity |
Weight + Hydraulic Cylinders |
Notes |
|---|---|---|---|
| 0130101072 | 72" / 1.270 CU YD | 935 lbs / 2" x 10" | High tip, greasable pins |
| 0130101078 | 78" / 1.392 CU YD | 965 lbs / 2" x 10" | Includes Parker hoses |
| 0130101084 | 84" / 1.515 CU YD | 1009 lbs / 2" x 10" | Optional bolt-on edge available |
| 0130101090 | 90" / 1.638 CU YD | 1060 lbs / 2" x 10" | Treaded step for access |
| 0130101096 | 96" / 1.760 CU YD | 1100 lbs / 2" x 10" | Universal quick attach compatible |
