Product Description
Loflin Fabrication | Vertical Root Grapple | 36", 42", 48" Widths | 2”x8” Hydraulic Cylinders | Hydraulic Flow 14 To 43 GPM | Horsepower 18 To 35 HP | For Mini Skid Steers & Tractors
DESCRIPTION
The Loflin Fabrication Mini Skid Steer & Compact Tractor Vertical Root Grapple is precision-engineered to make land clearing, root removal, and debris handling faster and more efficient. Built with heavy-duty steel tines, this attachment works like a rake, allowing dirt to fall through while securely grasping roots, logs, and brush.
Equipped with powerful 2" x 8" hydraulic cylinders, this grapple provides high clamping force, ensuring secure gripping of uneven materials. The independent grapple tines allow for precise control, adapting to the shape and size of materials for optimal performance in landscaping, construction, forestry, and agricultural applications.
Constructed with 3/8” thick steel tines, this grapple is built for durability, capable of withstanding heavy workloads. The powder-coated finish adds corrosion resistance, ensuring long-term reliability in rugged environments.
For seamless installation, the grapple is job-site ready, stocked with Parker brand hoses, fittings, and couplers for smooth hydraulic operation. It is available with Toro Dingo and Bobcat MT mounts, with custom sizing options available for compact tractors. If you need precision, strength, and ease of use, this grapple is the perfect addition to your equipment fleet.
Key Features
- American-Made Quality: Manufactured in the USA for professionals who demand reliability and strength.
- Rake-Like Functionality: Lets soil sift through while gripping roots, limbs, and bulky debris.
- Heavy-Duty Steel Construction: Built from durable 3/8” thick steel tines for aggressive root and stump removal.
- Powerful Cylinders: Equipped with dual 2″ x 8″ hydraulic cylinders for strong and smooth grapple motion.
- Independent Grapple Tines: Each side moves independently to conform to uneven terrain and irregular loads.
- Fully Protected Hydraulic Lines: Prevents hose damage during operation for worry-free jobsite use.
- Parker Hydraulic System: Includes Parker hoses, fittings, and couplers jobsite ready from day one.
- Greasable Hinge Points: Extends tool life while minimizing maintenance hassle.
- Treaded Step (Optional): A stable and safe way to enter your machine with the grapple attached.
- Required Power: Horsepower 18-35 HP & Hydraulic Flow 14-43 GPM
- Custom Fit Options: Available for Toro Dingo, Bobcat MT series, and compact tractors.
- Compact Opening Width: A 33” grapple opening provides excellent control and flexibility for tight areas.
Detailed Specifications
| Feature | Specification |
|---|---|
| Model | Mini Vertical Root Grapple |
| Brand | Loflin Fabrication |
| Compatible Equipment | Mini Skid Steer, Compact Tractors |
| Available Mounts | Toro Dingo MT, Bobcat MT (MT50, MT52, MT55, 570), Custom Tractor Mounts |
| Available Widths | 36", 42", 48" (Custom sizes available) |
| Grapple Opening Width | 33″ |
| Hydraulic Flow | 14 To 43 GPM |
| Horsepower | 18 To 35 HP |
| Tine Thickness | 3/8" Heavy-Duty Steel |
| Tine Style | Vertical Rake with Spacing for Sifting Dirt |
| Hydraulic Cylinders | Two (2) Cylinders, 2″ x 8″ |
| Hydraulic Hoses & Fittings | Parker Brand (Hoses, Couplers, and Fittings Included) |
| Hose Protection | Fully Shielded Hydraulic Lines |
| Hinge Points | Fully Greasable |
| Finish | Powder-Coated for Corrosion Resistance |
| Function | Root Removal, Debris Clearing, Sifting Dirt, Land Clearing |
| Made In | USA |
