Product Description
Lumishore Thru‑Hull Underwater Light | TIX202 Blue | Interchangeable LED | For Small to Medium Yachts
DESCRIPTION
The Lumishore TIX202 Blue Thru‑Hull Underwater Light is a compact yet powerful fixture designed for small to medium yachts. Delivering 4,100 lumens with a focused 60° beam angle, it creates brilliant underwater illumination and vibrant blue effects. Built with a marine‑grade aluminum bronze housing, the TIX202 offers the integrity of a thru‑hull installation with the convenience of an interchangeable LED array that can be serviced from inside the boat. Featuring an internal driver module, simple installation, and advanced protections, the TIX202 is a cost‑effective solution for owners seeking high‑performance underwater lighting.
Key Features
- Compact & Powerful – 4,100 lumens with a 60° beam angle.
- Blue Illumination – Creates stunning underwater effects for small to medium vessels.
- Interchangeable LED Array – Serviceable from inside the hull, no haul‑out required.
- Internal Driver Module – Simplifies installation and reduces wiring complexity.
- Durable Housing – Marine‑grade aluminum bronze construction.
- Flexible Mounting – Suitable for transom, side, or bottom hull installation.
- Advanced Protections – Over‑voltage/current, reverse polarity, and thermal safeguards.
- Compact Design – Low‑profile flush‑fit with minimal protrusion.
- Compatible Power – Works with both 12VDC and 24VDC systems.
- Limited 2‑Year Warranty – Backed by Lumishore reliability.
Detailed Specifications
| Specification | Details |
|---|---|
| Part Number | 60‑0152 |
| Model | TIX202 Blue |
| Beamwidth | 60° |
| Color | Blue |
| Lumens | 4,100 fixture lumens |
| LEDs Used | 9 |
| Input Voltage | 12 / 24 VDC |
| Driver Type | Internal driver module |
| Cut‑Out Size | 1.1" |
| Dimensions | 2.94" diameter, 0.36" profile, 7.1" shaft length |
| Max Hull Thickness | 5" |
| Housing Material | Marine‑grade aluminum bronze |
| Mounting Options | Transom, side, or bottom hull |
| Protections | Over‑voltage/current, reverse polarity, thermal |
| Warranty | Limited 2 years |
