Machinerie AM Inc | 900 Series ATV Grapple Loader/Trailer Package
Description
The 900 Series by AM Machinery is a versatile and lightweight machine designed for pulling with 500CC+ ATVs, Argo’s, and small tractors. Its compact footprint makes it ideal for maneuvering through narrow trails and dense bush areas.
Additional Highlights:
- Telescopic Legs: Allow for a smaller footprint in tight areas.
- Protected Leg Cylinders: Positioned on the sides to avoid damage from falling trees or debris.
- Rack and Pinion Grapple System: Offers precision and reliability, avoiding issues common with chain-driven systems.
- Double Pole Trailer: Ensures stability and equal load distribution.
- Boom-Mounted Winch: Enhances maneuverability when handling logs.
This combination of features makes the 900 Series a robust and efficient choice for various forestry and agricultural tasks.
Key Features
- 9’ Boom with 270° Rotation: Provides extensive reach and flexibility.
- Telescopic Stabilizers: Enhance stability and adaptability in various terrains.
- Lifting Capacity: Capable of lifting 1800 lbs at half-boom and 950 lbs at full reach.
-
Hydraulic Unit: Eliminates the need for auxiliary power, simplifying operation.
Detailed Specifications
| Model Code | 900R |
|---|---|
| Weight | 535 lbs |
| Capacity | 3500 lbs |
| Recommended for | ATV |
| Overall Length (F) | 161" |
| Overall Width (A) | 54" |
| Coupler Height (D) | 13" |
| Posts Max Height (B) | 25" |
| Loading Length (E) | 93" |
| Loading Width © | 38" |
| Base Loading Width (G) | 23 1/2" |
| Track Width (H) | 44" |
| Spindles | 1/2" |
| Hub Qty/Bolts | 5 holes |
| Agricultural Tire | 25X12X10 |
| Tongue Stand | Jack |
| Tandem | Adjustable |
| Ground Clearance (K) | 14" |
| Agricultural Tires | 25 x 12 x 10 |
