Product Description
Machinerie AM Inc | AM Series of Road Dump Trailer | 2 Axles of 1,500 lbs To 15,000 lbs Double Tires | GVWR 2 850 lbs To 30 000 lbs
Description
Our range of road dump trailers is designed to meet the diverse needs of professionals and hobbyists alike. Whether you’re handling small-scale landscaping projects or large-scale construction tasks, these trailers offer unmatched durability, efficiency, and versatility. Each model is equipped with a powerful 12V hydraulic system, robust axles, and high-capacity tires to ensure smooth and reliable performance. With various sizes and payload capacities ranging from 2,850 lbs to 30,000 lbs, you can find the perfect trailer to suit your specific requirements. Features include double-door tailgates for easy loading and unloading, electric brakes for enhanced safety, and sturdy construction to withstand the toughest jobs. Choose AM road dump trailers for your hauling needs and experience the difference in quality and performance.
Key Features
- Hydraulic System: Equipped with a powerful 12V hydraulic unit for efficient dumping operations.
- Robust Axles: Each trailer features dual axles with varying capacities to support different payloads.
- High Payload Capacity: Payload capacities range from 2,850 lbs to 30,000 lbs, catering to various hauling needs.
- Durable Construction: Built with high-quality materials to withstand tough working conditions.
- Double-Door Tailgate: Easy loading and unloading with double-door tailgates.
- Electric Brakes: Enhanced safety with optional or included electric brakes.
- Heavy-Duty Tires: Fitted with high-capacity tires suitable for different trailer sizes and loads.
- Versatile Sizes: Available in multiple dimensions, from 4’ x 8’ to 8’ x 24’, to suit different tasks.
- Gooseneck Options: Some models offer gooseneck configurations for improved stability and towing capacity.
- User-Friendly Design: Designed for ease of use, with features that simplify operation and maintenance.
These features ensure that AM hydraulic dump trailers provide reliable performance and versatility for a wide range of applications.
Detailed Specifications
Model | Weight (lbs) | Box Size | Capacity (GVWR) | Axles | Overall Length | Overall Width | Coupler Height | Side Wall Height | Track Width Center/Center | Axle Diameter | Quantity of Bolts | Suspension Blades | Tires | Tailgate | Coupler | 12 Volt Hydraulic Unit | Electric Brakes | Hydraulic Brakes | Cylinder |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
AM 480-285 | 1350 | 4’ x 8’ | 2850 | 2 x 1,500 lbs | 180" | 70" | 13″ | 20″ | 60″ | 1.900″(2) | 5 | Std | 175/80Dl3 | Double Door | 2″ | Included | Optional 7″ | N/A | Under 3″ x 6″(I) |
AM 510-700 | 1865 | 5’ x 10’ | 7,000 | 2 x 3,500 lbs | 204" | 82 1/2" | 15″ | 20″ | 72″ | 2 3/8″(2) | 5 | Std | 225/75Dl5 | Double Door | 2 5/16″ | Included | STD | N/A | Under 3″ x 6″(2) |
AM 610-1000 | 1925 | 6’ x 10’ | 10,000 | 2 x 5,000 lbs | 204" | 94 1/2" | 15″ | 20″ | 84″ | 3″(2) | 6 | Std | 225/75Dl5 | Double Door | 2 5/16″ | Included | STD | N/A | Under 3″ x 16″(2) |
AM 612-1200 | 2350 | 6’ x 12’ | 12,000 | 2 x 6,000 lbs | 228" | 94 1/2" | 15″ | 20″ | 84″ | 3″(2) | 8 | Std | 235/85R16 | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic |
AM 614-1400 | 2650 | 6’ x 14’ | 14,000 | 2 x 7,000 lbs | 252" | 94 1/2" | 20″ | 20″ | 84″ | 3″(2) | 8 | Std | 235/85R16 | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic |
AM 614-1600 | 3040 | 6’ x 14’ | 16,000 | 2 x 8,000 lbs | 252" | 94 1/2" | 20″ | 20″ | 84″ | 3″(2) | 8 | Std | 235/85R16 | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic |
AM 616-1400 | 3100 | 6’ x 16’ | 14,000 | 2 x 7,000 lbs | 276" | 94 1/2" | 20″ | 20″ | 84″ | 3″(2) | 8 | Std | 235/85R16 | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic |
AM 616-2000 | 3400 | 6’ x 16’ | 20,000 | 2 x 10,000 lbs (double tires) | 276" | 94 1/2" | 20″ | 20″ | 84″ | 3″(3) | 8 | Std | 235/85R16 | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic |
AM 616-2400 | 3600 | 6’ x 16’ | 24,000 | 2 x 12,000 lbs (double tires) | 276" | 94 1/2" | 20″ | 20″ | 84″ | 3″(2) | 8 | Std | 235/85R16 | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic |
AM 714-1400 | 3800 | 7’ x 14’ | 14,000 | 2 x 7,000 lbs | 252" | 94 1/2" | 20″ | 20″ | 84″ | 3″(2) | 8 | Std | 235/85R16 | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic |
AM 714-1600 | 3900 | 7’ x 14’ | 16,000 | 2 x 8,000 lbs | 252" | 94 1/2" | 20″ | 20″ | 84″ | 3″(2) | 8 | Std | 235/85R16 | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic |
AM 716-1400 | 4000 | 7’ x 16’ | 14,000 | 2 x 7,000 lbs | 276" | 94 1/2" | 20″ | 20″ | - | 3″ (2) | 8 | Std | - | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic |
AM 716-1600 |
4100 | 7’ x 16’ | 16,000 | 2 x 8,000 lbs | 276" | 94 1/2" | 20″ | 20″ | - | 3″ (2) | 8 | Std | - | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic |
AM 718-2000 |
4799 | 7’ x 18’ | 20,000 | 2 x 10,000 lbs (double tires) | 300" | 94 1/2" | 20″ | 20″ | - | 3″ (2) | 8 | Std | - | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic |
AM 720-2000 |
- | 7’ x 20’ | 20,000 | 2 x 10,000 lbs (double tires) | 324" | 94 1/2" | 20″ | 20″ | - | 8 | Std | - | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic | |
AM 716-2000 |
- | 7’ x 16’ | 20,000 | 2 x 10,000 lbs (double tires) | 276" | 94 1/2" | 20″ | 20″ | - | 8 | Std | - | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic | |
AM 816-1400 |
- | 8’ x 16’ | 14,000 | 2 x 7,000 lbs | 276" | 20″ | 20″ | - | 8 | Std | - | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic | ||
AM 816-1600 |
- | 8’ x 16’ | 16,000 | 2 x 8,000 lbs | 276" | 20″ | 20″ | - | 8 | Std | - | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic | ||
AM 820-2000 |
- | 8’ x 20’ | 20,000 | 2 x 10,000 lbs (double tires) | 324" | 20″ | 20″ | - | 8 | Std | - | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic | ||
AM 820-3000 |
- | 8’ x 20’ | 30,000 | 2 x 15,000 lbs (double tires) | 324" | 20″ | 20″ | - | 8 | Std | - | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic | ||
AM 824-3000 |
9766 | 8’ x 24’ | 30,000 | 2 x 15,000 lbs (double tires) | 385" | 20″ | 20″ | - | 8 | Std | - | Double Door | 2 5/16″ | Included | STD | Optional | Telescopic |
