MDE Machinery | Log & Debris Grapple with Saw | Fixed Position | Model SX1400SAW | Opening Width 43.33" Inches | For 13-18 Ton Excavators

MDE Machinery | Log & Debris Grapple with Saw | Fixed Position | Model SX1400SAW | Opening Width 43.33" Inches | For 13-18 Ton Excavators

Regular price $45,758.91
Regular price Sale price $45,758.91
Sale Sold out
Customizable
Fast
24/7 Support
  • Fixed-Position Design Provides superior stability and control.
  • Large 43.33” Grapple Opening Securely grabs and holds logs and materials.
  • Mount & Pins Included Ensures hassle-free installation.
  • Compatible with 13-18 Ton Excavators Ideal for mid-range excavators in forestry and construction.
  • Optimal Gripping Power Designed to handle heavy and bulky materials efficiently.
View full details

Product Description

MDE Machinery | Log & Debris Grapple with Saw | Fixed Position | Model SX1400SAW | Opening Width 43.33" Inches | For 13-18 Ton Excavators



DESCRIPTION

The MDE Machinery SX1400SAW is a powerful and rugged log and debris grapple with an integrated saw, designed to handle heavy-duty material handling in forestry, construction, and land-clearing applications. Built from 100% Swedish Hardox Steel, this fixed-position grapple delivers unmatched strength, durability, and precision, making it an essential attachment for 13 to 18-ton excavators.

Equipped with a 43.33-inch grapple opening and a 19-inch cutting diameter, the SX1400SAW is engineered to efficiently grip, lift, and cut logs, branches, and debris, ensuring maximum productivity. Whether you're clearing dense forests, managing storm debris, or handling construction materials, this grapple provides unrivaled gripping power and cutting efficiency.

With its fixed-position design, the SX1400SAW eliminates unnecessary movement, offering increased control and stability. The mount and pins are included for easy installation, allowing operators to get to work quickly. However, hoses and couplers are not included, giving users the flexibility to customize their hydraulic setup.

Key Features

  • Heavy-Duty Hardox Steel Construction Built for extreme durability and longevity.
  • Integrated Saw Efficiently cut through logs and debris with precision.
  • Fixed-Position Design Provides superior stability and control.
  • Large 43.33” Grapple Opening Securely grabs and holds logs and materials.
  • Mount & Pins Included Ensures hassle-free installation.
  • Compatible with 13-18 Ton Excavators Ideal for mid-range excavators in forestry and construction.
  • Optimal Gripping Power Designed to handle heavy and bulky materials efficiently.
  • Versatile Applications Perfect for logging, land clearing, and storm cleanup.

Host Machines

Name Photo (if available)
BOBCAT E145 BOBCAT E145
BOBCAT E165 BOBCAT E165
CASE CX160D CASE CX160D
DOOSAN DX140LC-5 DOOSAN DX140LC-5
DOOSAN DX140LCR-5 DOOSAN DX140LCR-5
DOOSAN DX170LC-5 DOOSAN DX170LC-5
HITACHI ZX160LC-6 HITACHI ZX160LC-6
JOHN DEERE 130G JOHN DEERE 130G
JOHN DEERE 135G JOHN DEERE 135G
JOHN DEERE 160G LC JOHN DEERE 160G LC
KOBELCO SK140SRLC-7 KOBELCO SK140SRLC-7
KOMATSU PC130-11 KOMATSU PC130-11
KOMATSU PC138USLC-11 KOMATSU PC138USLC-11
SANY SY135U SANY SY135U
SANY SY155U SANY SY155U
TAKEUCHI TB2150 TAKEUCHI TB2150
VOLVO EC140E VOLVO EC140E
VOLVO ECR145C VOLVO ECR145C
WACKER NUESON ET145 WACKER NUESON ET145



Detailed Specifications

Feature Specification
Excavator Compatibility 13 - 18 Tons
Width 31”
Height 40”
Teeth Thickness 1.18”
Grapple Opening Width 43.33”
Grapple Maximum Opening 55.11”
Grapple Minimum Closing 4.3”
Weight 1,763 lbs
Cutting Diameter 19”
Material 100% Swedish Hardox Steel
Mount & Pins Included
Hoses & Couplers Not Included
