MK Martin | 3PH Wing Rotary Cutter | Model PW180 | 15' Cutting Width | Horsepower 75+ HP | For Tractors
MK Martin | 3PH Wing Rotary Cutter | Model PW180 | 15' Cutting Width | Horsepower 75+ HP | For Tractors
Couldn't load pickup availability
Couldn't load pickup availability
Product Description
MK Martin | 3PH Wing Rotary Cutter | Model PW180 | 15' Cutting Width | Horsepower 75+ HP | For Tractors
DESCRIPTION
Transform your land maintenance with the MK Martin 3PH Wing Rotary Cutter (Model PW180), a robust, high-performance cutting tool designed for heavy-duty applications. With an impressive 15-foot cutting width, this rotary cutter is ideal for clearing fields, pastures, and brush with ease. The three triple-blade assemblies make quick work of even the toughest stubble, while the independently floating wings (20° in either direction) follow the contours of the terrain for a perfectly even cut every time.
Designed for optimal efficiency and convenience, the PW180 Wing Rotary Cutter features hydraulic wings that fold up for easy transport and compact storage. Whether you're tackling large fields or navigating tight spaces, this cutter is built to handle it all. The heavy-duty gearbox and independent slip clutch protection ensure durability and minimize downtime, even under the most challenging conditions.
If you're looking for a reliable, versatile, and easy-to-maintain rotary cutter, the MK Martin PW180 Wing Cutter is the perfect addition to your fleet. It’s engineered to provide professional-grade results and exceptional durability, making it ideal for everything from routine mowing to clearing brush and stubble.
Key Features
- Massive 15' Cutting Width Tackle large properties and clear brush quickly with the 15-foot cutting width. Perfect for large farms, pastures, or fields.
- Independent Floating Wings Each wing floats 20° in either direction, ensuring the cutter conforms to the natural contours of the ground for a uniform and precise cut.
- Hydraulic Wing Fold for Easy Transport Fold the wings up to reduce the overall width to 78 inches, making it easier to transport and store in tight spaces.
- Heavy-Duty Gearboxes The cutter is powered by four robust gearboxes two for the wings, one for the center, and one divider each designed to provide maximum power and durability. The gearbox ratings are 140 HP for the wings and 105 HP for the center.
- Durable 3/16" Deck Constructed from tough 3/16" steel, the deck is built to withstand demanding environments and provide years of reliable service.
- Slip Clutch Protection Each spindle is equipped with an independent slip clutch, providing essential protection against damage during heavy use and ensuring the longevity of the cutter.
- Pneumatic Wheels The 21" pneumatic wheels provide superior traction and stability, even on uneven or rough ground, enhancing the cutter's overall performance.
- Wide Cutting Height Range Adjust the cutting height from 3" to 15" to handle various vegetation types, from grass to thick brush and stubble.
- Stump Jumper Included The built-in stump jumper prevents damage to the blade assembly when encountering obstacles like rocks or stumps, ensuring smooth operation.
- Optional Tandem Axle For additional stability and smoother operation, an optional walking tandem axle is available, adding four wheels for extra support during use.
Detailed Specifications
| Feature | PW180 |
|---|---|
| Shipping Weight (LBS.) | 4,400 |
| 3PH Mount | Drawbar Hitch |
| Cutting Height | 3" - 15" |
| Cutting Path | 180" |
| Max Brush Diameter | 1.5" |
| Overall Width (Wings Down) | 184" |
| Folded Width (Wings Up) | 78" |
| Tip Speed (Ft/Min) | 15,100 ft/min (Wings), 14,850 ft/min (Center) |
| Wheels (Pneumatic) | 21" |
| Blades | 9 blades (1/2" x 4") |
| Tractor HP (Min) | 75 HP |
| PTO RPM | 540 |
| Gearbox Rating (Wing) | 140 HP |
| Gearbox Rating (Center) | 105 HP |
| Gearbox Rating (Divider) | 87 HP |
| Deck | 3/16" |
| Stump Jumper | Yes |
| Protection | Independent Slip Clutch on Each Spindle |
| Wing Float Range (Degrees) | 20° Down, 33° Up |
| Optional Tandem Axle | Yes |
