Product Description
MK Martin | Land Plane Grader | LP678, LP778 & LP878 | Working Width 72"-96" | For Skid Steers
DESCRIPTION
The MK Martin Grader Blade Skid Steer Attachments (LP678, LP778, LP878) are essential tools for tackling a variety of surface prep and grading tasks. Designed for heavy-duty use on gravel roads, construction sites, and agricultural lands, these Land Plane attachments are equipped to handle tough surfaces, including hardpack and potholes, ensuring a smooth, professional-grade finish every time.
Available in 72", 84", and 96" working widths, these models offer flexibility and precision, depending on the scale of your job. The dual hydraulic cylinders power the scarifier bar, digging deep below the surface to loosen material, which is then pulled to the surface for redistribution. The hydraulic control system allows operators to adjust the pressure on the fly, adapting seamlessly to varying ground conditions without leaving the operator’s seat.
The MK Martin Grader Blade Skid Steer Attachments are engineered for skid steer loaders (SSL) but can also be equipped with an optional 3PH (three-point hitch) mount, increasing versatility. Constructed with high-quality materials like hardened reversible cutting edges and long-wearing shanks, these attachments ensure long-lasting performance and precise grading, making them a must-have for any jobsite.
Key Features
- Versatile Working Widths: Choose between 72", 84", and 96" working widths for the perfect fit for your skid steer and job requirements.
- Dual Hydraulic Scarifier Bar: Loosens hardpack and digs deep to redistribute materials for a smooth, level finish.
- Reversible Hardened Cutting Edges: Features 1/2" thick reversible cutting edges, ensuring a durable, efficient grading process while maintaining sharpness for longer periods.
- Heavy-Duty Construction: Built with 4" x 6" x 1/4" steel tube frame for superior strength, ideal for tough terrains.
- Adjustable Long-Wearing Shanks: Includes 6 to 8 durable, adjustable shanks with replaceable chisel tips for optimal material penetration and leveling.
- Bolt-On Skid Shoes: AR400 abrasion-resistant skid shoes allow you to smoothly pass over surfaces without causing unnecessary damage.
- Hydraulic Control System: Adjust scarifier bar pressure directly from the operator’s seat, adapting quickly to changing conditions.
- Optional Skid Steer and 3PH Mount: Provides flexibility to use the attachment with skid steer loaders or tractors, offering a versatile solution for different needs.
- Flow-Over Design: Prevents the need to raise the grader for material release, improving efficiency and ease of use.
Detailed Specifications
| Feature | MK Martin LP678 (72") | MK Martin LP778 (84") | MK Martin LP878 (96") |
|---|---|---|---|
| Model | LP678 | LP778 | LP878 |
| Working Width | 72" | 84" | 96" |
| Overall Width | 77" | 89" | 101" |
| Length | 69.5" | 69.5" | 69.5" |
| Shank Quantity | 6 | 7 | 8 |
| Shank Tube Dimensions | 4" x 6" x 1/4" | 4" x 6" x 1/4" | 4" x 6" x 1/4" |
| Cutting Edge | Hardened 1/2" - Reversible | Hardened 1/2" - Reversible | Hardened 1/2" - Reversible |
| Skid Shoes | 3/8" x 2 Reversible | 3/8" x 2 Reversible | 3/8" x 2 Reversible |
| Cylinders | Dual Hydraulic Cylinders | Dual Hydraulic Cylinders | Dual Hydraulic Cylinders |
| Weight | 1,140 lbs | 1,240 lbs | 1,350 lbs |
| Mounting Options | Skid Steer, 3PH (Optional) | Skid Steer, 3PH (Optional) | Skid Steer, 3PH (Optional) |
