Products Description
Multivator FP Frame Assembly | 66"-192" Working Width | 09"-32" Tillage Heads | 25-100 HP | 20" Ground Clearance
DESCRIPTION
The Multivator FPA & FPXA Frame Assemblies are designed for medium-duty cultivation in tall crops such as nursery plants, ornamental grasses, and specialty row crops. Built with superior ground clearance (FPA: 25” | FPXA: 32”), these models effectively reduce weed pressure while ensuring efficient soil aeration and preparation.
With multiple frame widths and tillage head options, these Multivators can be tailored to fit specific farming needs, making them an excellent choice for precision cultivation. Featuring a durable Comer gearbox, steel gauge wheels, and customizable accessories, the FPA & FPXA provide unmatched efficiency and reliability for modern agricultural operations.
Backed by over 30 years of North American expertise, these Italian-engineered machines continue to set the standard in eco-friendly, high-performance weed control.
Key Features
- Optimized for Tall Crops – 25” (FPA) & 32” (FPXA) ground clearance for effective cultivation in nursery and ornamental crops.
- Medium-Duty Performance – Lightweight yet durable, built for efficiency and versatility.
- Comer Gearbox (540 RPM) – Reliable power transfer ensures smooth operation in varying soil conditions.
- Steel Gauge Wheels – Provides stability and precise depth control for consistent cultivation.
- Multiple Frame Widths Available – Customizable to match different field sizes and row configurations.
- Configurable Tillage Head Widths – Choose from different tillage head sizes for tailored cultivation.
- Optional Granular Fertilizer Box – Available in 40”, 60”, and 80” capacities for integrated soil nourishment.
- Optional FPA/FPXA Ridger Assembly – Enhances soil mounding and row shaping for specific crop needs.
Detailed Specifications
FPA Model Details
| Feature | Details |
|---|---|
| Brand | Multivator |
| Ground Clearance | 25” |
| Compatible Applications | Nursery crops, ornamental grasses, and tall crops |
| Frame Widths Available | 66” (386 lbs.), 90” (424 lbs.), 132” (579 lbs.), 180” (758 lbs.), 192” (925 lbs.) |
| Tillage Head Widths | 9”-11” (164 lbs., 8 blades), 12”-16” (172 lbs., 8 blades), 18”-22” (193 lbs., 16 blades), 24”-32” (219 lbs., 24 blades) |
| Drive Shaft | Hexagonal |
| Gearbox | Comer (540 RPM) |
| Gauge Wheels | Heavy-duty steel construction |
| Hitch Type | 3-Point Hitch |
| Customization Available | Yes |
FPXA Model Details
| Feature | Details |
|---|---|
| Brand | Multivator |
| Ground Clearance | 32” |
| Compatible Applications | Tall crops, heavy cover crops |
| Frame Widths Available | Same as FPA |
| Tillage Head Widths | 12”-16” (180 lbs., 8 blades), 18”-22” (200 lbs., 16 blades), 24”-32” (225 lbs., 24 blades) |
| Drive Shaft | Hexagonal |
| Gearbox | Comer (540 RPM) |
| Gauge Wheels | Heavy-duty steel construction |
| Hitch Type | 3-Point Hitch |
| Customization Available | Yes |
In Package
- FPA/FPXA Tool Bar
- Hex Drive Bar
- Steel Gauge Wheels
- Comer Gearbox (540 rpm)
- 3-Point Hitch and Hardware
- PTO Shaft (standard size 6, size 6 with slip clutch, or size 8 with slip clutch)
- Optional Granular Fertilizer Box (40", 60", 80" capacity)
- Optional FPA/FPXA Ridger Assembly
Enhance your cultivation process with the Multivator FPA and FPXA Frame Assemblies. Designed for medium-duty applications, these machines offer the perfect blend of performance and reliability for your taller crops. Contact us today to customize your Multivator package and elevate your agricultural operations. Don’t wait—optimize your cultivation efficiency now!
