OCMIS MR-63 MICRO RAIN GREEN SPACES HOSE REEL
***Online pricing not available, Please request a quote:***
How To Get A Quote:
Option 1:
Contact Us to make sure you are getting the best unit possible. These machines are complex so let us help you get exactly what you need!
Option 2: (quickest response times)
Step 1. Add the item to your cart
Step 2. Checkout or Click on the Chat button box that is at the bottom right of your screen
Step 3. Please tell us any info you think we would need to know
Step 4. Relax, our team is processing your request and an expert will be in touch to get you exactly what you need!
DESCRIPTION
The MR63 hose reel is designed for efficient irrigation of green spaces such as sports facilities, parks, gardens, and play areas. Here are its key features:
- Hose Diameter: 2.1 inches
- Hose Length: 328 feet
- Water Flow Rate: Up to 140 gallons per minute
- Irrigation Width: Over 200 feet
- Irrigation Length: Up to 450 feet
This model is ideal for:
- Football fields (natural and artificial surfaces)
- Vegetable farms
- Sod farms
- Equestrian facilities with large arenas
The MR63 is perfect for serious irrigators who need to apply large amounts of water quickly and efficiently.
TECHNICAL FEATURE
A (cm) | B (cm) | C (cm) | D (cm) |
---|---|---|---|
270 | 190 | 130 | 162 |
SPECIFICATIONS
- Chassis: 3-wheel design provides a stable base and easy to tow behind small powered vehicles and room for mounting booster pumps.
- Hitch: Heavy-duty galvanized design with strong hinge points and doubles as the anchor or stabilizer when raised in operation position. One part number serves two functions.
- Drum gear: Heavy-duty drive gear is bolted to the reel so if the need ever arises, it can be replaced with simple tools. No need for a cutting torch and welder.
- Levelwind: Scroll levelwind wraps tube accurately on the reel as the machine operates. No chains or gearboxes.
- Shutoff: Micro Rains were all designed with mechanical water shutoffs. These creative shutoffs eliminate the tubes, filters, valves actuating devices normally associated with traveler shutoffs.
- Cart lift: A one-piece hanger is incorporated as part of the sprinkler cart to easily hang the cart on the machine. The MR58 cart lifts automatically onto the machine at the end of the run.
- Cart tires: MR 43 and larger machines all have pneumatic wheels.
- Rear wheels: Sealed bearings with wide turf tires. Eliminates the need to grease on a regular basis. Turf tires provide support to help keep machine from rutting in soft or wet soils.
- PTO Rewind: Used to make small adjustments or to wind machine up if the needs arises to service or if field is wet.
- Turbine: The ultimate design in drive trains for small travelers. Compact direct coupled, eliminates belts, pulleys, springs and unnecessary parts and pieces.
- Chain cover: Levelwind chain cover completely wraps the chain reducing exposure to rain, dust and hard water being pumped. This increases the longevity of the chain and reduces maintenance.
Hose Diameter (mm) | Hose Length (m) | Raingun | Nozzles | End Hose |
---|---|---|---|---|
50 | 170 | HYDRA | 12/14/16 | J |
58 | 140 | HYDRA | 12/14/16 | I |
63 | 100 | HYDRA | 12/14/16 | A |
OPTIONS
- Booster pump
- Engine drive for slurry applications
- Blow out compressor
- Rewind by engine
- Rotating base on MRR58
