DESCRIPTION

The MRR58 hose reel is a robust and high-performing irrigator, ideal for agricultural use. Here are its key features:

• Hose Capacity: 656 feet
• Rotating Base: Yes
• Frame and Chassis: More robust and galvanized compared to the MR58
• Gun: Sime-Hydra with 12/14/16 mm nozzles
• Reduces turbine load loss
• Provides a range of machine speeds even with very low flows and inlet pressures

This model is appreciated by agriculturalists worldwide for its versatility, user-friendliness, and low running and maintenance costs.

TECHNICAL FEATURE

SPECIFICATIONS

• Chassis: 3-wheel design provides a stable base and easy to tow behind small powered vehicles and room for mounting booster pumps.
• Hitch: Heavy-duty galvanized design with strong hinge points and doubles as the anchor or stabilizer when raised in operation position. One part number serves two functions.
• Drum gear: Heavy-duty drive gear is bolted to the reel so if the need ever arises, it can be replaced with simple tools. No need for a cutting torch and welder.
• Levelwind: Scroll levelwind wraps tube accurately on the reel as the machine operates. No chains or gearboxes.
• Shutoff: Micro Rains were all designed with mechanical water shutoffs. These creative shutoffs eliminate the tubes, filters, valves actuating devices normally associated with traveler shutoffs.
• Cart lift: A one-piece hanger is incorporated as part of the sprinkler cart to easily hang the cart on the machine. The MR58 cart lifts automatically onto the machine at the end of the run.
• Cart tires: MR 43 and larger machines all have pneumatic wheels.
• Rear wheels: Sealed bearings with wide turf tires. Eliminates the need to grease on a regular basis. Turf tires provide support to help keep machine from rutting in soft or wet soils.
• PTO Rewind: Used to make small adjustments or to wind machine up if the needs arises to service or if field is wet.
• Turbine: The ultimate design in drive trains for small travelers. Compact direct coupled, eliminates belts, pulleys, springs and unnecessary parts and pieces.
• Chain cover: Levelwind chain cover completely wraps the chain reducing exposure to rain, dust and hard water being pumped. This increases the longevity of the chain and reduces maintenance.

OPTIONS

• Booster pump
• Engine drive for slurry applications
• Blow out compressor
• Rewind by engine
• Rotating base on MRR58
